B U L L E T I N
524
I N S T A L L A T I O N & O P E R A T I O N
PZP Vibratory Level Sensor
M o d e l P Z P
Thank you for purchasing a quality product from Monitor Technologies
LLC. We realize that you do have a choice of vendors when procuring
vibratory level sensors and we sincerely appreciate your business!
This manual contains the information necessary to ensure a safe and
successful installation. Please read and comply with the section on page
6 of this manual pertaining to SAFETY. Doing so will ensure proper oper-
ation of the equipment and the safety of all personnel.
Before discarding shipping container, please inspect it thoroughly and
verify that all parts ordered are accounted for. Sometimes smaller parts
become stuck under carton flaps and other packaging materials.
In the event that information contained herein does not completely sat-
isfy your requirements or answer your questions, you may contact
Technical Support on our website www.monitortech.com, by telephone
at 800-766-6486 (630-365-9403), or by fax at 630-365-5646. If your
sensor ever requires service either in or out of warranty, please contact
us and obtain an RMA number prior to shipping the unit to us.
®
www.monitortech.com
Advertisement
Related Manuals for Monitor PZP
Summary of Contents for Monitor PZP
- Page 1 PZP Vibratory Level Sensor M o d e l P Z P Thank you for purchasing a quality product from Monitor Technologies LLC. We realize that you do have a choice of vendors when procuring vibratory level sensors and we sincerely appreciate your business! This manual contains the information necessary to ensure a safe and successful installation.
- Page 2 Choosing a Location: (See Figure 2) particular attention should be given to assure that the mechan- 1) Material Flow - When selecting a location for the PZP, ical construction of the probe is not damaged by material. choose a point in the vessel where the probe will be out of Probe deflection (bending) as little as 1/16 inch (1.5mm) can...
- Page 3 1/2" NPT fitting (steel is rec- connection point of the extension and to protect the PZP from ommended since minor rethreading is required).
- Page 4 S E T U P Complete set-up of the PZP is accomplished by two functions: sensitivity and fail-safe. Each application can be adjusted inde- pendently for optimum operation. Sensitivity: (See Figure 6) Select sensitivity based on application as shown below.
- Page 5 Hi-Temp/Remote Electronics Probe With Pipe Extension M A I N T E N A N C E The PZP is a maintenance-free product and should be serviced by Monitor Technologies LLC only. If operation appears inap- propriate, refer to the Troubleshooting section of this bulletin. If proper operation is not achievable, consult the factory.
-
Page 6: Specifications
Electromagnetic Compatibility (EMC) Solid Extension: 1" pipe, 304ss, 12' (3.6m) length max. The PZP was tested and found to comply with the standards listed below. (customer specified length) The PZP should not be used in residential or commercial environments. Cable Extension:...
