Page 1 SIMOTICS FD Induction motor Type 1LL1 Operating Instructions / Installation Instructions Edition 04/2016 siemens.com...
Page 2 13.04.2016 11:56 V9.01...
Page 3 Introduction Safety information Description SIMOTICS FD Preparations for use Induction motor 1LL1 Assembly Electrical connection Operating Instructions Installation Instructions Start-up Operation Maintenance Spare parts Disposal Service and Support Technical data and drawings Quality documents Additional documents Edition 04/2016...
Page 4: Edition
Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
Page 5: Table Of Contents
Noise emissions........................32 4.12 Rotational speed limit values....................33 4.13 Phase synchronization during supply system switching............33 4.14 System-inherent frequencies....................33 4.15 Torsional loading of the drive train due to faults in the electrical supply........33 4.16 Transport and storage......................34 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 6 Electrical connection...........................65 Safety instructions relating to the electrical connection............65 Terminal box..........................65 6.2.1 Terminal box 1XB1621......................66 6.2.2 Terminal box 1XB1631......................67 6.2.3 Terminal box 1XB7730......................68 6.2.4 Terminal box 1XB7731......................68 6.2.5 Terminal box 1XB7740......................69 6.2.6 Terminal box 1XB7750......................70 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 7 Selecting the motor type and motor data in the STARTER program........97 7.9.2 Commissioning at the SINAMICS S/G converter using the AOP30........100 7.9.3 Commissioning at the SINAMICS G120P inverter using the IOP........103 Operation..............................105 Safety guidelines in operation....................105 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 8 Removing the labyrinth sealing ring..................129 9.2.3.4 Assembling the rolling-contact bearings................130 9.2.3.5 Install the V ring........................131 9.2.3.6 Installing the V ring ("Increased degree of protection" option)..........131 9.2.3.7 Installing the labyrinth sealing ring..................132 9.2.4 Seal the motor........................133 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 9 Dismantling the machine......................153 11.3 Disposal of components.......................154 Service and Support..........................155 Technical data and drawings........................157 Tightening torques for screw and bolt connections..............157 Quality documents............................159 Additional documents..........................161 Additional documents on CD....................161 Index.................................163 Tables Table 3-1 Machine design ..........................21 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 10 Main terminal box 1XB7730 spare parts...................145 Table 10-10 Additional spare parts........................145 Table 10-11 Main terminal box 1XB7731 spare parts...................146 Table 10-12 Additional spare parts........................146 Table 10-13 Main terminal box 1XB7740 spare parts...................147 Table 10-14 Additional spare parts........................147 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 11 Bearing cartridge at the drive end and non-drive end...............140 Image 10-4 Terminal box 1XB1621 with standard cable entry..............142 Image 10-5 Two-part cable entry........................142 Image 10-6 Terminal box 1XB1631......................144 Image 10-7 Main terminal box 1XB7730......................145 Image 10-8 Main terminal box 1XB7731......................146 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 12 Main terminal box 1XB7750 with standard cable entry.............148 Image 10-11 Auxiliary terminal box 1XB9014 .....................149 Image 10-12 Auxiliary terminal box 1XB9015 .....................150 Image 10-13 1XB9016 auxiliary terminal box ....................151 Image 10-14 Auxiliary terminal box 1XB302....................152 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 13: Introduction
You can delete or shift individual chapters or topics. Further, using the note function you can import your own content. The compiled "documentation" can be exported as PDF, for example. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 14 Using the "Documentation" function, you can efficiently compile your own plant or system documentation. The "Documentation" compiled in a specific language can also be automatically exported in one of the other available languages. The full functionality is only available for registered users. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 15: Safety Information
EN 50110‑1 "Working in a voltage-free state". Apply the five safety rules in the sequence stated before starting work. Five safety rules 1. Disconnect the system. Also disconnect the auxiliary circuits, for example, anti-condensation heating. 2. Secure against reconnection. 3. Verify absence of operating voltage. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 16: Qualified Personnel
● Always observe the “five safety rules" (Page 15) when carrying out any work on the machine. ● Only remove the covers using the methods described by these operating instructions. ● Operate the machine properly. ● Regularly and correctly maintain the machine. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 17 Burns and other damage to health and material may result. ● Read the information in these operating instructions and the product information supplied by the manufacturer. ● Observe the relevant safety regulations and wear the personal protective equipment specified. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 18: Electrostatic Sensitive Devices
● Always place electrostatic sensitive devices on conductive bases. ● Always pack, store and transport electronic modules or components in conductive packaging, such as: – Metallized plastic or metal containers – Conductive foam material – Domestic aluminum foil SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 19: Electromagnetic Compatibility
The machine fulfills the requirements regarding interference immunity in conformity with IEC/ EN 61000‑6‑2. On machines with integrated sensors (e.g. PTC thermistors), the manufacturer of the overall system must himself ensure sufficient interference immunity by selecting suitable sensor signal leads and evaluation units. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 20: Interference Voltages When Operating The Converter
● Protect the personnel working in the plant by taking appropriate measures, such as erecting identifying markings, safety barriers and warning signs and giving safety talks. ● Observe the nationally applicable health and safety regulations. ● Do not carry any magnetic or electronic data media. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 21: Description
