IJOY-550/HT-2720
To ensure that Human Touch
products are repaired in a manner that is fully consistent with the practices used during the manufacturing process, Human Touch requires that all
®
product repairs are performed using only factory-new parts and in accordance with these product repair instructions.
NOTE: SAVE ALL REMOVED PARTS FOR USE DURING REASSEMBLY
REMOVING THE BACKREST FROM THE CHAIR BASE
1. Power off the chair and unplug it.
2. Remove the two screw knobs from the bottom of the backrest.
3. Lift the backrest up and off the chair base.
CAUTION:
The backrest is heavy. You may want to use two people to lift it off the chair base.
REPLACING THE BACKREST
(Fig.1)
(Fig.1)
06/01/08
SERVICE LEVEL: 2
Advertisement
Table of Contents
Related Manuals for Human Touch IJOY-550
Summary of Contents for Human Touch IJOY-550
- Page 1 REPLACING THE BACKREST IJOY-550/HT-2720 To ensure that Human Touch products are repaired in a manner that is fully consistent with the practices used during the manufacturing process, Human Touch requires that all ® SERVICE LEVEL: 2 product repairs are performed using only factory-new parts and in accordance with these product repair instructions.
- Page 2 2. From the bottom of the backrest, install and hand-tighten the two screw knobs. CAUTION: Make sure that the two screw knobs are installed and tightened before using the chair. (Fig.2) Please send any questions or comments regarding these instructions to: documentation@humantouch.com © 2008 Human Touch , LLC. ™...
