Mounting Your Tentbox - TentBox CLASSIC Safety And Fitting Instructions

Mounting your TentBox

Requires two people
STEP 1: With the help of another person, lift your TentBox onto the top of
your Cross Bars so that it sits straight and well centred on top of your car.
STEP 2: Drop the 8 bolts into 4 of the fixing plates, making sure the square
under the bolt head fits snugly into the square hole. If your roof bars are
narrow enough, use the two inside holes. If they are wider, use the two outside
holes.
STEP 3: Slide two of these fixing plates onto one of rails underneath your
TentBox. You want to push them along so that you have a bolt hanging down
on either side of each cross bar, as shown below. You then repeat this
process on the other rail. You should now have 4 fixing points like the diagram
below.
