- Page 1 RAZER NOMMO PRO MASTER GUIDE...
- Page 2 The Razer Nommo Pro 2.1 Certified by THX produces power and clarity for an audio experience that’s immersive and lifelike. Experience silk-woven 20mm tweeters for smooth highs, Kevlar® coated 77mm full range drivers for big, tight sound, a dedicated 152mm down-firing subwoofer for powerful bass and Dolby Virtual Surround Sound technology.
-
Page 3: Table Of Contents
4. DEVICE LAYOUT ............................6 5. SETTING UP YOUR RAZER NOMMO PRO ....................7 6. INSTALLING RAZER SYNAPSE FOR YOUR RAZER NOMMO PRO ....Error! Bookmark not defined. 7. USING YOUR RAZER NOMMO PRO ............Error! Bookmark not defined. 8. CONFIGURING YOUR RAZER NOMMO PRO ..................17 9. -
Page 4: Package Contents / System Requirements
1. PACKAGE CONTENTS / SYSTEM REQUIREMENTS PACKAGE CONTENTS ▪ Razer Nommo Pro 2.1 gaming speakers 2x full range speakers 7-inch subwoofer Audio control pod ▪ Optical cable ▪ 3.5mm audio cable ▪ Power cord* ▪ Important Product Information Guide *May vary for specific regions... -
Page 5: Registration / Technical Support
REGISTRATION Register your product online at razerid.razer.com/warranty to get real-time information on your product’s warranty status. If you haven’t registered for a Razer ID yet, register now at razerid.razer.com to get a wide range of Razer benefits. Your product’s serial number can be found here. -
Page 6: Technical Specifications
▪ Optical connection ▪ 3.5mm connection ▪ Control pod featuring power, volume, mute, pairing and source control functions ▪ Razer Chroma™ enabled ™ F O R G A M E R S . B Y G A M E R S . -
Page 7: Device Layout
4. DEVICE LAYOUT 2x full range speakers Left speaker port Speakers to subwoofer cables Right speaker port Audio control pod Audio control pod port Audio source indicator Optical input port Standby button USB Type-B port LED indicator Power button headphone output port Power port Audio source button Power cord... -
Page 8: Setting Up Your Razer Nommo Pro
5. SETTING UP YOUR RAZER NOMMO PRO SETTING UP YOUR RAZER NOMMO PRO 1. Arrange your chair and your Razer Nommo Pro in a triangular position, preferably with all sides at an equal distance. 2. Plug the left and right speakers to their respective speaker ports on the subwoofer. - Page 9 3. Plug the audio control pod to the subwoofer. 4. Plug the power cord* from your subwoofer to an appropriate power source. *Use the appropriate power cord for your region. 5. Fully press the power button on the subwoofer until you hear a click; and then press the standby button on the control pod to disable standby mode.
- Page 10 CONNECTING YOUR RAZER NOMMO PRO TO AUDIO DEVICES VIA 3.5MM AUDIO PORT Plug your portable music player to your Razer Nommo Pro using the included 3.5mm audio cable. VIA OPTICAL PORT Plug your home entertainment system to your Razer Nommo Pro using the included optical cable.
- Page 11 VIA USB PORT Plug your PC or Mac to your Razer Nommo Pro using the USB Type-A to USB Type-B cable. If you are using the Razer Nommo Pro for the first time, you may be required to set up the device as your system’s default playback device.
- Page 12 Step 1: Open your Sound settings from Control Panel > Hardware and Sound > Manage audio devices. You can also right-click your sound icon on the system tray and select Playback devices. Step 2: In the Playback tab, select Razer Nommo Pro from the list and click the Set Default button. FOR MAC USERS Step 1: Open your Sound settings from System Preferences >...