Cooling IEC/EN 60034‑6 Type of construction IEC/EN 60034‑7 Terminal markings and direction of rotation IEC/EN 60034‑8 Noise emission IEC/EN 60034‑9 Starting characteristics of rotating electrical machines * IEC/EN 60034‑12 Vibration severity grades IEC/EN 60034‑14 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 22: Image
Table 3-2 Data on the rating plate Item Description Item Description Type of motor (15) Rated power [kW or HP] Order number (16) Rated efficiency factor Identifier of the motor series (17) Rated speed [rpm] SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 23 From January 1, 2017, the IE3 efficiency requirement for motors with a power of 0.75 kW to 375 kW applies for line operation. Efficiency IE2 still applies for motors that are operated from a converter. Please note the applicable country-specific rules and regulations. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 24 Shaft height Direction of rota‐ Speed tion External fan made of plastic 1LL..3A Bidirectional 1LM..3A External fan made of cast 1MM..3A Bidirectional steel 1MM..3B...2 Bidirectional < 3000 rpm 1MM..3B...3 1MM..3B...4 1MM..3B...6 1MM..3B...7 1MM..3B...8 1MM..3B... SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 25 ● Drive end: Pairing of angular-contact ball bearing / deep-groove shaft height 355 ... 450 ball bearing as a fixed bearing ● Non-drive end: Deep-groove ball bearing as a floating bearing with axial compression springs SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 26 Service Center. If you wish to retrofit using a different terminal box at a later date, please contact the Service Center (Page 155). See also Rotating the terminal box (Page 70) Terminal box (Page 65) SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 27 Depending on the order, various supplementary devices can be installed or mounted. These include sensors for bearing temperature monitoring or winding monitoring, for example. Anti-condensation heating (option) The machine is fitted with anti-condensation heating. The connection data is listed on an additional plate on the machine. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 28 Description SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 29: Preparations For Use
● Hot discharged air must not be drawn in again. ● On the vertical design with air intake from above, the air inlets must be protected against the ingress of foreign bodies and water. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 30: Space Required For Ventilation
The necessary space requirements are listed in the following table: Table 4-2 Space required for removing/installing the air filter Type Space requirement / clearance A 1L.….-3A…-…. 300 mm 1L.….-3B…-…. 350 mm 1L.….-4A…-…. 400 mm 1L.….-4B…-…. 450 mm SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 31: Thermal Motor Protection
● Install an interlock circuit that switches off the anti-condensation heating once the main machine is switched on. ● Only switch on the anti-condensation heating after the motor has been switched off. Carefully comply with the data on the anti-condensation heating plate. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 32: Support Base For Im B5 Construction Type
Take steps to reduce noise, such as introducing covers and protective insulation or adopting hearing protection measures, so that the machine can be operated safely within your system. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 33: Rotational Speed Limit Values
In the event of faults in the electrical connection during operation, excessive air gap torques can lead to additional mechanical torsional load on the line shaft. Note The system planner is responsible for the entire drive train. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 34: Transport And Storage
– Use a crane or fork-lift truck suitable for the load. – The center of gravity of the goods and the positions of the hoisting points are indicated on the packaging. Do not hoist any goods with damaged packaging. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 35 ● Always take account of the center of gravity when transporting or lifting the motor. If the center of gravity is not located centrally between the attachment points, then position the hoisting hook above the center of gravity. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 36: Securing The Rotor
80 Nm 20 kN 150 Nm 30 kN 230 Nm 40 kN Note Store the rotor locking device Be sure to store the rotor locking device. It must be remounted for possible disassembly and transport. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 37: Transporting The Machine Set
If the machine is stored incorrectly there is a risk that the bearings will suffer damage while out of use. Examples of resulting damage can include scoring and corrosion. Read the following storage instructions. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 38 ● The ground must be sufficiently strong. Prevent the motor from sinking into the ground. ● Covers or tarpaulins used to protect the equipment against the weather must not make contact with the surfaces of the equipment. Otherwise air circulation under the stored items will be prevented. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 39 ● Make sure that the storage conditions are such that condensation cannot form in the motor. ● If the machine is not sealed in plastic film, continually and slightly heat the machine, e.g. with anti-condensation heating (if available), and ensure that the air circulates in the storage room. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 40: Storing The Filter Mats (Option, Air Filter)
● Storage for longer than six months: Apply a coat of anti-corrosion compound which provides long-term protection, e.g. Tectyl 506. ● Inspect the machine regularly and apply an additional coating of corrosion protection if necessary. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 41: Converter Operation
Taking the following actions will reduce the bearing currents: ● Ensure that the contacts are established over a large area. Solid copper cables are not suitable for high frequency grounding because of the skin effect. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 42 – Use braided flat copper straps or high-frequency cables with finely-stranded conductors for the separate RF equipotential bonding cable. Solid copper cables are not suitable for high frequency grounding because of the skin effect. – Ensure that the contacts are established over a large area. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 43: Insulated Bearings When Operating The Converter
● In the overall system, set up a properly meshed grounding system with low impedance. ● Use the common-mode filter (damping cores) at the converter output. The Siemens sales representative is responsible for selection and dimensioning.
