- Page 1 Adeunis RF TWIMO RF Modules Starter Kit User Guide 208474A_UG_Starter kit_TWIMO_V1.0...
-
Page 2: Table Of Contents
Table of contents Preliminary information Precautions Product overview Kit content Getting around the TWIMO Starter Kit 3.1. Extension board overview 3.2. Open4 platform overview Before starting 4.1. Connect the extension board to the Open4 platform 4.2. Turn on the system Running the evaluation 5.1. - Page 3 English 208474A_UG_Starter kit_TWIMO_V1.0...
-
Page 4: Preliminary Information
This document and any copy or extract of it, can’t be disclosed without Adeunis-rf’s formal agreement. This document is subject to change without notice. All trademarks mentioned in this guide are the property of their respective owners. ADEUNIS RF 283 rue Louis Néel 38920 Crolles... -
Page 5: Product Overview
This Starter Kit is designed to help the user to achieve his objectives as quickly as possible. The new generation of Adeunis RF starter kit consists on the addition of an Adeunis extension board (embedding the TWIMO module) and a Raisonance Open4 platfom. -
Page 6: Extension Board Overview
LCD touch screen : allows to navigate into the menu Joystick : allows to navigate into the menu Adeunis RF extension board USB connector : power supply & PC connection All needed and usefull information can be found on the Raisonance website (www.raisonance.com). User... -
Page 7: Before Starting
Before starting 4.1. Connect the extension board to the Open4 platform The extension board must be connected to the Open4 platform. Procedure : • Unscrew the bottom case of the Open 4 by removing the four screws. • Remove the bottom cover. •... -
Page 8: Running The Evaluation
Note concerning the power supply : in the case of evaluating an Adeunis RF module functionning at 500mW, you may have to use an external power supply to run the maximum module power for more than an hour. The extension board is equiped with an external power supply socket (Jack 3.5). -
Page 9: Home Screen
Run the evaluation USB mode Set-up the module 5.3. Select the type of module Press the «change» icon. A list of the available Adeunis RF extension board appears. Select the proper board and press the «validate» icon. 5.4. Modify the configuration 5.4.1 RF Power... -
Page 10: 5.4.2 Rf Data Rate
5.4.2 RF data rate Following the RF Power mode, the RF Data rate must be selected. Choose the RF Data rate : • TWIMO MP & HP : 10kbps, 38.4kbps, 57.6kbps Press the «validate» icon 5.4.3 Channel (frequency) Following the RF Data rate, the Channel must be selected. Choose the channel Press the «validate»... -
Page 11: Test Mode
This mode allows a conventional «send/receive» function. The «TX» sends a frame and the «RX» receive it. Each «RX» and «TX» LCD show the frame structure, allowing to check the proper transmission. This mode is used to test the range covered by the Adeunis RF TWIMO modules. •... -
Page 12: Received Level» Mode
RX mode First column : RX counter Second column : sent frame counter (= received frames counter) RXcnt : number of frame received FrameLost : lost frame counter The PER can deducted by : FrameLost / TXcnt 6.2. «Received level» mode The «received level mode allows to run a permanent test between : •... -
Page 13: Scanner» Mode
RX mode First column : • Frame emitted by a Starter kit : number of frame received (when receiving a frame from a Starter kit, the Starter kit -sets in Rx mode- answers). • Frame emitted by a TWIMO module : the screen displays «Rx level» and the Starter kit does not answer. -
Page 14: Usb Mode
RSSI -88dBm : latest RSSI level measured Max -52dBm : higher RSSI level seen by the Starter kit Average -87dBm : average RSSI level in the selected channel Min -98dBm : lower RSSI level seen by the Starter kit On the right side a bargraph shows the three RSSi levels (max, Average, Min) as well as a real time measured RSSI (yellow pod). -
Page 15: Verify Or Evaluate An Installation
Verify or Evaluate an installation It’s possible and even recommended to use the TWIMO Starter kit to verify or evaluate an existing installation. 7.1. Method # 1 First step : • Set the TWIMO Starter kit in «Scanner» mode. • Shut down all existing transmitters. -
Page 16: Declaration Of Conformity (Ce0081)
(Statement of opinion from a notify body N°102158-604317-1/2) • Conformity has been evaluated with ARF7580AA module integrated on ADEUNIS RF TWIMO Extension Pack (ref ARF7865AA ) and with ARF7581AA module integrated on ADEUNIS RF TWIMO Extension Pack (ref ARF7864AA). •...
