8x8
Routing switchers 8x8
- HDV-88
- DVM-88
- DAM-88
- SVM-88
- SAM-88a2
USER MANUAL FOR USE AND MAINTENANCE
Read the instructions before using the device.
Keep this manual for periodic usage.
Z10-3 edition 1
Code: 003.160
003.101
003.110
003.120
003.131
Advertisement
Table of Contents
Related Manuals for Sams DVM-88
Summary of Contents for Sams DVM-88
- Page 1 Keep this manual for periodic usage. Sams elektronik d.o.o. 48 Zivka Davidovica st. 11050 Belgrade Serbia Tel/Fax: +381 11 3806 253 +381 11 2402 212 sams@sams.rs www.sams.rs Copyright © 1999 - 2014 Sams elektronik d.o.o. Published: 09. october 2012. Updated: 27. november 2014.
- Page 2 Any technical failure or deficiency that occurs during the warranty period specified on the invoice of the purchased equipment will be inspected and serviced by Sams elektronik doo or an authorized service center of the manufacturer, with the conditions set out in the warranty statement.
-
Page 3: Safety Warnings
CLASS I DEVICE Grounding is connected to the chassis of the device. The power supply is protected with fuse against overload. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 4: Technical Support And Service
Design and specifications of the device may change without prior notice. TECHNICAL SUPPORT AND SERVICE Sams elektronik has made every effort to ensure that the equipment works in perfect condition. In the event that problems that occur can not be resolved, or if you have any questions regarding this... -
Page 5: Table Of Contents
MAINTENANCE ......................6 REMOVAL AND STORAGE ....................6 DESCRIPTION .......................7 INSTALLATION ......................12 CP-88, MASTER REMOTE CONTROL 8x8 .................14 CP-8, SLAVE REMOTE CONTROL 8X1 ................15 CONNECTORS .......................16 CONFIGURATION AND CONNECTION, GRAPHIC EXAMPLE ..........16 SOFTWARE ........................17 NOTES .........................18 Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 6: Unpacking And Installation
Strictly comply to all steps for proper connection of devices in the system. Places for fastening MAINTENANCE The system maintains only person authorized by Sams elektronik doo. Any voluntarily opening device, upgrading or servicing is strictly prohibited and is subject to warranty void, and the possibility of injury. -
Page 7: Description
- Overload protection: ....front Mounted Circuit Breaker - Connectors: ..............BNC TEMPERATURE - Performance: ............5-40°C - Operating: .............. 0-50°C ORDERING INFORMATION Code Name Description 003.160 HDV-88 HD/SD SDI routing switcher 8x8 003.901 CP-88 Remote control 8x8 Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 8: Ordering Information
Power down memory recovery PC control The DVM-88 video routing switcher is a compact 8x8 serial video module. Input conform to all component and composite digital standards signals. The Auto reclocking circuitry is standards independent. Auto equalization circuitry compensates fo up to 200 m of 1694A cable. - Page 9 - Impedance: ......110Ω balanced / 75Ω unbalanced - Signal level: ............0.2-7V p-p PERFORMANCE - Sampling rates:............32-96KHz ORDERING INFORMATION Code Name Description 003.110 DAM-88 AES/EBU routing switcher 8x8 003.901 CP-88 Remote control 8x8 Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs...
- Page 10 - Gain stability: ............ < ± 0.1dB - Frequency response: ....± 0.1dB (50Hz to 5.5MHz) ORDERING INFORMATION Code Name Description 003.120 SVM-88 Analog video routing switcher 8x8 003.901 CP-88 Remote control 8x8 Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs...
- Page 11 - Output to output isolation: .... > 70dB at 20Hz to 20KHz - Maximum output level: ..........+24dB ORDERING INFORMATION Code Name Description 003.131 SAM-88a2 2ch audio routing switcher 8x8 003.901 CP-88 Remote control 8x8 Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs...
-
Page 12: Installation
AC ~230V/50Hz INPUT REMOTE OUTPUT AUDIO INPUT AUDIO OUTPUT 1-8 CH 1 1-8 CH 2 1-8 CH 1 1-8 CH 2 POWER USE ONLY WITH A 250V FUSE FUSE: 500mA SAM-88a2, rear side Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... - Page 13 REF - YELLOW - reference is ON / YELLOW FLASH - reference is OFF WDT - RED - remote is ON / RED FLASH - remote is OFF +5V - RED - power indication Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs...
-
Page 14: Cp-88, Master Remote Control 8X8
PC. When PANEL LOCK is off, the software on the PC is used only for monitoring and PC ENABLE LED flashes. PC ENABLE LED flashes when the PC software is active. Control from the PC is used to connect XY and has the same functions as the master command. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 15: Cp-8, Slave Remote Control 8X1
PC. When PANEL LOCK is off, the software on the PC is used only for monitoring and PC ENABLE LED flashes. PC ENABLE LED flashes when the PC software is active. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 16: Connectors
2 3 4 Connector for PC (male/female) SUB D9 pin PC TX PC RX 2 3 4 female male CONFIGURATION AND CONNECTION, GRAPHIC EXAMPLE Master remote Slave remote control controls Audio video routing switchers Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 17: Software
PC, the “COM OK” green colors will appear. It will not be included if you do not connect properly or if routing switcher is turned off. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 18: Notes
UNLOCK on the center of the screen. If you want to lock certain destinations press button KEY. In the same way it unlocks. By pressing UNDO return to the previous state of the selected intersection. NOTES Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs...
