US-48-500W, US-48-750W Quick Start Guide
Package Contents
UniFi Switch
Cage Nuts (Qty. 4)
Installation Requirements
Phillips screwdriver
Standard-sized, 19" wide rack with a minimum of 1U height available
For indoor applications, use Category 5 (or above) UTP cabling approved for indoor use.
For outdoor applications, shielded Category 5 (or above) cabling should be used for all
wired Ethernet connections and should be grounded through the AC ground of the power
supply.
We recommend that you protect your networks from harmful outdoor environments and
destructive ESD events with industrial-grade, shielded Ethernet cable from Ubiquiti. For
more details, visit:
Note:
housed inside a protective enclosure.
IMPORTANT:
https://dl.ubnt.com/qsg/US-48-500W_US-48-750W/US-48-500W_US-48-750W_EN.html[1/27/2020 1:40:10 PM]
US-48-500W, US-48-750W Quick Start Guide
ui.com/toughcable
Although the cabling can be located outdoors, the UniFi Switch itself should be
We strongly recommend using UPS backup and power regulation to
Power Cord
Mounting Screws (Qty. 4)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ubiquiti UniFi US-48-750W
Summary of Contents for Ubiquiti UniFi US-48-750W
-
Page 1: Package Contents
Ethernet connections and should be grounded through the AC ground of the power supply. We recommend that you protect your networks from harmful outdoor environments and destructive ESD events with industrial-grade, shielded Ethernet cable from Ubiquiti. For more details, visit: ui.com/toughcable... -
Page 2: Hardware Overview
US-48-500W, US-48-750W Quick Start Guide prevent equipment damage due to stability issues with local AC power. System Requirements Linux, Mac OS X, or Microsoft Windows 7/8/10 Java Runtime Environment 1.6 (1.8 or newer recommended) Web Browser: Mozilla Firefox, Google Chrome, Microsoft Edge, or Microsoft Internet Explorer 11 UniFi Controller v5.4.x or higher Hardware Overview... - Page 3 US-48-500W, US-48-750W Quick Start Guide SFP+ Speed/Link/Act LED (Ports 1 - 2) No Link Link Established at 1 Gbps Green Flashing Indicates Activity Link Established at 10 Gbps White Flashing Indicates Activity SFP Speed/Link/Act LED (Ports 1 - 2) No Link Link Established at 1 Gbps Green Flashing Indicates Activity...
-
Page 4: Hardware Installation
US-48-500W, US-48-750W Quick Start Guide Console Port RJ45 serial console port for Command Line Interface (CLI) management. Use an RJ45-to- DB9, serial console cable, also known as a rollover cable, to connect the Console port to your computer. Then configure the following settings as needed: Baud rate 115200 Data bits 8 Parity NONE... - Page 5 US-48-500W, US-48-750W Quick Start Guide https://dl.ubnt.com/qsg/US-48-500W_US-48-750W/US-48-500W_US-48-750W_EN.html[1/27/2020 1:40:10 PM]...
-
Page 6: Connecting Ethernet
US-48-500W, US-48-750W Quick Start Guide Connecting Ethernet https://dl.ubnt.com/qsg/US-48-500W_US-48-750W/US-48-500W_US-48-750W_EN.html[1/27/2020 1:40:10 PM]... - Page 7 US-48-500W, US-48-750W Quick Start Guide Using SFP+ and SFP Ports Ports SFP+ Module Type SFP Module Type SFP+ 1-2 10 Gbps 1 Gbps SFP 1-2 (Not supported) 1 Gbps https://dl.ubnt.com/qsg/US-48-500W_US-48-750W/US-48-500W_US-48-750W_EN.html[1/27/2020 1:40:10 PM]...
- Page 8 US-48-500W, US-48-750W Quick Start Guide https://dl.ubnt.com/qsg/US-48-500W_US-48-750W/US-48-500W_US-48-750W_EN.html[1/27/2020 1:40:10 PM]...
-
Page 9: Software Installation
US-48-500W, US-48-750W Quick Start Guide For information about compatible fiber SFP modules, visit: community.ubnt.com/unifi Software Installation Download and install the latest version of the UniFi Controller software at ui.com/download/unifi and follow the on-screen instructions. Note: If you already have UniFi Controller v5.4.x or higher installed, go to the section, Adopting the UniFi Switch. - Page 10 US-48-500W, US-48-750W Quick Start Guide You can manage your network and view network statistics using the UniFi Controller management interface. To adopt the UniFi Switch, proceed to the section, Adopting the UniFi Switch. For information on configuring and using the UniFi Controller software, refer to the User Guide on the website: ui.com/download/unifi Adopting the UniFi Switch...
-
Page 11: Configuring Poe Settings
US-48-500W, US-48-750W Quick Start Guide 2. Locate the UniFi Switch in the list of devices under the Model column. Click Adopt. 3. The System LED on the UniFi Switch will turn blue to confirm that it has been successfully adopted. Configuring PoE Settings 1. - Page 12 US-48-500W, US-48-750W Quick Start Guide 2. Click the Ports tab. 3. Click Actions for the port you want to configure. https://dl.ubnt.com/qsg/US-48-500W_US-48-750W/US-48-500W_US-48-750W_EN.html[1/27/2020 1:40:10 PM]...
-
Page 13: Specifications
US-48-500W, US-48-750W Quick Start Guide 4. Select the appropriate PoE setting: Off, 24V Passive, or PoE+. Then click Apply. For more information, refer to the User Guide on the website: ui.com/download/unifi Specifications US-48-500W/US-48-750W https://dl.ubnt.com/qsg/US-48-500W_US-48-750W/US-48-500W_US-48-750W_EN.html[1/27/2020 1:40:10 PM]... -
Page 14: Safety Notices
US-48-500W, US-48-750W Quick Start Guide Dimensions 485 x 43.7 x 374.6 mm (19.09 x 1.72 x 14.75") Weight US-48-500W 6.1 kg (13.5 lb) US-48-750W 6.5 kg (14.3 lb) Total Non-Blocking Line Rate 70 Gbps Max. Power Consumption US-48-500W 500W US-48-750W 750W Power Method 100-240VAC/50-60 Hz, Universal Input... -
Page 15: Electrical Safety Information
US-48-500W, US-48-750W Quick Start Guide clearance next to the ventilation holes for adequate airflow. WARNING: To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. WARNING: Do not use this product in location that can be submerged by water. WARNING: Avoid using this product during an electrical storm. -
Page 16: Declaration Of Conformity
US-48-500W, US-48-750W Quick Start Guide 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. - Page 17 US-48-500W, US-48-750W Quick Start Guide © 2020 Ubiquiti Inc. All rights reserved. https://dl.ubnt.com/qsg/US-48-500W_US-48-750W/US-48-500W_US-48-750W_EN.html[1/27/2020 1:40:10 PM]...
