Mounting Instructions 82132/33 Code-Combi B with Aluminium Control Unit
1 General
These mounting instructions are the basis for the approval by ECBS, VdS, A2P (CNPP)- DNV, UL. Installation of the
lock to be performed exclusively in accordance with these instructions.
Guidelines of the national certification bodies are to be considered and complied with in addition.
•
Use high quality alkaline/manganese monobloc batteries only. Low quality batteries may cause oxidation which results in a
functional failure of the lock..
•
Avoid residual crystalline moisture in the cabinet (e.g. from varnishing) to make sure that electrical contact areas are not
attacked.
•
Make sure that the ingress of dirt or detergents (e.g. remaining fillers or cold cleaners) is prevented.
•
Do not grease/oil the lock or key.
2 Mounting instructions for lock and control unit
RH version (standard version):
-
Bolt LH, keyhole horizontal
Bolt downwards, keyhole vertical
Bolt upwards, keyhole vertical
- LH version
Bolt RH, keyhole horizontal
•
Any variation of the lock or key may result in functional trouble and must better not be done. All claims under guarantee and
warranty will expire in this case.
•
Lock fastening: Use of M6 steel socket head cap screws or BSW ¼" steel bolts. The length of engagement must
correspond to the applicable standards considering the thickness of the lock of 30 mm and the screwing height of the lock
case of 24 mm.
•
Fastening screws: minimum property class 4.8 and maximum property class 8.8.
• Screws to be secured either by lock washer, flat spring, tooth lock washer, fan type lock washer considering the diameter
(d1) or to be cemented.
•
Screw tightening moment : minimum 5 Nm and maximum 6 Nm.
•
The bolt must be floating in installed condition.
• Perfect function of the lock and of any additional connected or triggered systems (e.g. boltworks) must be warranted and
checked by specialists during installation of the lock.
•
The lock must be mounted in closed condition (bolt extended).
