Installing the Drive

Before installing the drive, turn

off the system power.

Disconnect the power

cord, and remove the

cover.

• Remove a vacant 5.25" drive bay panel

from the computer. Slide the drive into

the drive bay.

Connecting the SATA

Power Cable

• Connect the power cable so the

projection of the cable connector side to

come to the left side. Be careful not to

connect upside down.

NOTE:

Improper connection may damage the

drive and void the warranty. Generally,

the power connector can only fit one way.

Connect to the power connector of the PC.

Page 1: Installing The Drive
Installing the Drive Before installing the drive, turn off the system power. Disconnect the power cord, and remove the cover. • Remove a vacant 5.25” drive bay panel from the computer. Slide the drive into the drive bay. Connecting the SATA Power Cable •...
Page 2 Connecting the SATA Data Cable • Connect the data cable. Be careful not to connect upside down. Connect to the SATA connector on the PC's Motherboard. Replace the cover, connect the power cord and restart your computer. • Your computer configuration may different from the illustrations.
Page 3: System Environment
Windows 10, 8.1, 8, 7, Vista(X86, X64), XP [Home Edition/ Professional/Media Center Software Required OS Edition] with SP3 or higher,Direct X 9.0 or Higher is required. CD-R : LG, Mitsubishi Kagaku Media, Verbatim, Taiyo Yuden or TDK discs are Recommended media recommended.
Page 4: Safety Instructions
Safety Instructions CAUTION: The laser used in the Drive can damage your eyes. Do not attempt to open PERICOLO : Il dispositivo di lettura e scrittura utilizzato in questo masterizzatore the cover. To reduce the risk of electric shock, do not remove the cover (or back). utilizza un raggio laser che, se osservato da vicino, può...
