- Page 1 Connected Doorlock notice PA2045B1...
-
Page 2: Table Of Contents
Fonctionnalities of the gateway ......... 13 Reset of the connected doorlock ....... 14 Resynchronization of the connected doorlock ..15 Batteries ..............16 Technical caracteristics ..........17 Light codes of the connected doorlock ..... 19 Light codes of the gateway ........20 Information ............... 21... -
Page 3: Content Of The Pack
Connected doorlock Content of the pack Motor Back plate Metal casing Cylinder (2 lengths available according to the reference) 3 keys + property card 4 lithium AAA batteries Bolting kit Quick Start Guide + Internet Gateway (option) Metal backplate screws... - Page 4 Connected doorlock Installation of the connected doorlock Doorlock equipped with a European standards cylinder. Different thicknesses of doors (up to 9cm). Multipoint locks. Doors with and without outside handle. Check your door and smartphone Download the free mobile application compatibilities on somfy.fr.
-
Page 5: Replacement Of The Cylinder Of Origin
Connected doorlock Replacement of the cylinder of origin Remove the existing cylinder Compare the key blades alignement of your cylinder and the Somfy ones Cylinder Cylinder of origin of origin Exterior Interior Exterior Interior P2 P1 P3 P2 P1 P3... -
Page 6: Adjustment Of Somfy Cylinder
As a reminder, the key blade P1 of the pieces P2 and P3, unscrew the fixing screws Then, pull on the gold metallic fork (2), to Somfy Cylinder needs to be aligned with located under the cylinder. release the key blade P1. - Page 7 Make sure the black key blade P1 rotates Finally, screw the fixing screws. cylinder, completely to the end. correctly, then screw the pin back. Insert the key in the cylinder Somfy, and check it is operating accurately. YOUR NEW CYLINDER IS NOW READY !
-
Page 8: Installation Of The Connected Doorlock
Exterior Interior Introduce the cylinder Somfy from the inside Stick the back plate around the cylinder with Position the connected doorlock on the cylinder of the door (1). You have to find the position in double-sided adhesive tape supplied. fork. - Page 9 Connected doorlock Appendix: Type of lock Doorlock with a framed door level Doorlock with an escutcheon Unscrew the bottom screw (A). Unscrew the fixing screws (C). Position the back plate on top of the framed Position the back plate on the escutcheon.
- Page 10 Installation of the connected doorlock Doorlock installation Batteries insertion Initialization +3’’ Fix the connected doorlock on the back plate Insert the 4 baterries, observe the correct The connected doorlock is going to analyse the with 3 fixing screws model). polarity when inserting the batteries and make door.
- Page 11 Synchronization Finalization Example of serial number ABCD123456789 If it is not already done, download Somfy Keys app. At the end of the installation and setting up of the doorlock, clip the metallic casing. Create your account. You can fix it with the model screw.
-
Page 12: Adding An Internet Gateway
Connected doorlock Adding an Internet gateway 1. Connect your smartphone to the WiFi network. 2. In Somfy Keys app, go to Internet gateway tab and follow the instructions. Select the WiFi network and tape in its password. The gateway makes the 3. -
Page 13: Fonctionnalities Of The Gateway
Connected doorlock Fonctionnalities of the gateway GATEWAY WITHOUT gateway WITH gateway Tags management in real time Lock / Unlock remotely Yes, with the app Availability of the lock status in BLE mode Yes, with the app Availability of the lock histoty... -
Page 14: Reset Of The Connected Doorlock
Connected doorlock Reset of the connected doorlock It programs the connected doorlock in factory setting In Somfy Keys app On the doorlock Inner side +10’’ Open the app Somfy Keys Unscrew the screw under the doorlock. On the lock screen, go to «manage access»... -
Page 15: Resynchronization Of The Connected Doorlock
Connected doorlock Resynchronization of the connected doorlock «The doorlock resynchronization updates all the data of the doorlock. It is done automatically when there are setting changes on Somfy Keys. It can also be done manually. « Open Somfy Keys. On the lock screen, go to «manage access»... -
Page 16: Batteries
. The connected doorlock will indicate you when you’ll have to replace the batteries. It’ll blink orange before each lock or unlock. The Somfy Keys app will also warn you of a low battery level. . Proceed in the same way as the installation to replace the batteries. -
Page 17: Technical Caracteristics
Connected doorlock Technical caracteristics Technical caracteristics of the motor : Technical caracteristics of the cylinder : Radio frequency : 2.4 GHz Compliant with the EN1303 (2006) standard Frequency bands and maximal power used 2402 - Classification: 16000C32 2480 MHz - E.r.p. < 25 mW Number of pins : 5 Bluetooth lock 4.0 (BLE) - Page 18 Connected doorlock Technical caracteristics Technical caracteristics of the gateway : Terms of use Altitude : < 2000 m Radio frequency 2.4 GHz Pollution index 2, Pol.2 Wi-Fi range 30 m in open space Safety rating against ingress of foreign bodies IP30, EN 60529 2400 to 2483.5 MHz...
-
Page 19: Light Codes Of The Connected Doorlock
Connected doorlock Light codes of the connected doorlock Bluetooth communication Doorlock unlocking Doorlock locking Other codes Low batteries Self-learning: in progress Self-learning: OK Self-learning: Failure Installation or update: OK Installation or update: Failure... -
Page 20: Light Codes Of The Gateway
Connected doorlock Light codes of the gateway Other codes Gateway never configured (waiting for its first configuration) Gateway waiting for its firt configuration Everything is OK Failure... -
Page 21: Information
Before the installation, check the compa- ture, liquid splashes, or immerse it. strongly on the environment of use : tibility of this Somfy product with the asso- possible disturbances by large electrical Do not attempt to repair it. ciated equipment and accessories. - Page 22 Connected doorlock Garantie This product has a warranty of 24 months SOMFY ACTIVITES SA hereby declares from the date of purchase. that the radio equipment covered by We care about our environment. Do If a technical malfunctionning is noticed not dispose of the appliance with usual...
- Page 23 Hotline France +33 820 055 055 Somfy dans un souci constant d’évolution et d’amélioration peut modifier le produit sans préavis. Photos non contractuelles. Copyright 2018 Copyright c 2018 Somfy ACTIVITES SA. All rights reserved SOMFY ACTIVITES SA, capital 35.000.000 Euros, RCS Annecy 303.970.230 - 06/2017...