Page 44: Image 4-3 Schematic Representation Of A Tandem Drive
Bearing currents can flow if the coupling between the motors of the tandem drive is not insulated. This can damage the DE bearings of both motors. ● Use an insulated coupling to link the motors. See also Service and Support (Page 155) SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 45: Assembly
● Temperature-sensitive parts such as normal cables or electronic components must not rest against or be attached to mounted machine parts. ● Only use heat-resistant mounting parts. The connecting cables and cable entries must be suitable for the ambient temperature. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 46: Insulation Resistance And Polarization Index
Measure the insulation resistance 1. Before you begin measuring the insulation resistance, please read the operating manual for the insulation resistance meter you are going to use. 2. Make sure that no power cables are connected. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 47 In this case, doubling or halving the insulation resistance at a temperature change of 10 K is used as the basis. ● The insulation resistance halves every time the temperature rises by 10 K. ● The resistance doubles every time the temperature falls by 10 K. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 48 Limit values of the anti-condensation heating insulation resistance The insulation resistance of the anti-condensation heating with respect to the machine housing should not be lower than 1 MΩ when measured at 500 V DC. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 49: Prepare The Mating Faces (Im B3)
● Ensure that the wall surface is flat and free of contaminations. ● Check the dimensions of the mounting-foot holes. ● Support the machine from below, e.g. using a wall bracket or by bolting it. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 50: Lift The Machine To Where It Will Be Installed, And Position It
Removing the rotor shipping brace If a rotor shipping brace is attached to the machine, remove it at the last possible moment, for example, when you are ready to push on the output or drive element. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 51: Removing The Rotor Shipping Brace From Machines In Vertical Type
Machined, bright surfaces of machine parts and small components such as screws, bolts, wedges, feather keys and dowel pins, are treated with an anti-corrosion agent. Carefully remove the anti-corrosion agent just before starting the installation work. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 52: Mounting The Output Elements
● "H" means balancing with a half feather key ● "F" means balancing with a whole feather key Image 5-1 Balancing type on the drive-end side SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 53 ● The coupling used must be prepared for system balancing. The number of poles of the machine is specified on the rating plate, at the 10th position of the motor type. There, four-pole machines are marked with a "B". SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 54: Requirements For Safe Lifting And Transporting
– Do not exceed the maximum lifting acceleration and lifting speed specified on the lifting plate. Lift the machine without jerking it. Acceleration a ≤ 0.4 g (≈ 4 m/s Velocity v ≤ 20 m/min ● Use only the load carrying device on the stator frame for lifting. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 55 If the lifting gear or load handling attachments were to fail, the machine could fall. This can result in death, serious injury or material damage. Never remain under or in the immediate vicinity of the machine when it is raised. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 56: Putting The Machine Down
Condensate can also cause rust to form within the machine. Ensure that condensate can drain away. Depending on the type of installation, the water drainage holes are located at the bottom: SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 57: Image 5-2 Condensation Water Drain For Vertical Mounting
Image 5-3 Condensation water drain for horizontal mounting To drain the condensation water, proceed as follows: 1. Remove the screw plugs to allow the condensation water to drain. 2. Then reinsert the screw plugs. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 58: Roughly Aligning The Machine
Screws may become loose or break, the machine will move, machine parts could be flung out of place. This can result in death, serious injury or material damage. ● Carefully align the machine to the driven machine. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 59: Selecting Fixing Screws
Preconditions for smooth, vibration-free operation: ● Stable foundation design ● Precise alignment of the machine ● Correct balancing of parts to be fitted to the shaft end. ● Maintaining the vibration velocity according to ISO 10816‑3 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 60: Aligning The Machine To The Driven Machine And Mounting (Im B3 / Im B35)
5. Fix the machine to the foundation. The choice of fixing elements depends on the foundation and is the plant operator's responsibility. ① Plates placed under the motor for alignment ② Laser alignment Image 5-4 Schematic diagram: Aligning the machine to the driven machine SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 61: Aligning The Machine To The Driven Machine And Attaching It To It (Im B5)
5. Move the machine fully up against the mating flange so that it is fully in contact. 6. Fix the machine using the flange fixing bolts, finishing by replacing the studs. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 62: Fastening The Support Base (Im B5)
Lowering too quickly risks damaging the centering. 4. If necessary, rotate the machine into the right position so that the clearance holes in the flange are central to the tapped holes. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 63: Axial And Radial Forces
0.05 mm in diameter. 5.3.8 Axial and radial forces You can obtain the permissible values for axial and radial forces by contacting the Siemens Service Center (Page 155) or referring to the machine catalog. NOTICE Damage to bearings or the shaft Large output masses and their centers of gravity outside the shaft extensions can lead to resonance in operation.
