Summary of Contents for Blue Sky Network D411
- Page 1 D411 Installation Guide Version 1.0 Part# 100505...
-
Page 2: Notice
Notice NOTICE This guide is published and copyrighted by Blue Sky Network (BSN). All information and specifications in this document are subject to change without notice. Nothing in this document is intended to create additional or separate warranties or guarantees. -
Page 3: Table Of Contents
Antenna Positioning ............................13 Antenna specifications ........................... 14 Antenna Cable Specifications ........................14 Quick Position Switch............................. 15 Configure ........................16 Parameters ..............................16 SkyRouter Parameter Update Screen ....................... 16 D411 Parameter Explanation ........................16 Appendix ........................17 100505 Page 3 of 19... - Page 4 D411 Installation Guide Table of Contents Appendix A – Revision History ........................17 Appendix B – Power Up Test ......................... 18 Support .......................... 19 100505 Page 4 of 19...
-
Page 5: Introduction
D411 The Blue Sky Network’s D411 is an Iridium and GPS mobile tracking platform with 6-28 VDC input. All data services are managed by the customer through our web-based SkyRouter portal. SkyRouter offers global asset tracking, account management features, such as user authorization, asset settings, messaging and billing information. -
Page 6: Skyrouter
Introduction SKYROUTER The SkyRouter portal ties together Blue Sky Network data solutions in an integrated and user-friendly way. By accessing the SkyRouter Web-site users can do the following: Advanced device tracking on a global, layered map including satellite imagery and standard street maps. -
Page 7: Technical Specifications
Antenna Iridium and GPS combined FEATURES Iridium satellite link: The D411 communicates to SkyRouter using the Iridium network of 66 Low Earth Orbit (LEO) satellites. GPS: The D411 has an integrated GPS receiver – Position reporting interval can be changed in SkyRouter. -
Page 8: Getting Started
Your D411 device must be activated prior to use. By default all Blue Sky Network tracking devices are shipped to customers in an un-activated state. All activation requests must be submitted by the Blue Sky Network SkyRouter Administrator on file. -
Page 9: Installation
Avoid locations that might expose the device to excessive heat or moisture. • Hold the D411 in place and mark the location for mounting screw holes. • Using the markings as a guide, drill mounting holes in those positions. -
Page 10: Power Cable - 100504
• Blue Sky Network is not liable for damage to the D411 caused by an improper installation. • The D411 is designed to operate on 6-28 VDC. The user is responsible for ensuring the voltage supplied to the D411 remains in this voltage range to include transient voltage spikes and load dump voltages. -
Page 12: Power Cable Wiring Diagram
D411 Installation Guide Installation POWER CABLE WIRING DIAGRAM 100505 Page 12 of 19... -
Page 13: Connecting The Antenna - An100107
The GPS antenna connector is labelled ‘GPS’. Make certain that the GPS cable is connected to the GPS output on the antenna to the GPS input on the D411, and that the Iridium cable is connected to the Iridium connector on both the D411 and the antenna. Failure to do so can damage both the antenna and D411. -
Page 14: Antenna Specifications
D411 Installation Guide Installation ANTENNA SPECIFICATIONS BSN AN-100107 - High performance GPS antenna with high-gain, low noise amplifier with an integrated passive Iridium antenna: • Mounting screw with slot for easy through hole stud installations • Low profile, waterproof •... -
Page 15: Quick Position Switch
The D411 comes with an LED wired remote Quick Position switch. The Quick Position switch is already wired into the supplied D411 harness. When the Quick Position mode is enabled this causes the D411 to transmit a series of QPOS (Quick Position) events to SkyRouter. The number of messages and the time between messages can be configured from SkyRouter (see Configure section of this guide for further information.) -
Page 16: Configure
CONFIGURE PARAMETERS Before using your D411 it is recommended that you take time to check and update the parameters on the device to prevent unexpected data usage. By default Blue Sky Network configures the D411 at the factory default setting of 120 second reporting (reports once every 2 minutes.) The D411 system parameters are all managed using the SkyRouter system. -
Page 17: Appendix
D411 Installation Guide Appendix APPENDIX APPENDIX A – REVISION HISTORY Date Revision Description 2014-11-17 Initial version D411 Installation Guide 2017-03-21 Updated the address 100505 Page 17 of 19... -
Page 18: Appendix B – Power Up Test
Power-Up Test: 1. Ensure that the Power Connector is securely connected to the D411 2. Ensure that the GPS and Iridium antenna connectors (at both the D411 and Antenna end) are securely connected to the correct terminals. 3. Supply power to the D411 unit. -
Page 19: Support
(case sensitive). Thank you for choosing Blue Sky Network! Blue Sky Network, 5333 Mission Center Rd. Suite 220, San Diego, CA 92108 Phone: +1 858 551 3894 | Fax: +1 858 225 0794 support@blueskynetwork.com | W: www.blueskynetwork.com...