-
Page 13: Using Your Razer Nommo Pro
Step 2: In the Output tab, select Razer Nommo Pro from the list. 6. USING YOUR RAZER NOMMO PRO USING THE STANDBY MODE Press and hold the standby button on the control pod to enable or disable standby mode. CHOOSING A PLAYBACK DEVICE Simply press the audio source button repeatedly until your desired input is selected. - Page 14 While powered on, rotate the volume control to increase or decrease the volume. Press the standby button to mute/unmute the volume. These functions also work on the headphone that is connected to your Razer Nommo Pro. USING THE HEADPHONE OUTPUT PORT While powered on, connect your headphone to the headphone output port of your Razer Nommo Pro.
- Page 15 ™ F O R G A M E R S . B Y G A M E R S .
- Page 16 7. INSTALLING RAZER SOFTWARE FOR YOUR RAZER NOMMO PRO Step 1: Make sure your Razer device is connected to the USB port of your computer. Step 2: Install the Razer software when prompted* or download the installer from razer.com/software. Step 3: Create your Razer ID or log in using an existing account.
- Page 17 8. CONFIGURING YOUR RAZER NOMMO PRO VIA RAZER SOFTWARE DOLBY® VIRTUAL SPEAKER Download the app for your mobile device, Razer Synapse 3 for your PC, or Razer Synapse for your Mac to enable your Razer Nommo Pro’s Dolby Virtual Speaker function.
-
Page 18: Configuring Your Razer Nommo Pro
Operating System. SYNAPSE TAB The Synapse tab is your default tab when you first launch Razer Synapse 3. This tab allows you to navigate the Dashboard subtab. Dashboard The Dashboard subtab is an overview of your Razer Synapse 3 where you can access all your Razer devices, modules, and online services. - Page 19 AUDIO TAB The Audio tab is the main tab for your Razer Nommo Pro. From here, you can customize your device’s settings to unleash its full potential. Changes made under this tab are automatically saved to your system and cloud storage.
- Page 20 The Sound subtab is for modifying your device’s volume, equalizer presets, and sound properties. Profile Profile is a data storage for keeping all your Razer peripheral’s settings. By default, the profile name is based on your system’s name. To add, rename, duplicate, or delete a profile, simply press the...
- Page 21 Lighting The Lighting subtab enables you to modify your Razer device’s light settings. Brightness You can turn off your Razer device’s lighting by toggling the Brightness option or increase/decrease the luminance using the slider. Switch Off Lighting This is a power saving tool which allows you to disable your device’s lighting in response to your system’s display turning off.
- Page 22 If you have other supported Razer Chroma-enabled devices, you can synchronize their quick effects with your Razer device by clicking the Chroma Sync button ( Advanced Effects The Advanced Effects option allows you to choose a Chroma Effect you want to use on your Razer Chroma-enabled peripheral. ™...
- Page 23 The Profiles tab is a convenient way of managing all your profiles and linking them to your games and applications. Devices View which Razer device is using a specific profile using the Devices subtab. To create a new profile within the selected device, simply click the add button ( ). To rename, duplicate, or delete a profile, simply press the Miscellaneous button ( ).
- Page 24 The Linked Games subtab gives you the flexibility to add games, view peripherals that are linked to games, or search for added games. You can also sort games based on alphabetical order, last played, or most played. Added games will still be listed here even if it is not linked to a Razer device. ™...
- Page 25 Razer devices. Reset tab The Reset tab allows you to perform a factory reset on all connected Razer devices with on-board memory. All profiles stored on the selected device’s on-board memory will be erased.
-
Page 26: Safety And Maintenance
9. SAFETY AND MAINTENANCE SAFETY GUIDELINES In order to achieve maximum safety while using your Razer Nommo Pro, we suggest that you adopt the following guidelines: Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the Razer hotline or go to support.razer.com... -
Page 27: Legalese
Product. In no event shall Razer’s liability exceed the retail purchase price of the Product. - Page 28 Razer reserves the right to amend any term at any time without notice. ™ F O R G A M E R S . B Y G A M E R S .