Page 64 Assembly 5.3 Installing the machine SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 65: Electrical Connection
Depending on the terminal box, different cable entries and options for the cable connection are possible. You can identify the terminal box installed on the machine via the illustrations in the following chapters. Terminal box 1XB1621 (Page 66) SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 66: Terminal Box 1Xb1621
● Bringing cables into the terminal box 1XB... with cable gland (Page 78) ● Connecting cables without cable lugs (Page 80) ● Connecting cables with cable lugs (Page 80) See also Bringing cables into the terminal box 1XB... with sealing insert with break-off ring (Page 77) SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 67: Terminal Box 1Xb1631
● Bringing cables into the terminal box 1XB... with cable gland (Page 78) ● Connecting cables without cable lugs (Page 80) ● Connecting cables with cable lugs (Page 80) See also Bringing cables into the terminal box 1XB... with sealing insert with break-off ring (Page 77) SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 68: Terminal Box 1Xb7730
● Bringing cables into the terminal box 1XB... with cable gland (Page 78) ● Connecting cables with cable lugs (Page 80) ● Connecting cables without cable lugs (Page 80) 6.2.4 Terminal box 1XB7731 Image 6-4 Terminal box 1XB7731 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 69: Terminal Box 1Xb7740
You can find additional information here: ● Bringing cables into the terminal box 1XB... with cable gland (Page 78) ● Connecting cables with cable lugs (Page 80) ● Connecting cables without cable lugs (Page 80) SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 70: Terminal Box 1Xb7750
● 1XB7731 – For six or fewer cables, you can rotate the terminal box with installed stator cables through ±90°. – For more than six cables, you must remove the internal stator cables before rotation. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 71 – Connecting the grounding conductor (Page 74) – Introducing and routing the cables ... – Connecting cables ... 11.Screw in the two diagonally arranged threaded bars and slide the cover onto these bars. Take care not to damage the seal. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 72 20 Nm). Ensure that the minimum air clearances are observed. More information: Minimum air clearances (Page 84) 12.Reconnect the power supply cables. More information: – Connecting the grounding conductor (Page 74) – Introducing and routing the cables ... – Connecting cables ... SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 73: Mounting/Removing The Terminal Box
2. Slide the terminal box cover over the threaded bars onto the lower section of the terminal box. 3. Screw the screws into the free holes and tighten by hand. 4. Release the threaded bars. 5. Tighten all four M10 screws, tightening torque 40 Nm. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 74: Preparation
The grounding conductor cross-section of the machine must be in full conformance with the installation specifications, e.g. according to IEC / EN 60204-1. Table 6-2 Determining the cross-section of the grounding conductor Phase conductor cross-section S Cross-section of grounding conductor [mm²] [mm²] S > 35 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 75: Brought-Out Cables - Connection Without Terminal Box
Converter operation (Page 88) 6.3.4 Brought-out cables - Connection without terminal box If the machine was ordered with brought-out cables, i.e. without terminal box, then the proper connection must be made in an external terminal box. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 76: Connecting The Machine For A Specific Direction Of Rotation
● Ensure that there is a safe and reliable PE ground connection before starting any work. ● The connecting cables can be sealed and secured at every cable entry point into the terminal box. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 77: Bringing Cables Into The Terminal Box 1Xb
The terminal box is opened, the cable cut to the correct length and stripped back. Make sure that no external forces are acting on the cable connection. Image 6-7 Strain relief device and sealing insert SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 78: Bringing Cables Into The Terminal Box 1Xb
The connection cables are inserted into the terminal box via an exchangeable cable entry plate or cable entry support. The cable entry plate is drilled by default. The cable glands are not included in the standard scope of supply. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 79: Laying Cables
● Arrange the exposed connecting cables in the terminal box so that the PE conductor has excess length and the insulation of the cable strands cannot be damaged. ● Close off unused bushings with a metal threaded plug. This is the way to achieve a high frequency-proof shielding. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 80: Connecting Cables With Cable Lugs
Connecting cables without cable lugs Lug terminal connections - which are suitable for connecting flexible and stranded conductors without the use of wire end ferrules - may be installed if ordered accordingly. If you wish to SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 81 2. Prepare the end of the cable depending on the cable and its use. Make sure that no external forces are acting on the cable connection. 3. Insulate the conductor ends in such a way that the remaining insulation reaches almost up to the cable lug. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 82: Image 6-9 Connection Using Terminal Clamps (Schematic Diagram)
1XB7740 / 1XB7750 ① For terminal boxes GT640, 1XB7730 and 1XB7731, the terminal element is fastened using a terminal nut M12 on the threaded stud of the terminal support with a torque of 20 Nm. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 83: Use Of Aluminum Conductors
Between terminal box cover and terminal box enclosure, the cover fixing screws serve as equipotential bonding. A special external ground conductor is only installed if, for example, flat seals are mounted without additional support. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 84: Stepless Mating Face For The Seal In The Terminal Box Cover
