- Page 1 PMXU43BT PMXU63BT PMXU83BT PMXU43BT - PMXU63BT - PMXU83BT Wireless BT Streaming Studio Mixer DJ Controller Audio Mixing Console System...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions 1. Introduction General mixing console functions Before you get started 2. Control Elements and Connectors Channel Input Main Control 3. Installation Mains connection Audio connections 4. Speci cations www.PyleUSA.com... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. Terminals marked with this symbol 5. Do not use this apparatus near water. carry electrical current of su cient 6. Clean only with dry cloth. magnitude to constitute risk of electric 7. -
Page 4: Introduction
1. INTRODUCTION Caution! We should like to draw your attention to the fact that extreme volumes may damage your hearing and/or your headphones or loudspeakers. Turn the MAIN MIX control and PHONES control in the main section fully counter-clockwise before you switch on the unit. Always be careful to set appropriate volume levels. -
Page 5: Control Elements And Connectors
2. CONTROL ELEMENTS AND CONNECTORS This chapter describes the various control elements of your mixing console. All controls, switches and connectors will be discussed in detail. 8 CHANNEL 6 CHANNEL 4 CHANNEL 2.1 CHANNEL INPUT 1. [MIC/LINE] Mono Input: Connect the microphone, musical instrument or audio device (CD player and so on) to the device. -
Page 6: Main Control
LINE Each mono input also features a balanced line input on a 1/4" connector. Unbalanced devices (mono jacks) can also be connected to these inputs. • Please remember that you can only use either the microphone or the line input of a channel at any one time. -
Page 7: Installation
7. Channel input socket (stereo): 8CH mixer with two group of input socket, 4CH and 6CH mixers with one group of input socket. If connected only to L (MONO) socket, the mixer will send out the same mono signal to L and R sockets. 8. -
Page 8: Audio Connections
3.2 Audio Connections You will need a large number of cables for di erent applications. The illustrations below show how the connectors should be wired. Be sure to use only high-grade cables. Please use commercial RCA cables to connect the 2-track inputs and outputs. You can, of course, also connect unbalanced devices to the balanced inputs/outputs. -
Page 9: Speci Cations
GENERAL SPECIFICATIONS MODEL PMXU43BT PMXU63BT PMXU83BT 4 CHANNEL 6 CHANNEL 8 CHANNEL Input Channels Mono: MIC/LINE Stereo LINE: USB sound card TAPE/CD Input Output Channels STEREO OUT PHONES RETURN STEREO SEND 26dB Input Channel Function HIGH: Gain: +15dB/-15dB, Frequency, 12kHz shelving MID: Gain: +15dB/-15dB, Frequency, 2.5kHz shelving... - Page 10 PMXU43BT - PMXU63BT - PMXU83BT Wireless BT Streaming Studio Mixer DJ Controller Audio Mixing Console System Features: • DJ & Studio Console Mixer System • Built-in Bluetooth Wireless Receiver • FX (Analog Effects) & 16 Bit DSP processor • Direct-to-Computer Connect & Sound Record Ability •...
