connected so that they cannot both be pressed down
at the same time, you can press only 1 pedal at a
time. If you press down the right pedal, the machine
moves to the right, and if you press down the left
pedal, the machine moves to the left. The further you
press a pedal, the faster your speed in that direction.
Note:
Come to a full stop before changing the
direction of the machine; do not abruptly change the
pedal direction. Doing so overstresses the traction
drive line, resulting in premature failure of drive-line
components. Actuate the pedals slowly and smoothly
to avoid potential turf scuffing damage as well as
drive-line component damage.
When operating the machine on hills, ensure that
the drive roller is on the downhill side for adequate
traction. Failure to do so may result in turf damage.
Hitch Assembly
Use the hitch assembly
and to lower/raise the transport wheels.
Seat-Adjustment Lever
You can move the seat forward or backward. Rotate
the seat-adjustment lever
slide the seat forward or backward, then release the
lever.
Armrest-Adjustment Bolts
You can adjust each armrest by turning the respective
adjustment bolt
(Figure
Figure 13
1. Adjustment bolt
Light Switch
Use the light switch to turn the lights on and off
10).
(Figure
10) to tow the machine
(Figure
10) upward and
13).
Hour Meter
The hour meter
machine operation.
Engine Controls
On/Off Switch
The On/Off switch
the machine to start and shut off the engine. This
switch is located on the front of the engine. Rotate the
On/Off switch to the O
engine. Rotate the On/Off switch to the O
to shut off the engine.
1. O
position
FF
Choke Lever
The choke lever
a cold engine. Before pulling the recoil-start handle,
move the choke lever to the
the engine is running, move the choke lever to the
position. Do not use the choke if the engine is
OPEN
already warmed up or if the air temperature is high.
g038454
(Figure
12
(Figure
10) indicates the total hours of
(Figure
14) allows the operator of
position to start and run the
N
Figure 14
2. O
position
N
(Figure
15) is required when starting
position. Once
CLOSED
position
FF
g021103