When determining the required minimum air clearance, the voltage value in the table may be increased by a factor of 1.1, so that the rated input voltage range is taken into account during general use. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 85: Finishing Connection Work
Take the following criteria into account when selecting the connecting cables for the auxiliary circuits: ● Rated current ● Rated voltage ● System-dependent conditions, such as ambient temperature, routing type, cable cross- section as defined by required length of cable, etc. ● Requirements according to IEC/EN 60204‑1 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 86: Bringing Cables Into The Auxiliary Terminal Box And Routing Them
6. Make sure that the seal on the screwed sockets for the cable glands satisfies the degree of protection. 6.5.3 Connecting temperature monitoring for the stator winding The stator winding is monitored for thermal loading by temperature sensors embedded in the stator winding. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 87: Terminating The Connection Work (Auxiliary Circuit)
2. Close the auxiliary terminal box using the cover supplied for this purpose. See section "Tightening torques for screw and bolt connections (Page 157)" for the tightening torque of the fixing bolts for the cover. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 88: Converter Operation
≤ 500 V 1500 V 1100 V 750 V Rise time 0.5 μs Rise time 0.5 μs > 500 to 690 V 2250 V 1500 V 1125 V Rise time 0.4 μs Rise time 0.4 μs SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 89: Converter Operation On A Grounded Network
PE connecting points of normal terminal boxes are suitable for this purpose. Material damage can result. ● Use an appropriately sized PE conductor. ● Connect the PE conductor to the grounding terminal on the motor enclosure. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 90 Electrical connection 6.5 Connecting the auxiliary circuits SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 91: Start-Up
● Appropriately configured control and speed monitoring functions ensure that the motor cannot exceed the permissible speeds specified in the technical data. For this purpose, compare the data on the rating plate or, if necessary, the system-specific documentation. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 92: Measuring The Insulation Resistance Before Commissioning
● Can the machine be put into operation? ● Must the windings be cleaned or dried? Detailed information on testing and the limit values can be found here: "Testing the insulation resistance and polarization index" (Page 46) SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 93: Greasing The Roller Bearings Prior To Commissioning
3. Check the bearings before regreasing. If necessary, install new bearings. 4. Lubricate the bearings and reinstall the bearing components. See also Regreasing intervals and types of grease for operating roller bearings (Page 117) Stoppages (Page 107) Transport and storage (Page 34) SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 94: Setting The Automatic Regreasing System
°C. Set the values for shutdown and warning corresponding to the operating temperature T Table 7-2 Set values for monitoring the bearing temperatures Set value Temperature Alarm + 5 K ≤ 115 °C operation Shutting down + 10 K ≤ 120 °C operation SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 95: Set Values For Monitoring The Winding Temperature
Allow the machine to run down before switching it on again. 2. If the machine is running smoothly and evenly, switch on the cooling equipment. Continue to observe the machine for a while in no-load operation. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 96 If the vibration values in operation are not maintained in accordance with DIN ISO 10816-3, then the machine can be mechanically destroyed. ● During operation, observe the vibration values in accordance with DIN ISO 10816‑3. Note You can find more information in Chapter 2 of catalog D81.8. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 97: Switching Off
● You have installed the STARTER software with at least version 4.3.1 with SSP, and you are connected to the converter. You require SSP V4.6 for the SINAMICS G120P inverter. ● The STARTER program has been started. You are in the "Configuration" dialog screen form. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 98: Image 7-1 Selecting A Motor Type
2. Select the "Enter motor data" option. 3. In the "Motor type" field, select the entry "[14] SIMOTICS FD induction motor series". Image 7-1 Selecting a motor type 4. Click "Continue" to confirm your entries. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 99: Image 7-2 Entering The Motor Data
– The value for parameter p335 (motor cooling method) is encrypted from the motor order number: Motor order number Cooling method Parameter p335 1LL1 IC01 1LP1 IC06 1LM1/1MM1 IC411 1LQ1/1MQ1 IC416 1LH1/1MH1 IC71W 1LN1/1MN1 IC86W Image 7-2 Entering the motor data 6. Click "Continue" to confirm your entries. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 100: Commissioning At The Sinamics S/G Converter Using The Aop30
● Navigate within the selection fields using <F2> and <F3>. ● In the entry fields, you can either directly enter the required value or select it from a list. ● Activate the selection with <F5>. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 101 – The value for parameter p335 (motor cooling method) is encrypted from the motor order number: Motor order number Cooling method Parameter p335 1LL1 IC01 1LP1 IC06 1LM1/1MM1 IC411 1LQ1/1MQ1 IC416 1LH1/1MH1 IC71W 1LN1/1MN1 IC86W SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 102 Start-up 7.9 Setting the motor parameters at the converter 3. Exit the motor data input by selecting the "Continue" field and activating the selection with <F5>. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 103: Commissioning At The Sinamics G120P Inverter Using The Iop
