Planet XGS3-PWR-AC User Manual

1. Introduction

Thank you for purchasing PLANET 400 Watts 100~240V AC
Redundant Power Supply Unit for XGS3-42000R:
XGS3-PWR-AC: 400 Watts AC power supply unit for XGS3-
42000R
3. Install and remove the redundant

power supply unit

Before installation, please be sure to read this user's manual
carefully to complete machine installation. This manual
shows how to quick install and remove the XGS3-PWR-AC
from XGS3-42000R.
The XGS3-42000R equip with one 100~240V AC power
supply unit in its standard package, the XGS3-42000R and
also provide one spare power supply unit slot for option
redundant power supply unit for XGS3-PWR-AC installation.
The XGS3-PWR-AC shall enhance the reliability of XGS3-
42000R.
The XGS3-42000R supports hot-swapping and
power redundancy backup. This secondary AC
power module can direct slid in to the Chassis
Note
while the System is operating.
– 1 –
– 3 –

2. Physical Description

Front panel
Figure 1. Power slots of XGS3-42000R
Rear panel
Power socket for Power socket for
power 2 power 1
Figure 2. Power sockets of XGS3-42000R
Figure 3. Front panel of XGS3-42000R
To install the XGS3-PWR-AC into XGS3-42000R, please
fasten the hand screw clockwise after slide in the XGS3-
PWR-AC to the XGS3-42000R.
Pleaes slid
before plug-in the rear power cord.
Caution
Power socket Power socket
for power 1 for power 2
AF 5541584845454
– 2 –
in the XGS3-PWR-AC module
– 4 –
