BV
POTENZA
PREDIAL
WARNING:
Do not operate the equip-
ment without first reading
the instruction manual.
Technical Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the POTENZA PREDIAL SP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PPA POTENZA PREDIAL SP

  • Page 1 POTENZA PREDIAL Technical Manual WARNING: Do not operate the equip- ment without first reading the instruction manual.
  • Page 2: Table Of Contents

    INDEX IMPORTANT SECURITY INSTRUCTIONS ................... 3 TECHNICAL CHARACTERISTICS ....................4 TOOLS REQUIRED FOR INSTALLATION ..................5 ELECTRICAL INSTALLATION ....................... 5 PRECAUTIONS WITH THE GATE BEFORE INSTALLATION ..........7 FIXATION AND INSTALLATION OF THE OPERATOR .............. 7 ANALOGIC LIMIT SWITCH INSTALLATION ................11 MAINTENANCE ..........................13...
  • Page 3: Important Security Instructions

    IMPORTANT SECURITY INSTRUCTIONS Recommendation: For the installation of the equipment, it is important that a PPA specialist installer follow all instructions given in this technical manual and in the user manual. With the user’s manual, the installer must present all the information, uses and safety items of the equipment to the user.
  • Page 4: Technical Characteristics

    *HEIGHT = (Value in MAX. DIMENSION OF in meters -0,15) x 2 meters -0,15) x 2 THE GATE LENGTH = 4,0 m LENGTH = 4,0 m POTENZA PREDIAL SP / POTENZA PREDIAL JET FLEX OPERATOR TYPE OVERHEAD OVERHEAD OVERHEAD MODEL Single Phase...
  • Page 5: Tools Required For Installation

    TOOLS REQUIRED FOR INSTALLATION Here are some tools required to install the automation: PLIERS HACKSAW NUT DRIVER SCREWDRIVER WRENCH LADDER SQUARE DRILLER PENCIL SANDER WELDING MACHINE HAMMER LEVEL MEASURING TAPE ELECTRICAL GRID For electrical installation, the network shall contain the following characteristics: - Electric network 127 V or 220 V;...
  • Page 6 - The cable for the fixed wiring must comply with NBR NM 247-3; - The power conductor of a product for internal use must be a flexible cable 3 x 0.75 mm²; 500 V, according to the norm NBR NM 247-5;...
  • Page 7: Precautions With The Gate Before Installation

    PRECAUTIONS WITH THE GATE BEFORE AUTOMATION Before applying the automation to the gate, some procedures should be taken: -Check the mechanical conditions, whether the balancing is correct and whether the opening and closing are suitable. Remove any equipment not necessary for the operation of the machine, such as locks, ropes, chains, tools, among others;...
  • Page 8 To install the equipment, follow the steps below: Step 1: The gate axis shall be between 100 mm and 300 mm below the central point of the gate leaf. ARTICULATING GATE LEAF HALF OF GATE LEAF GATE AXIS Step 2: Remove the top rail cover and install the securing brackets on the opposite side to the drive nut pin.
  • Page 9 Step 3: Insert the closing stop with the rubber facing the drive nut. Step 4: Insert the opening stop with the rubber facing the drive nut. Step 5: Place back the top cover on the rail.
  • Page 10 Step 6: Position the automation vertically on the door column and weld the mounting brackets on the column, respecting the measurements in the figure below. 270 mm Step 7: Attach the drive lever to the pin of the drive nut of the operator. Step 8: Weld the drive lever on the gate leaf, keeping the distance of 250 mm between the center of the gate shaft and the center of the lever’s turning point.
  • Page 11: Analogic Limit Switch Installation

    Step 9: With the gate closed, maintain a 50 mm tilt on the drive lever, respecting a distance from the center of the turning point of the drive lever and the center of the drive nut pin. PIN CENTER OF THE TRIGGERING TURNING POINT OF THE DRIVE...
  • Page 12 PROTECTION RUBBER Prior to the operation of the operator, it is mandatory to screw the panel cover with 4 x 3.5 x 12 mm screws (available in the kit).
  • Page 13: Maintenance

    Assembly: that is available for download at www. Fairing: Gear: ppa.com.br and make all connections and configurations. MAINTENANCE In the table below, we will mention some PROBLEMS - DEFECTS, PROBABLE CAUSES AND CORRECTIONS - which may occur in your operator. Before any maintenance, it is necessary to completely disconnect the electricity.
  • Page 14 +55 (14) 3407-1000 callcenter@ppa.com.br MOTOPPAR INDÚSTRIA E COMÉRCIO DE AUTOMATIZADORES LTDA. Av. Dr. Labieno da Costa Machado, 3526 - Distrito Industrial - CEP 17400-000 - Garça - SP - Brazil...