– Motor voltage – Motor current – Rated power – Rated power factor cos φ – Motor speed The optimized pulse patterns are activated automatically once the "SIMOTICS FD" motor type is selected (p300=14). SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 104 Start-up 7.9 Setting the motor parameters at the converter SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 105: Operation
Certain parts of the machine become hot during operation. Severe burns can result from contact with these parts. ● Check the temperature of parts before touching them. If required, apply suitable protective measures. ● Allow the machine to cool before starting work on the machine. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 106: Switching On The Machine
● Comply with the limit values and/or ramp-up conditions specified in the catalog or the order documentation. 3. If this is possible using the available measuring equipment, check the bearing and stator winding temperatures. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 107: Switching Off The Anti-Condensation Heating
If the machine is to be taken out of operation for more than 12 months, suitable anti-corrosion, preservation, packaging, and drying measures must be taken. See also Transport and storage (Page 34) Start-up (Page 91) SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 108: Avoidance Of Condensation Or Formation Of Condensation Within The Machine
● Can the machine be put into operation? ● Must the windings be cleaned or dried? Detailed information on testing and the limit values can be found here: SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 109: Decommissioning The Machine
Immediately perform an inspection after such faults. Correct the cause of the fault as described in the respective remedial measures section. Repair any damage to the machine. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 110: Electrical Faults
Possible causes of faults Remedial measures Rotating parts are grinding Establish the cause and realign the parts. Rotor not balanced Decouple the rotor and then rebalance it. Rotor out of true, shaft bent Contact the Service Center. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 111 Reduced air supply, direction of rotation of fan Check the air ducts; clean the machine. possibly incorrect X Uneven gearbox operation Resolve any gearbox faults. Take into account possible changes which may occur during overheating. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 112: Roller Bearing Faults
Too much grease in bearing Remove surplus grease. Wrong grease in the bearing Use the correct grease. Friction marks on raceway Replace the bearing. Scoring (brinelling) Replace the bearing. Avoid any vibration at standstill SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 113: Maintenance
Machine damage If the machine is not maintained it can suffer damage. This can cause faults which can result in eventual or immediate death, serious injury or material damage. Perform regular maintenance on the machine. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 114: Measuring The Insulation Resistance During The Course Of Maintenance Work
It is therefore important to check the insulation resistance and the polarization index at the following times: ● Before starting up a machine for the first time ● After an extended period in storage or downtime ● Within the scope of maintenance work SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 115: Inspections In The Event Of Faults
Additional tests may also be required according to the system-specific conditions. NOTICE Machine damage When carrying out the inspection, if you detect any impermissible deviations from the normal state, you must rectify them immediately. They may otherwise cause damage to the machine. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 116: General Inspection
Service Center (Page 155). 9.1.7 Servicing the roller bearings When inspecting rolling-contact bearings, it is generally not necessary to dismantle the machines. The motor only has to be dismantled if the bearings are to be replaced. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 117: Roller Bearings With Automatic Regreasing System
The lubricating grease must satisfy the criteria listed in the table below and must match the operating conditions. Table 9-3 Criteria for selecting roller bearing greases Criteria Standard Property, characteristic value Unit Type of base oil Mineral oil Thickener Lithium SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 118 If you use greases that satisfy only the minimum requirements of DIN 51825 or ISO 6743-9, then reduce the lubrication intervals by half or adapt them as appropriate. If in doubt, consult the manufacturer. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 119 Avoid mixing greases. Only the manufacturer can provide a guarantee for the miscibility of particular greases. Regreasing Regreasing data are stated on the lubricant plate of the machine: ● Regreasing intervals in operating hours ● Regreasing amount in grams ● Grease type SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 120 The roller bearing temperature rises sharply at first, then drops to the normal value again after the excess grease has been displaced out of the bearing. 3. The used grease collects outside each bearing in a spent grease chamber. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 121: Sealing The Rolling-Contact Bearings ("Increased Degree Of Protection" Option)
Replacing a filter mat 1. Switch off the motor while changing a filter. 2. When replacing a filter, wear protective overalls, a mask to provide protection against fine dust as well as protective eyewear and gloves. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 122: Installing Filter Mats
3. Place the outer cage over the inner cage with the filter mat. Fix the outer cage using the centrally located screw, see Tightening torques for screw and bolt connections (Page 157), Case C. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 123: Touch Up Any Damaged Paintwork
Replace damaged components. Corrective Maintenance When carrying out any work on the machine, observe the general safety instructions (Page 15) and the specifications contained in EN 50110‑1 regarding safe operation of electrical equipment. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 124: Prepare Servicing Work
