Summary of Contents for Auto Vox M8
- Page 1 AUTO-VOX M8 Touch Screen Mirror Dash Camera...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Chapter 1 Chapter 3 Precautions............... Wiring at a Glance..........Warning..............Installing Touch Screen Dash Cam......Warranty..............Installing Backup Camera........Wire Connection Steps.......... Chapter 2 Testing..............Main Features............Wire Routing............Touch Screen Dash Cam at a Glance..... Chapter 4 Turning on the Touch Screen Dash Cam.... -
Page 4: Chapter 1 Precautions
Note： 1. AUTO-VOX shall not be liable for any damages of any kind resulting from the purchase or use of the product of arising from the breach of the express warranty, including incidental, special or consequential damages, or loss of anticipated profits or benefits. -
Page 5: Chapter 2 Main Features
Chapter 2 MAIN FEATURES • 1296P 6 glass lens front camera recording • 180°horizontal super wide angle back up camera(without recording) • With LDWS (lane departure warning system) • Touch Screen and User's friendly menu interface • 6.86" wide display view TOUCH SCREEN DASH CAM AT A GLANCE Lens Reset... -
Page 6: Turning On The Touch Screen Dash Cam
Micro-phone Micro-SD Slot Mini USB Port Right Left O/M Button AV-IN（to connect rear view camera) Note: Functions for those button Left: Press to lock the video in Emergency folder. Press and hold for 3 sec to capture. O/M button: Press O/M button, LCD screen will be off meanwhile the dash cam still records. Press O/M button again, LCD screen will show meanwhile the dash cam still records. -
Page 7: Lcd Screen Saver Setting
3. Format the micro SD card on PC Take out the SD card and insert it to a car reader, and then connect to the PC to format. Note: If you use a 64 GB SD card, please format it on PC to FAT32. We suggest to format each week. FIRMWARE UPDATE Please contact our customer service at service@auto-vox.com for newest firmware. -
Page 8: Installing And Removing Sd Card
Insert Micro SD (class 10 or higher with FAT 32) in to the card slot making sure to follow correct orientation markings. Push the card until it clicks into place. Do not remove or insert the memory card when dual dash cam M8 is powered on since it may damage the card. - Page 9 Movie Mode • Select resolution: 1296P, 1080P, 720P Movie Mode 1296P 1080P 720P Movie Quality • Select Super Fine or Fine Movie Quality Super Fine Fine...
- Page 10 Movie Clip Time • Select the duration of each video: 1, 2, 3 minutes. • After setting it , the device will continue to record by overwriting the previously recorded video and replacing it with the new video. Movie Clip Time 1 min 2 min 3 min...
- Page 11 Sound Record • If you don't want to record sound ,please choose OFF. Note: When play back video by dash cam, sound can be played. But couldn't play on PC, please use video player VLC. Sound Record Beep • Select On or off. •...
- Page 12 Power Off • Select: Never, 1 min, 5min • When the dash cam is powered by car battery, the dash cam will power off automatically after stopping recording. Note: If parking monitoring function is on, it will not power off automatically even set 1 or 5 min. Power Off Never 1 min...
- Page 13 Select Stamp format • Set up the stamp format in your videos and pictures. Stamp Date+Logo Date Logo Flicker • Select the right frequency from 50Hz or 60Hz. Flicker 50 Hz 60 Hz...
- Page 14 LCD Power Save • May select 15,30 sec and 1 min. Default is 30 sec. • If you don't need the screen to display when driving, please set it. Though the screen is off, the dash cam still records, and the screen will be on automatically again when reversing.
- Page 15 Protect Level • Select with off, Level 0,Level 1, Level 2, Level 3, Level 4 • Note: This function works when the road is bumpy and mirror is vibrating during recording, the video file will be locked in Emergency folder. In those conditions, we recommend to set off.
- Page 16 Parking Monitoring • Select Off, High, Middle, Low. • When driving, please select Off. Parking Monitoring High Middle Reset Setup • If all setting need to be deleted, please touch "Yes". Back Reset Setup Reset Setup?
- Page 17 Language • Choose the language you need. Backing-up Line If you need guide line when reversing, please select On. FW Version • Touch this setting to find your newest firmware. Browse (Playback) Video Type: Normal, Parking, Emergency 1. Select the image or video you want to view, and then click the screen to play it. 2.
-
Page 18: Backup Camera At A Glance
BACKUP CAMERA AT A GLANCE Chapter 3 WIRING AT A GLANCE Car Cigarette Lighter AV-IN（to connect rear view camera) To ground (iron part) Micro-SD Slot Mini USB Port To reversing light +12V... -
Page 19: Installing Touch Screen Dash Cam
1. M8 dash cam working voltage: 5V 1.5A ; Please use standard car charger to supply the power for M8, or it will cause damage to the device. 2. If M8 shakes slightly, you might try the next slot on the bands, mirror sizes vary a lot. -
Page 20: Installing Backup Camera
INSTALLING BACKUP CAMERA ABC123 ABC123 Step1 Loose the screws on the license plate with wrench. Step1 Take off the license plate with wrench. Step2 Install the camera bracket behind the license plate. Step2 Find a best location and make a mark. ABC123 ABC123 Step3... -
Page 21: Wire Connection Steps
WIRE CONNECTION STEPS 1. Connect the red wire to the reverse light (positive) and the black wire to the ground (iron part of the car) 2. Open the inner plastic panel and remove it from the hatch or tailgate. (The panels are usually attached on the tailgate by clips. It may take a bit longer time to avoid clip damages. -
Page 22: Testing
TESTING Before routing the video cable, connect the monitor and put the car gear to reversing and see whether it is working. WIRE ROUTING After Testing, route the video cable as the picture below (two ways of routing are available). Attach rearview mirror Install rearview camera... -
Page 23: Technical Specification
Section 4 TECHNICAL SPECIFICATION Mirror Specification Touch Screen Mirror Dash Cam Display Screen Size 6.86”IPS Screen Lens F2.05 mega-pixel, 140°wide angle RESOLUTION Ratio SHD1296P,FHD1080P,HD720P Image Format Video Format Lane Departure Warning System Support Loop Recording Support with 1,2,3minutesng Taking Photo Support Backup Camera Support... - Page 24 Parking Mode Support Support Play back Audio Recording Support Current Frequency 50Hz/60Hz USB Function 1:USB-Disk 2:PC-Camera Working Temperature -20 ~ +70℃ (-4 ~158℉) Storage Temperature -30 ~ +80℃ (-22~176℉) Micro SD Support to 64G TF card with Class10and FAT32 Working Voltage DC5V 2A Battery Type Polymer Lithium Battery...
- Page 25 Backup Camera Specification Sensor 1/3 " Color CMOS Sensor Lens 6 glass lens TV System PAL( ) NTSC (√ ) S/N Ratio More than 40dB Effective Pixels 960(H)X576(V) Working Current 100mA ±10mA Resolution 700 TV lines Power supply DC 12V±10% Horizontal Angle 175°±...
-
Page 26: Chapter 5 Trouble Shooting
Section 5 TROUBLE SHOOTING Reasons&Solutions: a. the SD Micro card isn’t inserted; b. SD card class is too low, Unable to record videos and a genuine high-speed card should be better; c. Micro SD card is broken, and you should use a new one.ux Reasons&Solutions: a. - Page 27 Ver-2.0...
- Page 28 Email: service@auto-vox.com...
