SCHEMATIC DIAGRAMS

COMPACT COMPONENT SYSTEM

SP-FSX5

Contents

Block diagram

Standard schematic diagrams

Printed circuit boards

FS-X5

CD-ROM No.SML200309

CA-FSX5

2003 VICTOR COMPANY OF JAPAN, LTD.

Area suffix

C -------------------------- Canada

SP-FSX5

2-1

2-3

2-13 to 21

No.MB009SCH

2003/9

Need help?

Do you have a question about the FS-X5 and is the answer not in the manual?

Questions and answers

Summary of Contents for JVC FS-X5

Page 1 SCHEMATIC DIAGRAMS COMPACT COMPONENT SYSTEM FS-X5 CD-ROM No.SML200309 Area suffix C -------------------------- Canada SP-FSX5 CA-FSX5 SP-FSX5 Contents Block diagram Standard schematic diagrams 2-13 to 21 Printed circuit boards No.MB009SCH COPYRIGHT 2003 VICTOR COMPANY OF JAPAN, LTD. 2003/9...
Page 2 In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the parts that are printed over with black such as the resistor ( ), diode ( ) and ICP ( ) or identified by the " " mark nearby are critical for safety.
Page 3 < M E M O >...
Page 4: Block Diagram
Block diagram Function board Micon board LSELO LINE OUT L Q4111,Q4211 J4311 LSERO LINE OUT R Q4311 LINE OUT L/R LINE OUT LINE IN L/R MUTE LMUTE LINEINL J4341 LINEINR DIGITAL OUT IC481 CDDOUT FUNCTION L8101,L8201 & DOLBY E.VOL TUL/TUR TUNER FILTER MODULE...
Page 5 CD door switch board CD DOOR IC451 OUT1 MOTOR CD DOOR CD DOOR OUT2 MOTOR Q4501 DRIVER CLSW,OPSW,TOPIND CD door LED board J4301 Q4102 IC431 Q4101,Q4201 HEADPHONE CD DOOR Q4202 IC481 H.P.MUTE H.P.AMP. BLUE JACK H.P.MUTE FUNCTION INDICATOR & E.VOL Q4301 SMUTE HPSW...
Page 6 Standard schematic diagrams System control / Front / Key / Volume / LED section LS711 LS712 QSW0992-001 QSW0993-001 R7114 R7113 R7202 R7112 R7111 R7115 R7117 CDIND CDIND FMIND FMIND AMIND AMIND R7118 R7116 D7205 LINEIND LINEIND SML-310VT/JK/-X Q7202 R7103 R7102 R7101 KEY1 KEY3...
Page 7 GP1UM271XK IC731 S7301 QSW0651-001Z R7301 1.8K C7301 100/16 QGF1036F1-07 CN731 CN741 QGF1016F2-07W CN661 QGF1036F1-19 R8601 CDCMND R8045 R8602 TUDAOUT CDSTAT Q8611 D8611 D8612 R8603 CDREQ CPH3121-X MA3033/H/ 1N4148WS R8043 FLBK R8604 CDCLK R8042 FLCLK R8605 C8611 R8041 FLSTB 47/16 R8606 CDRST R8040 FLDATA...
Page 8 Function / CD door switch / CD door LED / AHB control section J4301 C4203 QNS0170-001 R4303 150P/50 L4201 C4204 R4203 Q4202 R4206 Q4102 220/10 C4202 2SC3661 2.2k B1026 2SC3661 C4201 R4106 R4201 C4206 R4205 4.7/25 R4204 Q4201 3.3k 2SC3661 B1025 C4104 C4106...
Page 9 CN895 QGA2008C1-26 SMUTE R4201 LOCK VOLCE VOLCLK VOLDATA LMUTE AHB1 CLSW OPSW BUZZER R4101 TOPIND CDDOUT OLOAD MODON C4301 F-SHIFT 4.7/25 THERM R4253 R4265 C4253 220K 10/16 Q4261 5.1K R4254 2SC2812N/6/ R4277 R4255 R4263 C4912 C4269 47/10 0.082/16 C4902 R4266 R4252 R4913 47/16...
Page 10 Digital amplifier section R1204 C1202 C1203 10K 2200P/50 2200P/50 R1217 R1205 C1232 R1236 180P/50 C1208 3.3K R1222 470K R1206 C1223 100K R1203 330P/50 A16V C1205 R1210 R1211 2SD1328/ST/-X 10/16 C1201 R1234 Q1203 R1218 8.2K C1213 4.7/35 1/6.3 R1223 8.2K IC131 10/35 R1229 IC121...
Page 11 R1223 R1308 R1224 IC132 C1308 C1307 STA505-X 22/25 470/25 C1306 0.1/25 L1236 L1201 C1216 R1242 QQR0797-002 C1226 C1227 C1305 0.1/25 C1214 C1238 C1235 C1234 470P/50 0.1/50 1000P/50 1000P/50 0.1/50 0.1/50 1000P/501000P/50 C1228 C1229 C1233 470P/50 C1240 C1239 C1215 L1202 0.1/50 0.1/50 0.1/50 R1243...
Page 12 CD servo control section R601 220k TBAL R602 FBAL C604 0.022 C603 0.022 PICKUP A’SSY OPTIMA-725B1 C601 C602 0.001 0.001 HQ100063 SQCK R257 GCTL KCMND R259 MSTAT KCLK R263 R262 0.1/16 C256 C633 CN001 1.7V 0.022 /OPEN 3.5V /REST 1.7V R635 R608 /RFDET...