● Properly assemble or disassemble the machine. ● Use only suitable tools and equipment. ● Immediately replace damaged components. ● Contact the Service Center (Page 155), if necessary. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 125: External Fan
2. Ensure that the retaining components are undamaged and correctly installed. 9.2.2.2 External fan made of plastic External fans made of plastic feature a cast-on driver similar to a feather key. The external fan is secured using a locking ring to prevent axial movement. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 126: External Fan Made Of Welded Sheet Steel
2. Loosen the crews that fasten the fan impeller to the hub and pull the fan impeller off. 3. Warm up the fan hub, e.g. using a flame and pull the hot fan hub off with a puller. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 127: Roller-Contact Bearings
– First, remove the fan cowl (Page 125) or external fan cowl. – Remove the external fan (Page 125). Note For a schematic diagram of the respective component layout, see Section "Spare parts (Page 135)". SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 128: Remove V Ring
IP56 (non-heavy-sea). The protective ring does not have to be removed for disassembling the bearing bush. Remove the protective ring together with the V ring and the outer bearing cover or end shield from the shaft. See also Install the V ring (Page 131) SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 129: Removing The Labyrinth Sealing Ring
4. Screw suitable bolts or screws into the radial threads for pulling off. Note the length of engagement to avoid clamping to the shaft or damaging the thread. 5. Warm the labyrinth sealing ring as you pull it off. See also Installing the labyrinth sealing ring (Page 132) SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 130: Assembling The Rolling-Contact Bearings
13.Install the bearing shield or bearing housing together with the bearing shield. 14.Install the outer bearing cover if one is being used. 15.Install the sealing elements: If present: V ring (Page 131) Labyrinth sealing ring (special design) (Page 132) SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 131: Install The V Ring
9.2.3.6 Installing the V ring ("Increased degree of protection" option) The grease chamber of the labyrinth sealing ring together with the V ring ensures compliance with degree of protection IP65. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 132: Installing The Labyrinth Sealing Ring
1. Apply a soluble adhesive to the three set screws such as Loctite 243) and screw them partially into the labyrinth sealing ring. 2. Apply an corrosion protection paint to the shaft in the area of the labyrinth sealing ring. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 133: Seal The Motor
"Hylomar M". Follow the manufacturer's application and safety instructions when doing this. ● Check all sealing elements, such as those on the terminal boxes, for elasticity, aging or damage, and renew them if they are no longer effective. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 134 Maintenance 9.2 Corrective Maintenance SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 135: Spare Parts
The anti-condensation heater is mounted directly on the winding. The anti-condensation heater cannot be removed without causing damage to the winding. A new anti-condensation heater may only be installed by Siemens Service Center (Page 155) specialists. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 136: Housing, Stators And Rotors
Lifting lugs 20.00 Terminal box without cable entry See also Terminal box 1XB1621 (Page 142) Terminal box 1XB7730 (Page 145) Terminal box 1XB7731 (Page 146) Terminal box 1XB7740 (Page 147) Terminal box 1XB7750 (Page 148) SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 137: Ventilation
Spare parts 10.5 Ventilation 10.5 Ventilation Table 10-2 Spare parts for ventilation Part Description 11.00 External fan 12.00 Complete fan cowl SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 138: Air Filter
Spare parts 10.6 Air filter 10.6 Air filter Table 10-3 Spare parts air filter Part Description 34.30 Spare part kit filter 34.32 Filter mat SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 139: Roller Bearing Cartridge At The Drive And Non-Drive End
Bearing kit at the drive end and non-drive end consists of the following components Deep-groove ball bearing (locating bearing) Deep-groove ball bearings Shaft sealing ring, labyrinth ring (optional) Shaft sealing ring Locking ring, guard ring Locking ring SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 140: Roller Bearing Cartridge At The Drive And Non-Drive End
Bearing kit at the drive end and non-drive end consists of the following components Deep-groove ball bearing (locating bearing) Deep-groove ball bearings Shaft sealing ring, labyrinth ring (optional) Shaft sealing ring Locking ring, guard ring Locking ring SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 141: Speed Sensor (Optional)
10.9 Speed sensor (optional) 10.9 Speed sensor (optional) Table 10-6 Spare parts, speed sensor assembly Part Description 55.10 Speed sensor kit (sensor, torque bracket, fastening material) The speed sensor kit can be ordered only as complete kit. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 142: Terminal Box 1Xb1621
Terminal box 1XB1621 spare parts Part Description Part Description 20.00 Terminal box without cable entry comprising the following components: 20.20 Terminal box housing 21.41 Terminal supports 20.27 Mounting rail 21.61 Terminal strip for auxiliary circuit SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 143 Cable gland 20.66 Strain relief - lower part 20.61 Cable gland - upper part 20.68 Seal 20.62 Cable gland - lower part 20.70 Sealing insert for cable entry 20.65 Strain relief - upper part SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 144: Terminal Box 1Xb1631
20.30 Cover 22.43 Terminal link, stepped with two holes 20.38 Cover seal 22.70 Fixing lug for PE conductor 20.86 Entry for auxiliary cable You can order the terminal box just as one component. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 145: Terminal Box 1Xb7730
