- Page 1 +55 (14) 3407-1000 MOTOPPAR INDÚSTRIA E COMÉRCIO DE AUTOMATIZADORES LTDA. Av. Dr. Labieno da Costa Machado, 3526 - Distrito Industrial - CEP 17400-000 - Garça - SP - Brasil...
- Page 2 EURUS STEEL 1/2 Technical manual ATENÇÃO: Do not use the product without first read the instruction manual.
-
Page 3: Table Of Contents
INDEX IMPORTANT SAFETY INSTRUCTIONS ..................3 TECHNICAL CHARACTERISTICS ....................4 TOOLS REQUIRED FOR INSTALLATIONS................... 5 ELETRICAL INSTALLATION ......................5 CARE WITH ELETRICAL INSTALLATION ..................6 CARE WITH THE GATE BEFORE OPERATION ................7 INSTALLATION AND FIXING THE OPERATOR ................8 ANALOG LIMIT SWITCH INSTALLATION .................13 MAINTENANCE ..........................16... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Recommendation: For the installation of the equipment, it is important that the specialized installer follow all the instructions quoted in this TECHNICAL MANUAL and in the USER’S MANUAL. With USER’S MANUAL, the installer must present all information, uses and safety items of the equipment to the user. -
Page 5: Technical Characteristics
TECHNICAL CHARACTERISTICS EURUS STEEL 1/2 - EURUS STEEL 1/2 JET FLEX OPERATOR TYPE Sliding Sliding Sliding MODEL Single phase Single phase Single phase RATED VOLTAGE 220 V 127 V 220 V / 127 V NOMINAL 60 Hz 60 Hz 60 Hz... -
Page 6: Tools Required For Installations
TOOLS REQUIRED FOR INSTALLATION Here are some tools needed to install the operator: PLIERS SAWING BOW SOCKET WRENCH SCEW DRIVER FIXED KEY LADDER FRAME DRILL PENCIL SANDER SOLDING MACHINE HAMMER LEVEL TAPE MEASURE ELETRICAL INSTALLATION For electrical installation, the network must contain the following characteristics: -Electric network 127 V or 220 V;... -
Page 7: Care With Eletrical Installation
CARE OF ELECTRICAL INSTALLATION To avoid damage to the wiring, it is important that all conductors are properly attached to the operator. Wiring must be done through conduits, passing internally through the base of the floor, ensuring that none of the wiring conductors are trapped and damaged. -
Page 8: Care With The Gate Before Operation
CARE WITH THE GATE BEFORE OPERATOR Before adapting the machine to the gate, check the slide by following the instructions below: 1º Step: Before installing the operator, check that the gate is in good mechanical condition, i.e. opening and closing properly. Open the gate manually and observe the effort required. -
Page 9: Installation And Fixing The Operator
3º Passo: Make sure that the door leaf does not jam in the opening and closing movement. The slide rail of the door must be perfectly straight, level, periodically clear of any element or grime that hinders the sliding of the rollers throughout its length, as shown below. - Page 10 2nd Step: Base dimensions should be appropriate for the dimensions of the automation. The concrete base should be at a distance of approximately 20 mm from the face of the door leaf. GATE LEAF SIDE VIEW CONCRETE BASE 3rd Step: Observing the conditions, the fully open position the gate and operator close to the face of the door leaf, following the measure of 50 mm between the edge of the leaf and the gate operator.
- Page 11 4th Step: Pre-align the operator to the gate, positioning the rack over the gear and pushing the assembly to the gate. Then mark the fixing holes on the floor or concrete base. MARK THE FIXING HOLES ON THE FLOOR. MARK THE FIXING HOLES ON THE FLOOR.
- Page 12 6th Step: With the operator unlocked, position the rack bar on the gear and aligned with the gate. It is necessary to leave approximately a clearance of 2 mm between the top of the gear tooth and the rack tooth bottom. 2MM GAP 7th Step: Secure the rack to the entire length of the door leaf with solder or screw every 300 or 400 mm.
- Page 13 8th Step: If the door leaf is warped, provide shims to ensure alignment of the rack. There are cases where the rack should pass the length of the sheet. In this case, provide a cross arm brace so do not skip the teeth on the machine departure. CROSS ARM BRACE 9th Step: After fixing the rack, definitely fix the operator on the floor or concrete base, definitely tightening the screws.
-
Page 14: Analog Limit Switch Installation
ANALOG LIMIT SWITCH INSTALLATION 1st Step: With the gate closed, place the magnet holder in the rack, positioned in front with the REED of the operator. This magnet will act as a closing limit switch. GATE OPENING MAGNECT SUPORT RACK MAGNECT SUPORT REED SUPPORT UPPER VIEW... - Page 15 2nd Step: Fully open the gate and place the other magnet holder on the rack, facing the REED operator. This magnet will act as an opening limit switch. ADJUSTMENT OF ADJUSTMENT OF THE SUPPORT THE SUPPORT MAGNET SUPPORT REED SUPPORT UPPER VIEW...
- Page 16 3rd Step: Start the engine and see if the REED’s are shutting off properly. If necessary, invert the connector on the board. After attaching the magnet holders, make the final adjustments by moving them to the right or left, depending on the desired setting. ADJUSTMENT OF ADJUSTMENT OF THE SUPPORT...
-
Page 17: Maintenance
Central: Tamanho: that is available for download at www. Montagem: Carenagem: ppa.com.br and make all connections and Engrenagem: configurations. MAINTENANCE In the table below, we will mention some PROBLEMS - DEFECTS, PROBABLE CAUSES AND CORRECTIONS - which may occur in the operator. Before any maintenance, the total shutdown of the power grid is necessary.
