AVTECH
AVTECH's Wireless Sensor Hubs, the WiSH (Wireless
Sensor Hub) and the WiSPR (Wireless Sensor Hub &
Powered Relay), wirelessly transmit sensor data to Room
Alert 32W and legacy model Room Alert 26W from up to 250'
away. Data is transmitted every 150 seconds via a secure,
private protocol on a ZigBee-based 2.4 GHz connection.
Transmissions are encrypted and will not interfere with other
wireless devices in the environment.
The WiSH and WiSPR include an internal temperature sensor,
2 digital ports and 1 switch port, allowing you to monitor a
variety of environmental conditions. You may pair up to 10
WiSH/WiSPRs with your Room Alert 32W or legacy model
Room Alert 26W in order to add up to 40 more sensors
wirelessly.
The WiSPR additionally repeats data from other WiSH/WiSPRs
to the Room Alert 32W or legacy model Room Alert 26W,
allowing you to extend the distance between other WiSH/
WiSPRs and your Room Alert.
Wireless Sensor Hub Package Contents
•
One (1) WiSH or WiSPR
•
One (1) 5V power adapter
•
Two (2) mounting screws
WiSH/WiSPR
Status
LED
Install Your Wireless Sensor Hub
Do not use this sensor in hazardous (classified) locations or life safety applications.
AVTECH Software, Inc.
Wireless Sensor Hubs
Power
Port
Left
Temperature & Environment Monitoring... Made Easy!
Digital
Switch
Ports
Port
Front
AVTECH.com
Advertisement
Table of Contents
Related Manuals for Avtech WiSH
Summary of Contents for Avtech WiSH
- Page 1 Transmissions are encrypted and will not interfere with other wireless devices in the environment. The WiSH and WiSPR include an internal temperature sensor, 2 digital ports and 1 switch port, allowing you to monitor a variety of environmental conditions. You may pair up to 10...
- Page 2 Velcro or simply place it on a flat surface. Step 2: Connect any external sensors. If you purchased external sensors for your WiSH/WiSPR, connect them according to their Installation Notes. Step 3: Connect your Wireless Sensor Hub to a power source.
- Page 3 Room Alert. (The short side of the enclosure should be vertical.) If possible, locate the WiSH Sensors on the top half of the wall to avoid obstacles (people, desks, cabinets, etc.), which reduce the range of the wireless signal. For example, if the ceiling height is 8', the optimum height for the WiSH/WiSPR is 6'.
- Page 4 Provide at least several inches of separation between the antennas and other metal objects. Obstructions With a clear line of sight from Room Alert to the WiSH/WiSPR, the wireless range can be up to 250'. However, each obstacle between Room Alert and the WiSH/WiSPR reduces the effective range of the wireless signal.
- Page 5 Maximum Extendible Length 900' Transmission Frequency 2.4 GHz Maximum Distance from Room Alert 250' Maximum WiSH/WiSPR Per Room Alert Operating Temperature -40º F to 185º F (-40º C to 85º C) Room Alert 32W Compatible Products Legacy model Room Alert 26W AVT-160418.01...
- Page 6 In this example, we’ve chosen WiSH Sensor 1. 3. In Sensor Label, you may leave the default, “WiSH Sensor 1,” or enter something more descriptive of up to 15 characters. You may use the following characters in sensor labels: letters, numbers, spaces, hyphens (-), underscores (_) and periods (.).
- Page 7 Configure Your Wireless Sensor Hub 5. Record this number on the sticker on the bottom of your WiSH/WiSPR so you’ll know which physical device corresponds to what you’re seeing in the interface. AVTECH — WiSH (Power) Sensor works with Room Alert 32W and 26W only.
- Page 8 Configure Your Wireless Sensor Hub Use AVTECH’s GoToMyDevices For The Convenience Of The Cloud Monitor unlimited Room Alert devices and sensors through the cloud from anywhere… anytime! It’s quick, easy and powerful. Enjoy the same look and feel from any device, whether you use a phone, tablet, laptop or desktop computer.
