P900464-01
INSTALLER: Leave this manual with the appliance.
DANGER
CARBON MONOXIDE WARNING
• This appliance can produce carbon
monoxide which has no odor.
• Using it in an enclosed space can kill
you.
• Never use this appliance in an en-
closed space such as a camper, tent,
car or home.
WARNING: Do not store gasoline or other flammable vapors and liquids in the vicinity of this or any other appli-
ance. An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing prop-
erty damage, personal injury, or loss of life
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appli-
ance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
PFS
®
US
Report No. F10-087
WHEN USED AS AN OUTDOOR APPLIANCE
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
• Shut off gas to the appliance.
• Extinguish any open flame.
• If odor continues, leave the area immediately.
• After leaving the area, call your gas supplier or fire department.
Failure to follow these instructions could result in fire or explosion, which
could cause property damage, personal injury, or death.
WARNING: For Outdoor Use Only.
Installation and service must be performed by a qualified installer, service
agency, or the gas supplier.
WHEN USED AS INDOOR VENTED APPLIANCE
Installation and Operation Instructions
Vented Gas Log and Burner Set
Models
MNF24ONE
MNF24OPE
For use with log sets
LMF24GTA/B
LMF30GTA/B
LMF36GTA/B
CONSUMER: Retain this manual for future reference.
MNF30ONE
MNF30OPE
LMF24MOA/B
LMF30MOA/B
LMF36MOA/B
Advertisement
Table of Contents
Related Manuals for Superior Fireplaces MNF24ONE
Summary of Contents for Superior Fireplaces MNF24ONE
- Page 1 Installation and Operation Instructions Vented Gas Log and Burner Set Models MNF24ONE MNF24OPE MNF30ONE MNF30OPE P/N 900464-01 Rev. C 11/2019 For use with log sets LMF24GTA/B LMF24MOA/B ® LMF30GTA/B LMF30MOA/B LMF36GTA/B LMF36MOA/B P900464-01 Report No. F10-087 INSTALLER: Leave this manual with the appliance.
-
Page 2: Table Of Contents
Thank you for your purchase. We appreciate your TABLE OF CONTENTS business! Safety ��������������������������������������������������������������������������������������������� 2 Please carefully read and follow all instructions in this manual� Pay Product Identification ��������������������������������������������������������������������� 4 special attention to all warnings and safety information. Local Codes ����������������������������������������������������������������������������������� 4 Following these safety, care, and operation instructions will help Unpacking ��������������������������������������������������������������������������������������... - Page 3 SAFETY Continued You must operate this appliance with the fireplace WARNING: Vent-free products are prohibited for screen and hood in place. Make sure fireplace screen bedroom and bathroom installation in the Common- and hood are in place before running appliance. The wealth of Massachusetts.
-
Page 4: Product Identification
SAFETY Continued • The flexible gas line connector used shall not exceed 36 inches (92 centimeters) in length� 6� If fireplace has glass doors, never operate this appliance with • The individual manual shut-off must be a T-handle type valve� glass doors closed�... -
Page 5: Installation
INSTALLATION CHECK GAS TYPE WARNING: DO NOT INSTALL IN SLEEPING Use the correct type of gas (natural or propane/LP)� If your gas supply ROOM OF MOBILE HOMES. is not the correct gas type, do not install appliance� Call dealer where you bought appliance for proper type appliance�... - Page 6 INSTALLATION Continued Carefully follow the instructions below� This will ensure safe instal- Noncombustible Requirements for Safe Installation lation into a masonry, UL127-listed manufactured fireplace or listed Material Distance (A) outdoor firebox� Minimum Clearances For Side Combustible Material, Side Wall and 12"...
-
Page 7: Operation
INSTALLATION Continued MANTEL CLEARANCES NOTICE: Surface temperatures of adjacent walls and In addition to meeting noncombustible material clearances, you mantels become hot during operation. Walls and man- must also meet required clearances between fireplace opening and tels above the firebox may become hot to the touch. mantel shelf�... - Page 8 Installation Continued For Massachusetts Residents Only: Installation of this gas log set Chimney Height Minimum Permanent Flue Opening as a vented indoor appliance in the Commonwealth of Massachusetts 6' to 15' 39 sq� inches requires the damper be permanently removed or welded in the fully open position�...
- Page 9 Installation Continued Masonry Screw • sediment trap • tee joint • pipe wrench • approved flexible gas line with gas connector (if allowed by local codes) (not provided * An equipment shutoff valve with 1/8" NPT tap is an acceptable alternative to test gauge connection�...
- Page 10 INSTALLATION Continued Test Pressures In Excess Of 1/2 PSIG (3.5 kPa) Equipment Shutoff Valve PROPANE/LP 1� Disconnect appliance with its appliance main gas valve (control With 1/8" NPT Tap* From External Regulator valve) and equipment shutoff valve from gas supply piping system� Approved Flexible Gas (11"...
- Page 11 2� Install supplied A23/12V battery following positive and negative directions� 3� Replace battery cover onto remote control� MF SERIES BURNER SYSTEM LOG COMPATIBILITY CHART Burner System Model Refractory Concrete Logs For Use With This Burner System LMF24GTA/B MNF24ONE LMF30GTA/B MNF24OPE LMF24MOA/B LMF30MOA/B MNF30ONE LMF36GTA/B MNF30OPE...
