New England Arbors Versailles Assembly Instructions

A S S E M B LY I N S T R U C T I O N S
The Versailles Raised Garden Bed
or Versailles Raised Garden Bed Extension Kit
Please read through before starting assembly.

Check Box for These Contents

In the event of missing or defective parts please call our customer service dept. at 1 800 282 9346 (Mon. to Fri. 8:00 AM to 4:00 PM EST).
(UK Tel: (44) 2038 687160 (Mon. to Fri. 1:00 PM to 10:00 PM GMT).
1. Post with Post Caps attached (4) - Post 10830, Cap 10832
2. Side Panels (8) - 10831
3. 3.5" (10 cm) Stainless Steel Screws (16) - 20039
NOTE: The Versailles Raised Garden Bed Extension Kit
Contains the Following Parts & Quantities:
1. Post with Post Caps attached (2) - Post 10830, Cap 10832
2. Side Panels (6) - 10831
3. 3.5" (10 cm) Stainless Steel Screws (12) - 20039
3
Not to Scale

General Information

• Read Instructions through carefully before beginning assembly.
• When assembling components, place on a non-abrasive surface
(i.e. shipping box) to avoid scratching.
• We recommend an area approx 4'x 8' (1.2 m x 2.4 m) for unobstructed
assembling.
• You should not need to use excessive force when assembling components.
9 in.
(23 cm)
1
2
12 in.
56 in.
(30 cm)
(142 cm)
65.2 in.
65 in.
(166 cm)
(165 cm)
www.newenglandarbors.com
www.newenglandarbors.co.uk
65.2 in.
(166 cm)
59 in.
(150 cm)
59 in.
(150 cm)
V2.2/082117
