Page 2: Table Of Contents
CONTENTS - INTRODUCTION ......................page 1 - ROTOR TECHNICAL DATA ..................page 2 - INTERFACE TECHNICAL DATA ................page 3 - MOUNTING INSTRUCTIONS .................. page 4 1. Where to install the sat dish ..................page 4 2. Rotor’s installation ....................page 4 3. - Page 3 DEAR CUSTOMER, Congratulations! You are now the owner of STAB ROTOR SAT. This is the first sat motor developed by STAB in cooperation with EUTELSAT in order to define the DiSEqC 1.2 standard. ROTOR SAT HH100i - HH120i...
-
Page 4: Rotor Technical Data
- Fine tuning impulse 0,1° - Fine tuning impulse 0,1° - Inclination max 70° - Inclination max 70° - Weight 3 Kg - Weight 3,2 Kg OPTION - Extension for antenna support Rotor Sat HH100i-HH120i instructions manual – page 2... -
Page 5: Interface Technical Data
If the interface drops to the floor, disconnect it immediately from the mains. If after careful examination there is no damage to the box, you can connect it again. Otherwise if there is evidence of damage, please contact your local dealer. Rotor Sat HH100i-HH120i instructions manual – page 3... -
Page 6: Mounting Instructions
With the provided shorter cable connect the REC plug of the interface to the input plug of your receiver (fig. 5 - cable 3). FIG. 2 SOUTH FIG. 3 15 mm FIG. 4 8 mm F-CONNECTOR 3 mm Rotor Sat HH100i-HH120i instructions manual – page 4... -
Page 7: Connections
(from 98.4 to 196.8 feet) Cable type sat coaxial cable sat coaxial cable Inner conductor CU ø=1,02 mm CU ø=1,13 mm Inner conductor resistance 22 ohm/Km 18 ohm/Km Outside conductor resistance 22 ohm/Km 10 ohm/Km Rotor Sat HH100i-HH120i instructions manual – page 5... -
Page 8: Map To Determine The Installation Parameters - Europe Map
3.2 Map to determine the installation parameters - EUROPE MAP L O N G I T U D E Rotor Sat HH100i-HH120i instructions manual – page 6... -
Page 9: North Africa Map
3.2 Map to determine the installation parameters - NORTH AFRICA MAP L O N G I T U D E Rotor Sat HH100i-HH120i instructions manual – page 6a... -
Page 10: Middle East Map
3.2 Map to determine the installation parameters - MIDDLE EAST MAP L O N G I T U D E Rotor Sat HH100i-HH120i instructions manual – page 6b... -
Page 11: South East Asia Map
3.2 Map to determine the installation parameters - SOUTH EAST ASIA MAP L O N G I T U D E Rotor Sat HH100i-HH120i instructions manual – page 6c... -
Page 12: How To Find Out The Elevation Angle Of The Rotor
Example: VENICE - around 6,9° EAST - (fig. 8) ex. VENICE 6,9° Rotor Sat HH100i-HH120i instructions manual – page 7... - Page 13 (fig. 14). Find the best picture and store the new position. Now you can operate the recalculation or find each position, check the best picture and store all positions one by one. Rotor Sat HH100i-HH120i instructions manual – page 8...
- Page 14 FIG. 12 SOUTH WRONG ORBIT IDEAL ORBIT 60° 0° 60° BOLT A FIG. 13 SOUTH WRONG ORBIT IDEAL ORBIT 60° 0° 60° FIG. 14 SOUTH WRONG ORBIT IDEAL ORBIT 60° 0° 60° Rotor Sat HH100i-HH120i instructions manual – page 9...
-
Page 15: Use Of The Remote Control
On the display will flash first the letter “F --” and then the letter “P --”. Finally by using the remote control buttons assign a new number connected to the satellite or restate the previous one. Rotor Sat HH100i-HH120i instructions manual – page 10... -
Page 16: Setting And Storing The East - West Limits
19 ........KOPERNICUS 2 ......28° E 20 ........ARABSAT 2B ........30° E 21 ........TURKSAT 1B ........31° E 22 ........TURKSAT 1C ........42° E 23 ........INTELSAT 601 ........34,5° E 24 ........PAS 1 ..........45° W 25 ........AMOS..........4° 26 ........THOR ..........0,8° W Rotor Sat HH100i-HH120i instructions manual – page 11... -
Page 17: Return To The 0° Position Of The Rotor
12.3 When “0” or “00” flashes on the display then the rotor is at the 0° position. 13 Restoring the satellites tables 13.1. To restore the initial satellites positions you have to send the rotor to the 0° position (par. 12) and operate the recalculation function (par. 11). Rotor Sat HH100i-HH120i instructions manual – page 12... -
Page 18: Problems Solving Guide
The mains fuse has blown. Substitute fuse by authorised personnel. • • 10. The interface does not accept Remote control batteries are mis- Insert batteries. • any instructions. sing or discharged. Substitute batteries. Rotor Sat HH100i-HH120i instructions manual – page 13... -
Page 19: Warranty Conditions
This warranty covers all production defects and working faults, but excludes all damages caused by drops, incorrect use or external oxidations due to incorrect installation. Any repair made by unauthorised personnel will automatically cancel this warranty. Rotor Sat HH100i-HH120i instructions manual – page 14... - Page 20 Via Seminiato, 79 - 44031 AMBROGIO (FERRARA) - ITALY Local time 8.00 to 12.00 a.m. and 1.30 to 5.30 p.m. (MIDDLE EUROPE time) Phone +39-0532-830739 Fax +39-0532-830609 http//: www.stab-italia.com e-mail: sandro@stab-italia.com www.stab-italia.com e-mail: sandro@stab-italia.com PRINT BACK TO THE CONTENTS TABLE Rotor Sat HH100i-HH120i instructions manual – page 15...
