Z10-3 edition 1
Code: 002.001
HDS-4
HD/SD SDI switcher 4x1
USER MANUAL FOR USE AND MAINTENANCE
Read the instructions before using the device.
Keep this manual for periodic usage.
Sams elektronik d.o.o.
48 Zivka Davidovica st.
11050 Belgrade
Serbia
Tel/Fax: +381 11 3806 253
+381 11 2402 212
sams@sams.rs
www.sams.rs
Copyright © 1999 - 2014 Sams elektronik d.o.o.
Published: 26. july 2010.
Updated: 29. october 2014.
Advertisement
Table of Contents
Related Manuals for Sams HDS-4
Summary of Contents for Sams HDS-4
- Page 1 Keep this manual for periodic usage. Sams elektronik d.o.o. 48 Zivka Davidovica st. 11050 Belgrade Serbia Tel/Fax: +381 11 3806 253 +381 11 2402 212 sams@sams.rs www.sams.rs Copyright © 1999 - 2014 Sams elektronik d.o.o. Published: 26. july 2010. Updated: 29. october 2014.
- Page 2 Any technical failure or deficiency that occurs during the warranty period specified on the invoice of the purchased equipment will be inspected and serviced by Sams elektronik doo or an authorized service center of the manufacturer, with the conditions set out in the warranty statement.
- Page 3 CLASS I DEVICE Grounding is connected to the chassis of the device. The power supply is protected with fuse against overload. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs...
- Page 4 Design and specifications of the device may change without prior notice. TECHNICAL SUPPORT AND SERVICE Sams elektronik has made every effort to ensure that the equipment works in perfect condition. In the event that problems that occur can not be resolved, or if you have any questions regarding this...
-
Page 5: Table Of Contents
CABLE CONNECTION BETWEEN SWITCHER AND REMOTE ..........8 REMOTE CONTROL SCU-4 .....................9 CONFIGURATION AND CONNECTION, GRAPHIC EXAMPLE ..........10 NETWORK SETUP ......................11 NETWORK ACCESS AND DEVICE CONTROL ..............11 PROBLEMS AND SOLUTIONS IN A NETWORK ENVIRONMENT ..........13 SOFTWARE SUPPORT ....................15 NOTES .........................16 Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 6: Unpacking And Installation
Strictly comply to all steps for proper connection of devices in the system. Places for fastening MAINTENANCE The system maintains only person authorized by Sams elektronik doo. Any voluntarily opening device, upgrading or servicing is strictly prohibited and is subject to warranty void, and the possibility of injury. -
Page 7: Description
Control over ethernet HDS-4 is a 4x1 HD/SD SDI switcher. Switcher input has an automatic equalization of signal which compensates length up to 100m of 1694A cable, an vertical interval switching by SMPTE RP 168-1993 standard. Also have EDH processor, reclocked signal to the output and LED detection of type of reference signal. -
Page 8: Installation
If the switcher is connected to the network, changes in inputs that are made in this way remote control does not detect. CABLE CONNECTION BETWEEN SWITCHER AND REMOTE Connector for Control Panel SCU-10 (male/female) SUB D9 pin female male 2 3 4 Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 9: Remote Control Scu-4
Switchers elektronik REMOTE CONTROL SCU-4 The connection to the switcher Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 10: Configuration And Connection, Graphic Example
.r s in S e rb C O D S -4 E : 0 0 2 .0 3 0 V /5 0 P O W F U S E : 5 0 0 m Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 11: Network Setup
NETWORK ACCESS AND DEVICE CONTROL The device can be configured through the web browser. First, the device must be found in the local network. To do this, start the Sams Netfinder software double clicking on the icon. The software first scans for devices. - Page 12 Green field ONLINE changing letters from small to large, as long as there is communication with the device. In this way we have an overview on state of the connection. If the letter does not change, communication is stopped. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs...
-
Page 13: Problems And Solutions In A Network Environment
If the software NETFINDER is not able to locate the device in the network try the following: 1. Right click on Local Area Connection 2. Select option “Change Windows Firewall settings” 3. When a window “Windows Firewall” opens select tab “Exceptions” 4. Click on button “Add program” Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... - Page 14 13. In the IP Address field enter 192.168.0.200 (can be some other IP) 14. Connect the UTP cable to the computer and the other side to the device. 15. Turn on device. 16. Wait the computer to show “10mb connected...” Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs...
-
Page 15: Software Support
EXAMPLE: http://[ip_adresa]/get_data?dst00=0 This means: first input selected NOTE: - If you use a web browser for programming, we recommend that it be Mozilla Firefox , with desabled ® options to cache the page. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 16: Notes
Switchers elektronik NOTES Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs...
