- Page 1 1.003 Wireless subsystem repeater U-PROX HW Installation and programming manual...
-
Page 2: About This Document
About this document his manual covers installation, adjustment and use of U-PROX HW (hereinafter repeater) wireless access control system repeater. Read this manual carefully prior to installing the system. Characteristics, Intended use and parameters of the repeater are described in the section "Summary". -
Page 3: Table Of Contents
Communicator operation ....................7 Wireless lock system architecture ................10 Wireless lock system deployment ................11 Server addresses automatic configuration for U-Prox IC L ........12 U-Prox IC L addresses automatic configuration for repeaters ........13 U-Prox IP500 automatic configuration..............14 How to work with the device .................. -
Page 4: Brief Description Of The Repeater
Brief description of the repeater U-PROX HW repeater - a device designed to extend the range of the wireless subsystem of U-Prox IP access control system. Repeater operates with U-Prox IC L access control panel and U-Prox IP500 wireless battery powered escutcheons. -
Page 5: Terms
Terms Identifiers In access control systems each user has a unique RF ID. Identifiers can take the form of a plastic card, key FOB etc. Access point (AP) Access point is a logical concept of the access control system implying control of passing through a door in one direction. -
Page 6: Description And Operation
The look of the repeater is shown in Fig. 1 The Enclosure Panel board Connectors Fig. 1. U-Prox HW repeater Location of connectors on repeater board and their function is shown in Fig. 2 Figure 2. U-Prox HW board Assignment of the repeater contacts and indication... -
Page 7: Light Emitting Diode
Repeater goes to the “Normal” mode after downloading the configuration. To return to the factory settings use the command from the U-Prox software or with the routine described in Service Maintenance section. In the Normal mode repeater processes information from U-Prox IP500 panels received through the built-in wireless ISM band interface and transmits it to U-Prox IC L through Wi-Fi and local computer network. - Page 8 Fig. 3. Mixed type (Ethernet & Wi-Fi) local network connection example Where U-Prox HE - repeater designed to expand the scope of the ISM band wireless interface. To connect to the network use Ethernet (wired computer network).
- Page 9 It is highly recommended to use routers with two different technology Internet access channels for redundancy. For wireless communication channel (Wi-Fi) redundancy U-Prox HW supports operation with two Wi-Fi access points (main and backup) see Fig. 5. Fig.5 Redundancy in Wi-Fi network...
-
Page 10: Wireless Lock System Architecture
U-Prox HE and U-Prox HW repeaters. The U-Prox access control system server, U-Prox IC L, U-Prox HE and U-Prox HW communicate each other via the computer network. The U-Prox IC L, U-Prox HE and U-Prox HW communicate to the U-Prox... -
Page 11: Wireless Lock System Deployment
The deployment is made in three steps (see Fig. 7.): U-Prox IC L control panel connection U-Prox HW repeaters connection U-Prox IP500 wireless panels connection... -
Page 12: Server Addresses Automatic Configuration For U-Prox Ic L
Fig. 7. Wireless lock system deployment The algorithms for operation on each step described below Server addresses automatic configuration for U-Prox IC L Panel checks for DHCP mode ON (panel address 0.0.0.0) or static IP If DHCP mode is ON, the dynamic IP address obtain routine will start... -
Page 13: U-Prox Ic L Addresses Automatic Configuration For Repeaters
Despite it is broadcast announcement, it is limited with one range local network and active network equipment. That’s why the IP addresses of the U-Prox IC L panel are to be set manually for networks with sophisticated topology. The system will warn operator after the receiving of the data package from the new repeater through the U-Prox IC L panel. -
Page 14: U-Prox Ip500 Automatic Configuration
U-Prox IP500 automatic configuration U-Prox IP500 announces itself in the ISM band after the power-up If U-Prox IP500 does not connected to anyone U-Prox IC L the automatic configuration mode will start: Panel will broadcast data packages announcing itself as a new... -
Page 15: Mount Recommendations
Internet network with route backup possibility via the second redundant router U-Prox HW repeater operates in automatic mode. It routes event message data from the allowed U-Prox IP500 wireless panels to U-Prox IC L panels connected to the Ethernet computer network after the configuration data download. -
Page 16: Repeater Program Order
Adjust communication to the server (no need in automatic configuration mode): Server 1 IP or DNS name of U-Prox IC L control panel Access ports (write port and read port) Test message frequency Repeater program order Software... -
Page 17: Service Maintenance
Service maintenance Return to factory settings To return to factory settings: De-power repeater Press and hold FUNC button Supply power to repeater Wait for 10 seconds, until LED diode lights and release FUNC button LED diode will flash 6 times that means factory settings restored...
