- Page 1 Led NL Instructions for installation and use - English Lighting Translation of the original instructions in French More documents on: www.zodiac-poolcare.com H0544400_REVB - 2018/10...
- Page 2 • Do not spray insecticide or any other chemical (flammable or non-flammable) in the direction of the appliance, as this may damage the body and cause a fire. • Zodiac® heat pump, filter pump and filter appliances are compatible with the most commonly used types of pool water treatment systems.
-
Page 3: Table Of Contents
• The distribution or modification of this document in any way is prohibited, without prior authorisation from Zodiac®. • Zodiac® is constantly developing its products to improve their quality. The information contained herein may therefore be modified without notice. CONTENTS ❶... -
Page 4: ❶ Specifications En
❶ Specifications 1.1 I Description RGBW colour Pure white 6RGBW 12RGBW 24RGBW 12BW 24BW NL spotlight + protective cover Wrench White & grey cosmetic trims Colour chart 1.2 I Technical specifications NL Spotlight 6RGBW 12RGBW 24RGBW 12BW 24BW Type Colour & white (RGBW) Pure white Power supply 12VAC - 50/60Hz... -
Page 5: I Dimensions And Marking
1.3 I Dimensions and marking : Lens : Body : Power cord NL Spotlight 6RGBW 12RGBW 24RGBW 12BW 24BW Length 118 mm 143 mm 118 mm 143 mm Gasket 9 mm Thread 10.2 mm Body Ø 37 mm Gasket Ø 45 mm Outer Ø... -
Page 6: ❷ Installation
❷ Installation 2.1 I Layout : Pool : Maximum water level : Wall fitting Ø1.5’’ : Wall bushing : Watertight duct Ø2.5 cm minimum : Junction box : Duct to equipment room transformer : NL Spotlight : Spotlight wire... -
Page 7: I Power Connections
• Each spotlight must be installed at a minimum depth of 10 cm below the water level. • The lower cable gland(s) of the junction box for each spotlight must be positioned above the pool's maximum water level. 2.1.1 Preparing the pool before installation •... - Page 8 2.2.1 Connecting to an external controller The NL spotlight is compatible with certain types of remote control systems for pools. It has been in particular specially designed to operate with the Zodiac® AquaLink® TRi, eXO® iQ (LS) or Hydroxinator iQ systems using the iAquaLink™ app.
-
Page 9: ❸Use
❸Use 3.1 I Operating principle LED technology is a lot more powerful, has a much longer lifespan and consumes less energy than incandescent or halogen spotlights. RGBW LEDs provide luminous atmospheres created by combining white, blue, red and green LEDs (9 unchanging colours and 5 coloured light shows). The NL spotlight is compatible with the iAquaLink™... - Page 10 Sequence Colour mode Alpine white Sky blue Cobalt blue Caribbean blue Spring green Emerald green Emerald rose Magenta Violet Slow color splash (all colours alternate for an electric atmosphere) Fast color splash (1,500 colours alternate for an electric atmosphere) America (alternating blue, white and red) Mardi gras (all colours alternate for a lively atmosphere) Disco Tech...
-
Page 11: ❹ Maintenance
❹ Maintenance 4.1 I Winterizing • In the event of the risk of freezing temperatures, the pool must be winterised and the water level must be lowered to below the spotlight(s). • Lower the water level to about 10 cm below the pool's spotlight(s). •... - Page 12 Your retailer Modèle appareil Appliance model Numéro de série Serial number Pour plus d’informations, enregistrement produit et support client : For more information, product registration and customer support: www.zodiac.com ZODIAC® is a registered trademark of Zodiac International, S.A.S.U., used under license.
