The Cat5 RemoteCam1-S family is offered as a unified electronics platform for cost effective remote Pan Tilt Zoom
(PTZ) camera installations. This system, offered in popular kit form, provides a rugged, high quality wall bracket for
supporting a camera, a universal power supply, molded color coded cable sets and interface electronics.
Regulated camera power, remote control and S-Video are carried on a single standard Cat5 UTP wire for distances
up to 300' 1 .
8-Pin mini DIN
(Video, Power & Control)
This technique of integrating PTZ cameras reduces installation hardware and labor for each camera position. All
hardware and cables are available with these kits to cover the most common video and video conferencing
applications for A/V Integrators.
SCT is now offering four complete kits for a wide variety of cameras and optional cable kits for popular video codec
configurations:
Kit Descriptions:
RC1-Sx™
RC1-SB™
RC1-SP™
RC1-ST™
Cable Sets:
RC1-Sx™
RC1-SB™
RC1-SP™
RC1-ST™
Optional Codec-Specific Cables:
Polycom
Tandberg
1 Sony BRC-300 currently supports S-Video, power & control up to 100 feet on a single Cat5
2 Tandberg Wave-II™ camera control loop limited to manufacturers specification
www.soundcontrol.net
28 Knight Street, Norwalk, CT., 06851
© SOUND CONTROL TECHNOLOGIES, INC., 2006
Patch Cable
General purpose interface
(Canon, Elmo & Sony)
Sony BRC-300 1
Polycom® Powercam™
Tandberg® Wave-II™
General purpose cables
Sony BRC-300 1
Polycom® Powercam™
Tandberg® Wave-II™
Codec Selection Guide
Codec Selection Guide
C
R
EMOTE
O
VERVIEW
Simple Overview
Power
Supply
Single Cat5
(Up to 300')
Page 2
Page 3
Page 4
2
Page 5
Page 6
Page 6
Page 6
2 Page 6
Page 7
Page 7
