Chamberlain MyQ Business CAPXL Quick Start Manual

IF Y OU DO NOT H A V E A CC E S S T O m y Q
PL EA S E CA LL LI F T MA ST E R C US T O ME R C ARE AT
800 -3 23 - 2 27 6 T O S E T UP A N A C C OU N T .
1 . C RE A TE A N EW m y Q
1. On the left navigation bar, click Dashboard, then Facilities tab. Click the Add New
Facility button.
2. Select the Facility type
(Community Faciility or
Commercial Facility).
3. Click Continue.
4. Click Confi rm. (You will not
be able to change facility
type once the facility is
created.)
5. Enter the Facility
information and click Save.
2 . S E LE CT A SU BSC RIP TI ON PL AN
1. Click profile name in upper right corner then select Billing.
2. Select a subscription Plan and Add on features if desired.
3. Enter payment information and select monthly or yearly payments.
3 . AD D CAP X L T O T HE F AC ILIT Y
Open the CAPXL box and locate the CP# on the inside of the enclosure.
1. On the Left navigation bar, select Facility, then click the Device Management.
2. Click on the Add Devices button, Select CAPXL [+], and enter the CP # and name
of the CAPXL.
®
Bu si ne ss™
®
B us ine ss FAC IL ITY
C A P X L
Q U I C K S T A R T
G U I D E
4 . CO NFI GU R E CA PXL SE TT IN GS
1. Enter CAPXL settings such as the welcome message, custom background image,
and register or link with Phone.com for VoIP calling service.
2. Click Save.
5 . CO NFI G U R E DO OR SE T T IN GS
1. Click the Doors tab to edit Door settings including hold open schedule, relay hold
durations, DTMF tone, and Door name.
2. Click the Add Door button to add additional doors (max 4 per CAPXL).
6 . A D D CR E D E NTI AL S
1. On the left navigation bar, click Credentials.
2. Click the Add Credential button to add transmitters, cards, etc. Individually or in
bulk to the Facility.
NOTE: A credential must be associated to a person for it to be active. See Step 8.
