Contents 1. Product Introduction ................................1 1.1 Model number and access control ........................1 1.2 Chassis design and dimensions ..........................1 1.3 The mechanical system of the speed gates ....................2 1.4 Electric control system ..............................2 1.5 Operation principle of the speed gates ......................3 1.6 System composition of the product ........................
Figure 1-1 1.2 Chassis design and dimensions The SUS304 stainless steel body looks simple and clean and is anti-corrosion. The SBTL8000 series grants legal access to the authorized persons and restricts illegal access. In case of an emergency, the lock will release to allow fast evacuation and egress.
Mode indicator: This indicator shows the current passing mode status of the channel and guides the passenger to pass the passage orderly and safely. Loudspeaker: The system will trigger the alarm if it detects any unauthorized entry to the lane. SBTL8000 series User Manual...
The alarm signal will not be cancelled until the passenger retreats from the passage. A pedestrian can pass through the lane only after successful verification with a valid card read by the card reader. SBTL8000 series User Manual...
AC110~240V, 50-60Hz Input control signal Output voltage Switching signal DC 24V Time of 20% - 95% Relative humidity 0.8 Sec (adjustable) opening/closing (Non-condensing) Temperature Passage rate Maximum 30/minute -28℃ to 60℃ Infrared sensor Working environment Indoor SBTL8000 series User Manual...
A distance of 100mm between the speed gates turnstile and the wall needs to be reserved for ease of opening the top cover of the machine to perform maintenance and adjustment. The reference figure is shown below: SBTL8000 series User Manual...
100mm. In addition, the conduit outlet is bent to prevent the ingress of water into the conduit. SBTL 8000 series installation holes and cabling positions are as shown in Figure 2-3a: SBTL8000 series User Manual...
Page 9
Figure 2-3a. Use a hammer drill to drill M12 screw holes, then install the screws. Place the swing turnstile according to the size and respective installation position as shown in the figure before installation and fixing. Connect the turnstile to the power supply and SBTL8000 series User Manual...
Page 10
If the test is passed, tighten the screws. It is recommended to mark a warning line on the ground, as shown in Figure 2-3b, after installing the device to remind the pedestrian to stand behind the line when swiping the card. Figure 2-3b SBTL8000 series User Manual...
1. Position adjustment of the swing barrier Type: zero (default) Left limit Right limit 2. Passing mode Opening mode: Two-way swipe (default) Left free, Right swipe Left swipe, Right free Two-way free Left prohibit, Right swipe SBTL8000 series User Manual...
Page 12
Method: Allow the card to be swiped in the channel (default) Do not allow card swiping in the channel 9. Reset counter Reset: Out counter (default) Into the counter 10. Gate closing delay time Time: 0~10 (default 0) 11. Brake unlock mode Mode: Delay unlock (default) SBTL8000 series User Manual...
Page 13
Area selection: Disable during In and out of infrared (default) All infrared zone anti-pinch 18. Memory opening Whether to open: No (default) 19. System working mode Mode: working mode (default) Test mode Restore to factory 20. Version number: Version: V9.0.0 SBTL8000 series User Manual...
When the gate is self-tested, the swing In the process of self-test, there are arm is not in the normal closing obstacles, please remove the obstacles, position! restart the self-test after power-on! SBTL8000 series User Manual...
Caution: The above-mentioned maintenance method of the speed gates, especially the movement and the electric control maintenance, must be carried out by professional personnel. Always remember to cut off the power supply before maintenance and repair. SBTL8000 series User Manual...
