Sunshine Kids Monterey Manual

Expandable booster
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
skjp.com
50_Monterey (EngUK) Manual_04-09-10.indd 1
4/9/10 8:39:39 AM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Monterey and is the answer not in the manual?

Questions and answers

Related Manuals for Sunshine Kids Monterey

Summary of Contents for Sunshine Kids Monterey

  • Page 1 skjp.com 50_Monterey (EngUK) Manual_04-09-10.indd 1 4/9/10 8:39:39 AM...
  • Page 2 Securing the Child 12-13 Section 8 Seat Belt Buckle Position Section 9 Care and Maintenance Section 10 Warranty Product: Monterey™ child booster seat Model: 15000 Mfg. by: Sunshine Kids Juvenile Products, Ltd. PO Box 12463 Tamworth, Staffordshire B77 9AS UK Customer Service: Tel: 0845 300 9071 Email: uk-sales@skjp.com...
  • Page 3 Head support adjuster Upper belt guide Adjuster for seat ISOFAST™ back width adjuster strap Cup holder ISOFAST™ connectors Lower belt guide Fig. 1 Diagonal Fig. 1A Fig. 1B 50_Monterey (EngUK) Manual_04-09-10.indd 3 4/9/10 8:39:39 AM...
  • Page 4 Fig. 2 Fig. 2A Fig. 3 Fig. 5 Fig. 4 50_Monterey (EngUK) Manual_04-09-10.indd 4 4/9/10 8:39:39 AM...
  • Page 5 Fig. 6 Fig. 7 Fig. 9 Fig. 8 Fig. 10 50_Monterey (EngUK) Manual_04-09-10.indd 5 4/9/10 8:39:39 AM...

  • Page 6: Warnings

    (diagram A) Sunshine Kids advises that any child seat not be purchased secondhand. Please safely dispose of, or recycle, your child seat. Do NOT sell it or pass it on.

  • Page 7: Warnings

    DO NOT use booster seat without the original fabric cover or a replacement cover made by Sunshine Kids. The cover is integral to the safety and performance of the booster seat. DO NOT let a child play with this child seat. It is not a toy.

  • Page 8: Safety Information

    Section 2: Safety Information ALWAYS cover booster seat if vehicle is left in direct sunlight. Fittings can become hot and cover fabric can become faded. ALWAYS keep this user guide in storage slot (in the underside of this child seat) for future reference. ALWAYS make sure that this booster seat does not become trapped in the door of the vehicle or within a folding vehicle passenger seat.

  • Page 9: Assembly And Adjustments

    Cup Holders: Cup holders are located on both sides of seat bottom. Swivel outward to the locked position for use. Swivel inward to the recessed and locked position when not in use. IMPORTANT: Do not step on or put excess weight on cup holder which could cause it to break.

  • Page 10: Assembly And Adjustments

    WARNING: Unsecured objects can become flying hazards and can cause serious injury in an accident. Sunshine Kids always recommends utilizing ISOFAST installation in vehicles equipped with lower anchors. 1) Disengage ISOFAST anchors from storage position. 2) Lay booster seat on its side.

  • Page 11: Isofast Installation

    Section 4: ISOFaST Installation (continued) Disengaging ISOFAST installation: Follow above instructions in reverse. 1) Depress the cam lock lever while pulling child seat away from the vehicle seat back until the ISOFAST straps are extended all the way. 2) Disconnect ISOFAST connectors from vehicle anchors. 3) Pull ISOFAST adjuster straps to recess the ISOFAST connectors into the back of the booster seat bottom for safe storage.

  • Page 12: Securing The Child

    2) Push seat bottom and backrest of booster seat down and back into vehicle seat until there is secure positioning and full contact with the booster seat and vehicle seat bottom and vehicle seat back. (Fig 5) Section 7: Securing the Child 1) Make sure booster seat is properly positioned and installed on vehicle seat as per the instructions in Sections 4 and 5.

  • Page 13: Securing The Child

    Section 7: Securing the Child (continued) Warning: If lap portion and diagonal portion of seatbelt are not positioned correctly, the booster seat is not properly installed. Diagonal portion of seatbelt should lay over the shoulder and NOT touching the neck. (Fig 8) Lap belt position should be forward and as low as possible over child’s pelvis and contacting the upper thigh.

  • Page 14: Care And Maintenance

    Section 9: Care and Maintenance Cleaning the Cover: Read all labels attached to cover for washing instructions. Hand wash cover cold water with mild detergent only. Line dry to prevent shrinkage. Do NOT use hot water, bleach, machine wash or machine dry. Cleaning the Shell: Sponge clean ONLY using warm water and mild soap.

  • Page 15: Warranty

    However, should this product prove faulty within 12 months of its purchase due to a material or manufacturing defect, please return it to the original place of purchase. Sunshine Kids will then, at its sole discretion, either repair it free of charge or replace it with the same or similar product.
  • Page 16 Ma k in g Tra ve l S a f e a n d Ea s y skjp.com Mont (UK) Manual - Rev11-040910 50_Monterey (EngUK) Manual_04-09-10.indd 16 4/9/10 8:39:40 AM...
