EW41
QUICK START GUIDE
Please refer to the installation manual for more details
Current
ON/OFF
function
Temperature
in room
The display will turn on when pushing one of the buttons.
After a short period it will automatically turn off the display.
The display contrast level and the backlight can be adjusted in the menu.
Speed
Temperature
at chimney top
Increase speed
OK/Access menu
Decrease speed
UK
Advertisement
Table of Contents
Related Manuals for Exodraft EW41
Summary of Contents for Exodraft EW41
-
Page 1: Quick Start Guide
EW41 QUICK START GUIDE Please refer to the installation manual for more details Current ON/OFF Speed function Increase speed OK/Access menu Decrease speed Temperature Temperature in room at chimney top The display will turn on when pushing one of the buttons. - Page 2 Lighting the fire in the fireplace/stove 1. Press the ON/OFF-button to turn on the EW41 display. The display will show OFF. 2. Start the chimney fan by pressing the ON/OFF-button again. The display will show BOOST. The chimney fan will run at maximum speed for 7 minutes (default setting) and thereafter continue at the operating speed it was run- ning at last time it was in operation.
- Page 3 Turning off the fan - two options A. Manually: The fan is turned off by pressing the ON/OFF button once. NOTE: If the temperature sensor is activated the fan cannot be turned off manually as long as the temperature is above the stop temperature setting.
-
Page 4: Error Messages
Error messages 1. If an error is registered, the display on the control panel will be lit and the type of alarm shown. The display will show ERROR and the error type will be listed below as seen here on the right. An alarm tone will beep 5 times if the alarm is 03 (high temp.) or 04 (power failure) and the display will stay lit.
