- Page 1 Smart PIR Motion Detector WL-ZSPWBPWBPW-PI11-04 Product Manual Version 1.0 © 2019 Logika Limited...
- Page 2 Introduction Thank you for choosing Logika. Please take a moment to carefully read through the manual to ensure safe and proper installation and use. • Before use, the product must be properly installed as described in this manual by a qualified technician.
-
Page 3: Device Layout
Device Layout Multi-Function Button System Indicator Detection Area Battery Box Front Back Magnet Base... -
Page 4: Specifications
Features • Communication Mode: IEEE 802.15.4 Zigbee. 360° movement detection. • • Battery powered and easy to install. Link with other Zigbee devices for multiple actions from controlling lighting to being part of • your overall security system. Specifications Communication Mode IEEE 802.15.4 (ZigBee/HA1.2) Antenna Type Internal Antenna... -
Page 5: Installation Steps
Installation Steps Hardware Installation There are two options for mounting the Smart PIR Motion Sensor: Option A: Place the device upright on a suitable flat surface. Option B: Mount the device on the ceiling or wall as described below. 1) Mark the position on the ceiling/wall and drill the two holes, inserting the wall plugs. Then screw in the base. - Page 6 Adding the Device to the Smart Home Network Use the Logika Smart Home app to add the device to the Smart Home system. Please refer to the Logika Smart Mobile App user guide which will take you through the process of adding smart devices to the system.
-
Page 7: Device Functions
Device Functions When the device is first powered on, it will normally automatically attempt to connect to the Zigbee Smart Home network. The System Indicator light will flash as it’s searching for the network. If it connects, the light will remain on for 2 seconds and then go out. If this does not happen, you can manually connect via the mobile app and follow the instructions below. - Page 8 User Guide Major Axis: 4.0m Minor Axis: 3.5m Minor Axis: 3.5m Major Axis: 4.0m When the Smart PIR Motion Detector detects any movement, the System Indicator will flash red momentarily and an alert will be sent to the system, notifying of the movement in the mobile app. If the battery voltage is running low, an alert will be sent to the mobile app, to remind the user to replace the battery.
-
Page 9: Troubleshooting
You should now be free to add the device to the local smart network. The issue you are experiencing is not mentioned here. Please contact us at support@logika.nz with your issue and we will do our utmost to help!
