8. Functional description /
operating instructions
Please read
carefully so that you are familiar with, and are
able to use, all of the functions of your
Lite-Ex PL 10e. For your own safety and
information please read the instructions on the
following pages carefully!

8.1 Assembly of the Lite-Ex PL 10e

Lamp head
Disc
Fig. 1

8.2 Getting started

The supplied batteries must be inserted to
begin with (outside the Ex-area). In order to be
able to use the flashlight in the Ex-area it must
be ensured that the lamp head and the body of
the flashlight are screwed together tightly. The
flashlight can then be switched on by lightly
rotating the yellow ring switch clockwise.
8
these operating
Thread-forming screw for
plastic 20 x 10 T6
Belt clip
Flashlight body
LED housing
Sealing ring 22.76 x 2
instructions
Ring switch
Sealing ring 22.8 x 1.5
