FRONT PANEL:

Reset: Use to reset the device settings. When the Reset button icon, and the surrounding ring are illuminated, press and hold the button for 4 seconds to initiate a
power cycle. If the lights are not lit, the device can be factory reset. Press and hold the button for 10 seconds to reset the device to factory default settings. Note:
When the button and ring are lit, a power cycle must be performed prior to performing a factory reset.
•

INSTALLING THE MODEM

1. Connect the coaxial cable (not supplied) to the Cable connector on the rear panel
of the modem and connect the other end to the cable wall outlet. Do not bend or
over tighten the cables, as this may strain the connector and cause damage. To
connect a modem and a television to the same wall outlet, you must use a cable
line splitter (not included).
2. Connect the Ethernet cable (supplied) to a Ethernet port on the back panel of the
modem and connect the other end to the Ethernet port of a PC. Use a Category 5e
or Category 6 Ethernet cable with RJ-45 connectors to ensure Gigabit Ethernet
speeds (if the computer supports it).
3. Connect an RJ-11 phone cable (not supplied) to the Voice 1 or 2 port on the
modem (when provisioned for voice service as specified by the service provider),
and connect the other end to the phone port of the telephone. If voice service is
not provisioned through the service provider, telephone service is not available.
4. Connect the power adapter (supplied) to the Power port on the modem. Connect
the other end to a power outlet.
