F: Node Assembly - Teradek LINK Pro User Manual

A:
Link Pro assembly
B:
Wi-Fi antenna
connectors
C:
Node assembly 1
D:
Node assembly 2
E:
Node assembly 3
F:
Node assembly 4
G:
Battery mount
A:
SIM card slot 1
B:
4-pin data/power input 1
C:
SIM card slot 2
D:
4-pin data/power input 2
E:
SIM card slot 3
F:
4-pin data/power input 3
G:
SIM card slot 4
H:
4-pin data/power input 4
