Summary of Contents for Adeunis RF Narrow Band NB868-500mW
- Page 1 NB868-500mW RF Module User guide version V2.2.5 Software version V2.3.0 ADEUNIS RF 283 rue Louis Néel - Parc Technologique Pré Roux 38920 CROLLES - France Tel. : +33 (0)4 76 92 07 77 - Fax : +33 (0)4 76 04 80 87 www.adeunis-rf.com...
-
Page 2: Information
Batch number Disclaimer This document and the use of any information contained therein, is subject to the acceptance of the Adeunis RF terms and conditions. They can be downloaded from www.adeunis-rf.com. Adeunis RF makes no warranties based on the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications and product descriptions at any time without notice. -
Page 3: Narrow Band Modules Regulatory Considerations
Rec 70-03 (describing in annex 1, frequency bands, g, g1, g2, g3 or g4) . In certain cases, you may need to notify the final equipment to European administrations. Adeunis RF can assist you on regulatory aspects Crolles, January 6th, 2012 VINCENT Hervé... -
Page 4: Table Of Contents
Disposal of waste by users in private households within the European Union EINLEITUNG Hinweise zum Umweltschutz Warnhinweise Entsorgung der Abfälle von Betreibern in Privathaushalten innerhalb der Europäischen Union Modules overview 1.1. Adeunis RF concept 1.2. Module functionality 1.3. Module range 1.4. NB868-500mW Technical specifications Main characterictics 2.1. - Page 5 NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 3.4. RSSI 3.4.1 RSSI continuous 3.4.2 Frame RSSI 3.5. Scan Free function Product Configuration - Command Mode 4.1. Command mode input/output 4.2. AT Commandes 4.3. Description of registers 4.4.
-
Page 6: Introduction
Under no circumstances can the manufac- turer, or the distributor of an ADEUNIS RF program, be held liable for any damage caused by the use of the aforesaid program. Program names, as well as all copyright relating to programs, are the exclusive property of ADEUNIS RF. -
Page 7: Disposal Of Waste By Users In Private Households Within The European Union
EINLEITUNG Alle Rechte an diesem Handbuch sind das alleinige Eigentum der ADEUNIS RF. Alle Rechte sind vorbehalten. Jede (ohne die schriftliche Geneh- migung des Eigentümers erfolgende) Wiedergabe dieses Handbuches durch Druck, Kopie, Aufzeichnung oder jedwedes andere Mittel sowie die (vollständige oder teilweise) Übersetzung in jede andere Sprache einschließlich aller Programmiersprachen durch Verwendung welcher elektris-... -
Page 8: Warnhinweise
NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 Warnhinweise Gültig für die Relaisempfänger mit den Artikelnummern : ARF7763BA Lesen Sie die Anleitungen dieses Handbuches. Die durch dieses Produkt gewährte Sicherheit kann nur bei einer Anwendung entsprechend dem vorgesehenen Einsatzzweck gewährleistet werden. -
Page 9: Modules Overview
NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 1. Modules overview 1.1. Adeunis RF concept The idea is to provide the user with a module which is ready for sending and receiving data over a radio link thus enabling the user to focus on the development of its application. -
Page 10: Main Characterictics
NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 Dimensions 32x 16 x 2.8mm (4mm with shield) 2. Main characterictics 2.1. Form factor and footprint Footprint of the module Note : dxf and gerber files are available on request 2.2. -
Page 11: Pinout Of The Module
NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 2.2.1 Pinout of the module 2.2.2 Pin configuration Pin module Pin name I/O (1) Description Ground (2) Ground (2) RF output ANTENNA Must be adapted with 50 ohms matching Supply voltage (2) Ground (2) Standby mode activation/deactivation... -
Page 12: Electrical & Radio Characteristics
NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 Should be connect to GND to get best RF sensitivity 2.3. Electrical & Radio characteristics 2.3.1 Absolute maximum ratings Parameter Unit Conditions Supply voltage -0.3 Storage Temperature range -125 °C Input RF level... -
Page 13: Radio Characteristics
Up to 10km in open field Duty cycle Depending on the use * spectral occupancy 2.4kbps being slightly Spacing 12.5kHz* 25kHz 50kHz 75kHz greater than 12.5KHz, Adeunis RF advocates use N-2/N+2 Rejection on adjacent channel 46dBc 50dBc 39dBc 39dBc (N-1/N+1) Alternate channel... -
