VSS Nederland SUPREME IMAGE VCD-328IR Instruction Manual

VSS Nederland
Video Systems
ITEM NTSC
Image Sensor 1/3" Interline transfer type color CCD (Sony)
Hi-Res
768H x 494V (380K Pixels) 752H x 582V (440K Pixels)
Effective
Pixels
Std-Res
510H x 492V (250K Pixels) 500H x 582V (290K Pixels)
Scanning System 525 Lines 2:1 Interlace
Scanning Frequency 15.734KHz(H), 59.94Hz(V)
Resolution 600TVL(Hi-Res), 350TVL(Std-Res)
Shutter Speed 1/60~1/100,000 sec
S/N Ratio
More than 48dB (AGC Off)
Sync. System
Min. Illumination
Lens Std. f=4mm F2.0 Lens (Option: 2.9mm, 6.0mm)
White Balance
Video Output
Power Supply(*)
High-Res.
Power
Consumption
Standard-Res.
Operating Temp.
Operational Humidity
Dimensions
117mm
(*) Use regulated & specified power supply.
VSS Nederland B.V. - Telfordstraat 11m
VCD-328IR
PAL
625 Lines 2:1 Interlace
15.625KHz(H), 50Hz(V)
1/50~1/100,000 sec
Internal
0Lux (IR LED On)
ATW
VBS 1.0 Vp p (75 Load) -
DC12V ± 10%
±
Max.: 350mA/DC12V (IR-LED On)
Max.: 380mA/DC12V (IR-LED On)
-10 - ~ +50
Max. 90% RH
95mm (Dome: 90)
- 8013 RL Zwolle
INSTRUCTION MANUAL
SUPREME IMAGE
High Resolution DNR Smart IR igh Resolution DNR Smart IR
1/3" Sony Super HAD High/Standard-Resolution Color CCD
600TVL Hi-Resolution, 350TVL Std-Resolution
Built-in 4mm F2.0 Fixed Lens
- Option: 2.9mm, 6.0mm
Auto Switching IR LED control by photocell
- IR LED: 30pcs
Smart IR : It prevents IR saturation
2D-Digital Noise Reduction
Dead Pixel Compensation
3-Axis Gimbal Bracket
Power: DC12V
- Tel.: +31 38 42 89 420 - Fax: +31 38 42 89 429
Video Surveillance Camera
solution DNR mart IR mart IR
C l Color Dome Camera D C
Ø90
