Newgrind Rhino RS150 Operator's Manual

Resurfacing machine
Hide thumbs Also See for Rhino RS150:

Advertisement

Table of Contents

Rhino
Resurfacing Machine
Operator's Manual
RS150 1.5HP
RM250 3HP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rhino RS150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Newgrind Rhino RS150

Summary of Contents for Newgrind Rhino RS150

  • Page 1 Rhino Resurfacing Machine Operator’s Manual RS150 1.5HP RM250 3HP...
  • Page 2 For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 3: Specifications

    SPECIFICATIONS RM150 3HP Model RM150 1.5HP Input Power 120V 50/60Hz 380-460V +/- 15% 50/60Hz Amps 14-16A Plug Type 15A 125V 3P4W 30A 480V 3~ (NEMA L16-30P) Disc Diameter 5" / 127mm 133-665 200-900 Disc Speed (RPM) Machine Width 14" / 355mm Weight 150lbs / 69kg 150lbs / 69kg...

  • Page 4: Specific Safety Rules

    SPECIFIC SAFETY RULES ment. Such preventive safety measures reduce the risk of starting the equip- DO NOT let comfort or familiarity with ment accidentally. product (gained from repeated use) 13. Maintain equipment with care. Keep replace strict adherence to equipment tools and accessories in good condition.
  • Page 5 Machine Operation: The Variable Frequency Drive (VFD) is designed to allow the user to operate the equipment on either single phase or three phase power for the 3HP model. The equipment is able to operate on either 50 Hz or 60 Hz frequencies. The DO NOT LIFT THE EQUIPMENT OFF THE VFD will automatically adjust for phase GROUND WHILE STARTING! Doing so can...
  • Page 6 when the desired position is achieved. - Check all fasteners and tighten if necessary. Failure to check for positive engagement could result in damage to the equipment Weekly: or injury to the user as the handle could Inspect handle wires for damage. release unexpectedly when the machine Blow heat...
  • Page 7 For VFD error codes please see attached document LIMITED EQUIPMENT WARRANTY OF SALE Grind Inc. warrants that each new unit manufactured for New Grind Inc. to be free from defects material workmanship in normal use and service for a period of (2) one year from date of shipment to the original retail equip-ment rental...

  • Page 8: Force Majeure

    consequential damages, including loss of ments (collectively the products “) ordered pro ts, whether or not caused by or result- by the Purchaser. These terms and condi- ing from the negligence of seller and/or tions shall govern and apply to the sale of the manufacturer of the product unless Seller’s products to Purchaser, regardless speci cally provided herein.
  • Page 9 obligation on New Grind Inc.'s behalf delivery to the Purchaser. Any claims for unless made in writing and signed by an loss or damage during shipment are to o cer of New Grind Inc. led with carrier by the Purchaser. Seller will not assume responsibility for performance carrier.
  • Page 10 Seller. These terms and conditions may be modi ed, cancelled or rescinded only by a written agreement of both parties execut- ed by their duly authorized agents. New Grind Inc. 103B- 81 Golden Dr Coquitlam BC V3K 6R2 Telephone: 1-888-467-0242 carissa@newgrind.com www.newgrind.com...
  • Page 11 www.newgrind.com...
  • Page 12 SMVector Frequency Inverter Operating Instructions SV01C...

  • Page 13: Troubleshooting And Diagnostics

    Troubleshooting and Diagnostics Fault Messages The messages below show how they will appear on the display when the drive trips. When looking at the Fault History (P500), the . will not appear in the fault message. Fault Cause Remedy High Temperature fault Drive is too hot inside •...
  • Page 14 Troubleshooting and Diagnostics Fault Cause Remedy Digital Input More than one digital input set for the Each setting can only be used once (except Configuration fault (P11... same function settings 0 and 3) P13) Only one digital input configured for MOP One input must be set to MOP Up, another function (Up, Down) must be set to MOP Down...
  • Page 15 Troubleshooting and Diagnostics Fault Cause Remedy Flying Restart fault Controller was unable to synchronize with Check motor / load the motor during restart attempt; (P110 = 5 or 6) Single-Phase fault A mains phase has been lost Check mains voltage Start fault Start command was present when power •...
  • Page 16 AC Technology Corporation • 630 Douglas Street • Uxbridge, MA 01569 • USA +1 (508) 278-9100 SV01C...