Page 14: Usage Up To 25Mw: Maximum Number Of Channels
Depending on the frequency used and the See CEPT Recommendation 70-03 for more information channel * spectral occupancy 2.4kbps being slightly greater than Spacing 12.5kHz* 25kHz 50kHz 75kHz 12.5KHz, Adeunis RF advocates use N-2/N+2 Rejection on adjacent 46dBc 50dBc 39dBc 39dBc channel (N-1/N+1) Alternate channel 46dBc... -
Page 15: Power Supply
2.5. Antenna ADEUNIS RF will assist you in your choice of antennas so as to optimize the performance of your products. Feel free to contact us for more information. We suggest the schematic below : •... -
Page 16: Communication Mode
NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 • For a quick set-up, we recommend not to get the self, to install the capacitor to 27 pF (or replace it by a short circuit or a 0 ohm resistor) and solder a 8.6 cm length wire behind the capacitor. -
Page 17: Transmission Integrity Control
NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 three attempts. Importante note : the addressed mode must be activated in order to use the secured mode. 3.2.1.4 Transmission integrity control The RF protocol includes a 16 bits CRC. Each data extracted from an RF packet with an invalid CRC is silently discarded by the module state machine. -
Page 18: Addressing
NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 An RF transmission can starts according following evens : • either a timeout (S217) • or a quantity of data in the buffer memory (S218) The first of these two limits reached triggers transmission start. When the number of octets in the buffer memory reaches the threshold of register S218 before the timeout of register S217, it is triggering on data. -
Page 19: Rssi Continuous
NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 reception of the frames from a distant product. The terminals are -127dBm for the lower limit and -20dBm for the upper limit The RSSI is deactivated (by default) by positioning register S230 at: 0 3.4.1 RSSI continuous The RSSI is coded on one octet in absolute values of the channel level value in dBm and transmitted to the UART. -
Page 20: Product Configuration - Command Mode
NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 E.g.: ATT03 529 60 -> Scan of channel 529 for 1 minute. The result returned has the following form: C529=-087/-096/-101dBm<cr><lf>; i.e. in order: RSSI min. RSSI mean/RSSI max. measured over this period. 4. -
Page 21: Description Of Registers
NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 Command Description Reply ATT02 Starts the Scan Free mode «Returns for each channel, its number and RSSI value associated : Cxxx=-090dBm<cr><lf> ATT03 <c> <t> Scan of channel «c», during a «t» period , with : The command returns three values of RSSI: mini, medium and maximum. - Page 22 NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 Register Content Default value Comments Preamble duration S204 0 : Automatic preamble UART data rate: 0 : Autobaud 1 : 2.4kbps See note 1 2 : 4.8kbps The other parameters of the serial interface are : 3 : 9.6 kbps S210...
- Page 23 NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 Register Content Default value Comments RF radiated power: 0 : 27 dbm 1 : 25 dbm 2 : 23 dbm S231 3 : 20 dbm 4 : 17 dbm 5 : 14 dbm 6 : 10 dbm Low Power modes :...
-
Page 24: Configuration Coherency
NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 • either a timeout (S217) • or a quantity of data in the buffer memory (S218) The first of these two limits reached triggers transmission start. When the number of octets in the buffer memory reaches the threshold of register S218 before the timeout of register S217, it is triggering on data. -
Page 25: Soldering Curve
NARROW BAND - NB868 - User guide version V2.2.5 - Software version V2.3.0 Considering the components on the module, we can define the module as a level 3 component, whose floor life under 60% max RH is 168 hours. Having in mind that module to mother board assembly delay is not under control, same for temporary storage atmosphere, the best solution is to dry the module after test and put it in reels and then pack them in MBB bags.
