Sound Control Technologies RemoteCam4-Producer Installation Instructions

Thank you for choosing the Sound Control Technologies' RemoteCam4™ camera integration kit!
 1 Power Supply & cord (Currently all RemoteCam Kits
utilize the WPS-12) to provide power for the
RemoteCam4™ electronics as well as the remote camera
up to 300' from the head end. All the RemoteCam™ kits
use the same power supply. The power supply is AC 100-
240V~47-63HZ compliant.
 1 RemoteCam4™ Head End Module (RC4-HE) which
provides system power, control interface (HDMI CEC, RX,
TX, GND & IR) for the camera & one HDMI video output
 1 RemoteCam4™ Camera Module with PowerSniffer™
(RC4-CE) that provides camera power, control (HDMI
CEC, RX, TX, GND & IR) and HDMI video input for the
camera
 Documentation
 Specific cables (P/N according to the following chart)
Company
Polycom
To proceed with the installation, insure that you have installed one CAT5e or CAT6 cable between
the camera installation site and the codec installation site.
www.soundcontrol.net
Included in each RC4-Producer™ kit will be:
for the codec.
Codec
Group Series
300, 500 & 700
Minimum distance should be approximately 30'/9M.
203-854-5701
RemoteCam4-Producer™
Installation Instructions
Camera
EagleEye IV
RC4-Producer™
Producer
©SOUND CONTROL TECHNOLOGIES, INC. 2017
DATE: 08/15/17
PRELIMINARY
SCT Kit Cables
RCC-C029
RCC-C031
RCC-H030
