The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user's authority to operate the equipment.
CAUTION : To prevent electric shock and risk of fire hazards:
◆ Do NOT use power sources other than those specified.
◆ Do NOT expose this appliance to rain or moisture.
This installation should be made by a qualified service person and
should conform to all local codes.
1
WDR Digital Sensor Color Dome Camera
Advertisement
Table of Contents
Related Manuals for VSS Nederland VCD-5371PIX
Summary of Contents for VSS Nederland VCD-5371PIX
- Page 1 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
-
Page 2: Table Of Contents
■ Contents How to Use the Camera Features ■ Menu Warnings and Precautions ■ Settings ㆍ PRESETS Components ㆍ EXPOSURE ㆍ WDR Names and Functions of Parts ㆍ WHITE BALANCE ㆍ DAY/NIGHT ■ Lens ㆍ IMAGE ADJ. ■ OSD ㆍ SPECIAL ■... -
Page 3: Features
■ Features Warning ■ The camera requires periodic inspection. High Resolution Color for Crisp, Motion Detection Contact an authorised technician to carry out the inspection. Clear Video Since the camera detects motion without any ㆍProgressive image capture additional external sensor, you can monitor ㆍ690TVL Effective activity more efficient. - Page 4 ■ Precautions Do not drop the camera or protect Never keep the camera pointed Do not install the camera in Do not install or use the camera in an it from physical shocks. directly at strong light. extreme temperature conditions. environment where the humidity is high.
-
Page 5: Components
■ Components Names and Functions of Parts ■ 1. COLOR DOME CAMERA ① ② 2. SCREWS ③ 3. WIRE FOR VBS-EXTRA ④ 4. INSTRUCTION GUIDE WDR Digital Sensor Color Dome Camera WDR Digital Sensor Color Dome Camera... -
Page 6: Names And Functions Of Parts
■ Names and Functions of Parts Names and Functions of Parts ■ LENS : Vari-Focal DC Auto Iris Lens VBS-EXTRA FOR CONNECTING TO LCD ① ③ Please use the supplied wire when connecting to external monitor VBS-EXTRA 3 AXIS BRACKET ④... -
Page 7: Installation
■ Installation 1. Dome Base Mounting - Open the dome cover by loosening 3 screws using special wrench provided. - Mount the base of camera to a sturdy surface using 4 screws (1.5 inch) and 4 premade holes on the base of the dome. 2. -
Page 8: Installation (Adaptor Plate)
■ Installation (Adaptor Plate) How to Use the Camera ■ ■ Menu Adaptor Plate SETUP menu 3.5x25 tapping screw (provided) PRESETS ㆍNORMAL ㆍINDOOR ㆍOUTDOOR Camera Body ㆍLENS ㆍFOCUS ㆍEXPOSURE MODE ㆍAGC EXPOSURE Locking ㆍDNR ㆍHIGHLIGHT Unlocking direction direction ㆍCOLOR ROLL ㆍSENS-UP ㆍMIDDLE ㆍHIGH... -
Page 9: Settings
■ How to Use the Camera SETUP ■ Settings Select the function using Change the status using PRESETS NORMAL the UP or DOWN button. the LEFT or RIGHT button. EXPOSURE.. Settings can be made using the 5 buttons located in the camera. MIDDLE WHITE BALANCE DAY/NIGHT... - Page 10 ■ How to Use the Camera EXPOSURE ● FOCUS : To adjust the DC and VIDEO lens focus SETUP PRESETS NORMAL FOCUS DETECTOR EXPOSURE.. FOCUS METER MIDDLE SET FOCUS REGION.. WHITE BALANCE PREVIOUS PAGE. DAY/NIGHT AUTO.. When the SETUP menu screen is displayed, select‘EXPOSURE’by SET FOCUS REGION using the Up and Down buttons so that the arrow indicates‘EXPOSURE’.
-
Page 11: ㆍ White Balance ㆍ Day/Night ㆍ Image Adj
■ How to Use the Camera WHITE BALANCE ● SENS-UP : When it is night or dark, the camera automatically detects Use the White Balance function to adjust the screen colors. the light level and maintains a clear picture if this mode is activated. 1. - Page 12 ■ How to Use the Camera DAY&NIGHT SETUP Note TIME DELAY • Under the following conditions White Balance may not work properly. PREVIOUS PAGE. In such cases, select the AWC mode. ① When the color temperature of the subject environment has a very high temperature range (e.g.
-
Page 13: Camera Id
■ How to Use the Camera SPECIAL When the SETUP menu screen is displayed, select 'SPECIAL' by using CAMERA ID the Up and Down buttons so that the arrow indicates 'SPECIAL'. CAM-001 SETUP POSITION UP-LEFT PRESETS NORMAL PREVIOUS PAGE. EXPOSURE.. MIDDLE ①... - Page 14 ■ How to Use the Camera ● DZOOM : Digital P/T/Z are used to create a zoom lens effect. IMAGE Zoom Factor (1X to 8X), Pan(±100%, center of image can be moved FREEZE to left and right edges of screen), Tilt(±100%, center of image can FLIP be moved to top and bottom edges of screen) SHARPNESS...
-
Page 15: Privacy Setup
■ How to Use the Camera ㆍWhite : MOTION ZONE Position movement ● SYNC : Two synchronization modes are available, INTERNAL and EXTERNAL LINELOCK. In LINE-LOCK mode, it synchronizes the Green : MOTION ZONE Size enlargement video signal between cameras without a synchronous generator. Red : MOTION ZONE Size reduction The line-lock synchronization is only used in areas of 60Hz (NTSC) ㆍFor MOTION ZONE Confirm, long press SET button... -
Page 16: Troubleshooting
■ Troubleshooting If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an Problem Solution authorized technician. The Motion Detection • Check that MOTION DET in the SPECIAL SETUP Problem Solution is not set to 'OFF'. -
Page 17: Specifications
■ Specifications ITEM NTSC AC24V / DC12V DC12V AC24V / DC12V DC12V Power Consumption 170mA(AC24V)/250mA(DC12V) 160mA 170mA(AC24V)/250mA(DC12V) 160mA Image Sensor PIXIM 1/3" High Sensitivity Digital Sensor Effective Pixels 758(H) x 540(V) Dynamic Range 120dB(Max), 102dB(Typical) Horizontal Resolution 690TVL Effective Min. Illumination 0.1Lux Day &... - Page 18 WDR Digital Sensor Color Dome Camera Instruction Guide WDR Digital Sensor Color Dome Camera Printed in KOREA...