Page 13 CN671 TXDO FLASH MICON RXDO /RESET 4.4V SQCK 4.4V KCMND R259 4.2V MSTAT 4.4V KCLK 4.2V 4.4V R263 RXDO CLKSW IC251 R251 MCLK 4.4V 3.7V R262 TXDO MCLK UPD780024AGKB92 3.7V R252 MDATA P25/SCK0 MDATA 0.1/16 4.4V 4.4V R253 VDD1 C256 4.4V AVSS /P.ON...
Page 14 Power supply / FL display section EP904 QNZ0136-001Z Z9102 Z9101 QNG0003-001Z BURST QNG0003-001Z F9101 L9101 QQR1336-001 D9403 0.6V MAINS PLUG 16.7V T9200 QQS0190-001 C9310 100P/50 CP931 ICP-S1.2-X TH901 D9101 QAD0141-8R0 D3SBA60 D9301 R9301 M1FL20U-X R9113 C9306 150K 100/16 ( 1/4W) ( 1/4W) C9304 100P/50...
Page 15 R9313 ( 1/4W) DI751 DI751 QLF0108-001 QLF0108-001 FL TUBE Q9407 UN2111-X 17.7V IC931 BA00ASFP-X D9401 17.7V UDZS13B-X ( FL3.5V) R7502 0.6V R7501 C7509 100/10 R9306 LVA10440-A3 CN751 QGF1036C1-09 CN903 QGF1036C1-09 Q9305 Q9301 UN2111-X 2SC2235/OY/-T VDISP 39.8V 35.1V Q9303 8.4V UN2111-X 6.1V 35.7V Q9302...
Page 16 Printed circuit boards Power board (1/2) Forward side (Power supply board) D9001 L9301 WR901 EP903 CN903 Q9011 D9010 R9078 R9077 D9404 CN931 R9608 R9604 C9309 R9605 Q9604 Q9405 D9304 R9406 Q9406 R9603 R9607 L9202 Q9304 R9601 C9305 C9301 Q9303 C9209 R9303 D9305 R9310...
Page 17 Reverse side (Power supply board) WR901 CN903 L9301 R9712 L9711 R9912 L9911 C9212 L9422 R9425 CN931 C9309 D9304 Q9403 Q9404 Q9401 D9403 Q9601 R9407 C9209 D9305 Q9302 C9301 C9305 Q9305 R9302 D9302 C9307 D9202 CN902 Q9402 HS902 C9210 L9712 R9409 L9412 R9403 L9411...
Page 18 Power board (2/2) Forward side (Function board) WR311 C4922 CN451 R4325 C4322 R4503 C4915 R4502 CN951 Q4322 Q4501 D4321 R4510 R4507 R4508 R4180 R4280 R4509 C4180 C4280 R4214 C4502 Q4211 D4502 D4901 Q4111 R4114 C4912 D4501 C4901 C4154 R4154 R4158 C4231 R4152 C4902...
Page 19 Reverse side (Function board) WR311 R4277 R4919 C4922 R4918 CN951 R4275 CN451 C4273 C4272 C4168 R4271 C4162 R4161 IC492 C4169 R4913 C4163 R4323 IC493 IC451 R4166 R4211 C4251 R4256 R4231 IC491 R4261 R4156 C4262 C4151 C4268 R4163 C4155 R4263 C4256 C4255 IC481 R4155...
Page 20 Micon board (1/2) Forward side (Regulator board) R3024 R3026 R3028 R3030 R2132 Q2102 CN981 Q2101 C3018 D2104 Q2202 Q2201 R2131 R2232 R2231 R3011 R3012 R3022 R9424 R3010 C3017 D3001 C3016 C3015 C1133 C3019 C3020 C1134 R3035 R3023 C1233 R1132 C1234 Q3006 Q1101 R3037...
Page 21 (Digital amplifier board) C3026 C2308 X3001 R2108 C2110 L2102 R2115 L2101 R3004 C2122 R2112 X3002 R2128 IC212 R2106 IC211 C2101 IC232 IC213 R2122 C2113 C2307 R2118 C2108 C2103 C2102 R2215 Q2104 R2216 C2107 Q2103 R2212 R2309 R2301 R2235 R2134 R2208 C2207 R2223 R2211...
Page 22 Micon board (2/2) Forward side CN805 C8702 D8010 C8701 IC871 Q8409 Q8411 D8011 Q8410 R8959 C8007 C8706 R8036 R8018 C8705 R8034 WR803 C8008 R8023 C8009 R8017 R8701 R8020 R8016 C8704 R8019 C8019 R8021 X8701 R8095 R8045 Q8402 C8004 Q8401 R8043 R8042 C8401 R8041...
Page 23 (Front board) D7203 D7204 D7202 R7206 R7203 CN731 D7205 FW701 D7303 D7302 IC731 D7301 CN711 S7105 S7106 (LED board) S7101 R7101 LS712 S7102 S7103 LS711 FW701 R7103 S7104 (Volume board) R7204 (Front board) Q7202 Q7203 Q7204 CN731 R7205 R7308 Q7303 S7106 FW701 D7303...
Page 24 CD servo board Forward side M851 CN651 IC291 C658 R808 CN601 R806 R604 Q631 C821 R632 C606 C605 R805 R603 R291 R292 R293 R809 C801 C802 C812 C611 R803 R804 R807 C608 Q801 R257 R617 C657 C612 R652 C679 R653 R272 C676 R654...
Page 25 < M E M O >...
Page 26 VICTOR COMPANY OF JAPAN, LIMITED AV & MULTIMEDIA COMPANY AUDIO/VIDEO SYSTEMS CATEGORY 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan Printed in Japan (No.MB009SCH)