- Page 12 Installation Continued Round Tube 2� Find the back left log (LMF24GTA/B or LMF24MOA/B models: D-060, Burner LMF30GTA/B or LMF30MOA/B models: D-018, LMF36GTA/B or LMF36MOA/B models: D-026)� See Figures 17, 17A, and 17B� Figure 17A shows how the log must fit against the end of the burner� Figure 17B shows how the notch in log fits against the vertical portion of the burner tube�...
- Page 13 Installation Continued 3� Find the front left log (LMF24GTA/B or LMF24MOA/B models: D-059, 4� Find the charred log (D-020)� See Figures 19, 19A, and 19B� The LMF30GTA/B or LMF30MOA/B models: D-017, LMF36GTA/B or log has a slot in the bottom that fits over the square grate and LMF36MOA/B models: D-025)�...
- Page 14 Installation Continued Square Peg Right Split Crossover 5� Find the middle split log (LMF24GTA/B or LMF24MOA/B mod- Log (D-022) els: D-063, LMF30GTA/B or LMF30MOA/B models: D-021, LMF36GTA/B or LMF36MOA/B models: D-028)� See Figures 20 and 20A� The split side of the log faces forward� The log has a notch that fits around the burner tube on the right side�...
- Page 15 Installation OPERATION Continued FOR YOUR SAFETY Back Top Log (D-062, READ BEFORE LIGHTING D-023 or D-029) Right Split Crossover WARNING: If you do not follow these instructions Log (D-022) exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A.
-
Page 16: Inspecting Burners
OPERATION INSPECTING BURNERS Continued Check burner flame patterns often� IGNITER ASSEMBLY The igniter assembly is factory preset for proper ignition of the burner� Incoming Alterations may have occurred during shipping and handling� Call a Gas Line Equipment qualified service person to readjust the igniter assembly if necessary� Shutoff Valve The igniter should be positioned as shown in Figure 28�... -
Page 17: Cleaning And Maintenance
We also recommend that you keep the burner tube clean and free of MNF24ONE AND MNF30ONE dust and dirt� To clean these parts we recommend using compressed • Rating (Variable): 29,000/40,000 Btu/Hr air no greater than 30 PSI�... -
Page 18: Wiring Diagram
WIRING DIAGRAM Green Orange White Orange Igniter HI/LO Pilot Solenoid Black AF-4000 AF-5000MOD Main Control Module AF-4000B/P Black Orange Brown Black Black (GND) Brown Brown These wires are not used on this application Opti Black CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous opera- tion. -
Page 19: Troubleshooting
TROUBLESHOOTING WARNING: Turn off appliance and let cool before servicing. Only a qualified service person should service and repair appliance. NOTE: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY When ''ON'' button on remote control is 1�... - Page 20 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Delayed ignition of burner 1� Manifold pressure is too low 1� Contact local natural or propane/LP gas company 2� Burner orifice clogged 2� Clean burner (see Cleaning and Main- tenance, Page 17) or replace burner orifice(s) Burner backfiring during combustion 1�...
- Page 21 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Leave the building immediately •...
-
Page 22: Replacement Parts
REPLACEMENT PARTS See Pages 23-25 for a complete replacement parts list� Use only SERVICE HINTS parts supplied from the manufacturer� When Gas Pressure Is Too Low • pilot will not stay lit Normally, all parts should be ordered through your IHP distributor or dealer�... -
Page 23: Parts
PARTS MODELS MNF24ONE, MNF24OPE, MNF30ONE AND MNF30OPE WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifi- cally approved with this heater may result in property damage or personal injury. Cat. No. - Page 24 PARTS MNF24ONE, MNF24OPE, MNF30ONE AND MNF30OPE This list contains replaceable parts used in your appliance� When ordering parts, follow the instructions listed under Replacement Parts on Page 22 of this manual� WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not ap- proved by IHP.
- Page 25 PARTS LOG SET MODELS LMF24GTA/B, LMF30GTA/B AND LMF36GTA/B This list contains replaceable parts used in your appliance� When ordering parts, follow the instructions listed under Replacement Parts on Page 22 of this manual� LMF24MOA/B LMF30MOA/B LMF36MOA/B CAT. NO. Log Id. # CAT.
- Page 26 PARTS LOG SET MODELS LMF24MOA/B, LMF30MOA/B, AND LMF36MOA/B This list contains replaceable parts used in your appliance� When ordering parts, follow the instructions listed under Replacement Parts on Page 22 of this manual� LMF24MOA/B LMF30MOA/B LMF36MOA/B CAT. NO. LOG ID NO. CAT.
-
Page 27: Warranty
Innovative Hearth Products Superior Brand Gas Log Set ® Limited Three Year Warranty THE WARRANTY Innovative Hearth Products Limited Three Year Warranty ("IHP") warrants your Superior brand Gas Log Set ("Product") to be free from defects in materials and workmanship ®... - Page 28 SuperiorFireplaces.us.com Record the following important information about your appliance: Appliance model number Appliance serial number Date appliance was Installed Type of gas appliance uses Dealer name Innovative Hearth Products (IHP) reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