Seal 22.39 Neutral point connection 21.11 Connecting plate with internal cable 22.70 Fixing lug for PE conductor 21.41 Terminal bushings Table 10-10 Additional spare parts Part Description Part Description 20.51 Entry plate with seal SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 146: Terminal Box 1Xb7731
Connecting plate with internal cable 22.41 Terminal link, straight with two holes 21.41 Terminal bushings 22.70 Fixing lug for PE conductor Table 10-12 Additional spare parts Part Description Part Description 20.51 Entry plate with seal SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 147: Terminal Box 1Xb7740
21.11 Connecting plate with internal cable 22.39 Neutral point connection 21.41 Terminal bushings 22.70 Fixing lug for PE conductor Table 10-14 Additional spare parts Part Description Part Description 20.51 Cable entry plate with seal SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 148: Terminal Box 1Xb7750
22.01 Saddle terminal, complete 20.50 Cable entry plate 22.30 Connecting bar for main current 20.58 Seal 22.39 Neutral point connection 20.59 Spacer 22.70 Fixing lug for PE conductor 21.11 Connecting plate with internal cable SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 149: Auxiliary Terminal Box 1Xb9014
Auxiliary terminal box 1XB9014 Image 10-11 Auxiliary terminal box 1XB9014 Note The auxiliary terminal box can only be ordered as one complete part, single parts are not available. Contact the Siemens Service Center (Page 155). SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 150: Auxiliary Terminal Box 1Xb9015
Auxiliary terminal box 1XB9015 Image 10-12 Auxiliary terminal box 1XB9015 Note The auxiliary terminal box can only be ordered as one complete part, single parts are not available. Contact the Siemens Service Center (Page 155). SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 151: 1Xb9016 Auxiliary Terminal Box
1XB9016 auxiliary terminal box Image 10-13 1XB9016 auxiliary terminal box Note The auxiliary terminal box can only be ordered as one complete part, single parts are not available. Contact the Siemens Service Center (Page 155). SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 152: Auxiliary Terminal Box 1Xb302
Auxiliary terminal box 1XB302. Image 10-14 Auxiliary terminal box 1XB302. Note The auxiliary terminal box can only be ordered as one complete part, single parts are not available. Contact the Siemens Service Center (Page 155). SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 153: Disposal
The machine is made up of heavy parts. These parts are liable to fall during dismantling. This can result in death, serious injury or material damage. Before you release any machine parts, secure them so that they cannot fall. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 154: Disposal Of Components
● Wooden packaging for sea transport consists of impregnated wood. Observe the local regulations. ● The foil used for water-proof packaging is an aluminum composite foil. It can be recycled thermally. Dirty foil must be disposed of via waste incineration. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 155: Service And Support
(www.siemens.com/yourcontact) Siemens Support for on the move You can obtain optimum support anywhere you go using the "Siemens Industry Online Support” app. The app is available for Apple iOS, Android and Windows Phone. SIMOTICS FD 1LL1...
Page 156 Service and Support SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 157: Technical Data And Drawings
Table B-1 Tightening torques for screw/bolt connections with a tolerance of ±10% Case 1080 1700 2600 4200 1200 2000 3100 4700 7500 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 158 Non-standard tightening torques Different tightening torques for electrical connections and bolted connections for parts with flat seals or insulating parts are specified in the relevant sections and drawings. See also Securing the rotor (Page 36) SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 159: Quality Documents
Quality documents You can find the quality documents here: https://support.industry.siemens.com/cs/ww/de/ps/13318/cert (https:// support.industry.siemens.com/cs/ww/en/ps/13318/cert) SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 160 Quality documents SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 161: Additional Documents
Additional documents Additional documents on CD The documentation for components from other manufacturers that are installed in the machine can be found on the CD. SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 162 Additional documents D.1 Additional documents on CD SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 163: Index
Center of gravity, 35, 55 Emitted interference, 20 Centering flange, 61, 62 End shield, 128 Checks to be carried out prior to commissioning, 91 Equipotential bonding, 83 Common-mode filters, 43 Equipotential bonding conductor, 42 Condensate, 56, 106 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 164 Faults, 109, 115 Output element, 53 Installation Overspeed, 29 Initial inspection, 115 Installing filter mats, 122 Installing the protective ring, 131 Insulated bearings, 25, 43 Paint system, 123 Insulated coupling, 44 Paintwork damage, 123 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 165 Rotor shipping brace, 36, 39, 51 Support base, 32 Remove, 50 Switching on, 95, 106 Rotor winding, 23 System resonances, 33 System-inherent frequencies, 33 Safety instructions Flammable substances, 17 Tandem operation, 44 Hazardous substances, 17 Technical Support, 155 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 166 Type of balancing, 52 V ring, 128, 131 Ventilation, 24 Vibration values, 33, 96 Voltage via the converter, 88 Wall faces, 49 Wall mounting, 49 Winding temperature Monitoring, 95 Set values, 95 Wire end ferrules, 81 SIMOTICS FD 1LL1 Operating Instructions 04/2016...
Page 168 Siemens AG Process Industries and Drives Postfach 48 48 90026 NÜRNBERG GERMANY www.siemens.com/drives...

Siemens SIMOTICS FD 1LL1 Operating Instructions Manual

Quick Links

Related Manuals for Siemens SIMOTICS FD 1LL1

Summary of Contents for Siemens SIMOTICS FD 1LL1

Table of Contents
