Summary of Contents for Resol FlowSol E
- Page 1 FlowSol ® Manual for the specialised craftsman Installation Operation Commissioning Thank you for buying this RESOL product. Manual Please read this manual carefully to get the best performance from this unit. www.resol.com Please keep this manual safe.
- Page 2 Safety advice Description of symbols Please pay attention to the following safety advice in order to avoid danger and WARNING! Warnings are indicated with a warning triangle! damage to people and property. Î They contain information on how to avoid the danger described.
-
Page 3: Table Of Contents
FlowSol ® The RESOL FlowSol E has been especially designed for using excess power ® produced by a photovoltaic system. The measuring device reliably detects excess current and the integrated controller redirects it to a steplessly variable electric heater for heating a water store. -
Page 4: Overview
Overview Technical data Circulating pump: • Integrated high-efficiency pump and DeltaTherm E controller ® Wilo Yonos PARA 15/7.0-PWM2 (heating water) • Integrated electric heater of up to 3 kW, steplessly variable and grid compliant (power consumption of the pump: 3 … 45 W) •... -
Page 5: System Overview
System overview Energy meter Controller Power unit Measuring unit VBus ® VBus ® Load Hydraulics Store PV generator PV inverter... -
Page 6: Mounting
Mounting Electrical connection WARNING! Electric shock! Wall mounting Upon opening the housing, live parts are exposed! Î Always disconnect the device from power supply before opening the housing! ATTENTION! ESD damage! Electrostatic discharge can lead to damage to electronic com- ponents! Î... -
Page 7: Hydraulic Connection Buffer Store (Heating Water)
Î Put the cover on the plug. Hydraulic connection buffer store (heating water) The cover also serves as a strain relief. Flow Î Connect the plug to the connector attached to the base plate. Further loads such as washing machines must not be connected in paralel to the station. -
Page 8: Commissioning
Commissioning Venting the FlowSol ® When the hydraulic system is filled and ready for operation, connect the power Î Fill the system with water. unit to the mains. The controller has to be connected to the power unit (pre-con- nected) and to the measuring unit by means of the VBus ®... -
Page 9: Non-Return Valve
Non-return valve Troubleshooting The non-return valve is located above the pump in the return line. If an error has occurred, it will be indicated on the controller screen. Please pay attention to the controller manual! Maintenance Fault condition Possible cause Elimination In order to remove limescale, we recommend cleaning the heating element and the Pump noise... -
Page 10: List Of Spare Parts
List of spare parts Pos. Designation Spare part number Wall plate DeltaTherm ® E Power (incl. thermal cut-out) 11209970 Cross piece with safety valve HW 11209948 Temperature sensor Store (S2) 11211397 Non-return valve see cross piece Circulating pump HW 11209952 Return ball valve (RE) 11209953 DeltaTherm... - Page 12 - they only represent use outside the copyright requires the approval of RESOL – Elektronische Rege- some examples. They can only be used at your own risk. No liability is assumed for lungen GmbH.
