INTRODUCTION
DPS series programmable power supply provides continuous adjustable output voltage and current as well as
automatic shift between constant voltage and current. It features with high stability & reliability, high accuracy, 4
groups memories by using digital technology, panel lock, output ON/OFF function, voltage & current limit setting
with password, and intelligent temperature control and alert function.
DPS series power supply has three outputs: two with adjustable output voltage and one fixed output voltage
(2.5V, 3.3V, 5V selectable, for DPS-3033GL-3 only).The two adjustable outputs provide both manual and
programmable control modes. When it is turned on, the unit is default) and in manual model. Pressing TIMER
button to set parameters. Pressing RUN or STOP button to turn on or off programmable control output.
As a constant voltage (CV) and constant current (CC) source, DPS series is able to, even at the maximum
output current, provides a fully rated and continuously adjustable output voltage. For a big load, DPS series can be
used as a CV source, the output current can be adjusted via a current regulator on the front panel; when used as a
CV source, the maximum output voltage can be controlled via voltage regulator on the front panel. That is to say,
the power supply will automatically shift from CV source to CC source when the output current reaches the target
value.
CAUTION:
！
1. The power supply must be operated under the rated line voltage. If the power supply is meant
to work for a long time, it is suggested to use 60%~70% load to as to avoid rapid aging.
2. Avoid frequent short-circuit operations.
3. Do not turn on the power supply when the output terminal is with heavy load. Turn the output
voltage adjustment knob to the lowest value, next connect the load, and then turn on the power
supply. Adjust the voltage/current adjustment knob to set the wanted values.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Matrix DPS Series
Summary of Contents for Matrix DPS Series
- Page 1 Pressing RUN or STOP button to turn on or off programmable control output. As a constant voltage (CV) and constant current (CC) source, DPS series is able to, even at the maximum output current, provides a fully rated and continuously adjustable output voltage. For a big load, DPS series can be used as a CV source, the output current can be adjusted via a current regulator on the front panel;...
- Page 2 2. GENERAL AND PRODUT MODELS 2.1 General Power source: 110V/220V±10%, 50/60Hz Operation environment: Indoor use Altitude: <2000m Temperature: 1 ℃~40℃ Relative humidity: <80% Category: II Pollution degree: II Storage temperature: -10℃~70℃ Weight: 7.0kgs DPS-3033GL-3, 8.0kgs for DPS-3055GL-3&DPS-6022GL-3 Dimension: 300L*220W*148H (mm) 2.2 Accessories Power cord: 1pcs Users manual: 1 pcs...
-
Page 3: Specification
DPS-3055GL-3 & DPS-6022GL-3: CH1&CH2 output power limit within 100W. 3. SPECIFICATION Technical specifications of DPS series should be tested in 30 minutes after unit warm up. Testing environment: +20 ℃~+30℃ Specifications are subject to changes without notice. - Page 4 Model DPS-3033GL-3 DPS-3055GL-3 DPS-6022GL-3 Output 0~30V/3Ax2 0~30V/5Ax2 0~60V/2Ax2 Model DPS-3033GL-3 DPS-3055GL-3 DPS-6022GL-3 Constant Voltage Operation Output 0~30V/3Ax2 0~30V/5Ax2 0~60V/2Ax2 Line regulation CV≤0.01%+3mV CV≤0.02%+3mV CV≤0.02+5mV Empty load 10mS~250mS 10mS~250mS 10mS~250mS Rising time Load regulation 0.5A load CV≤0.01%+3mV 10mS~250mS CV≤0.02+5mV 10mS~250mS CV≤0.02+5mV 10mS~250mS Recovery time ≤100µS (50% load change, minimum load 0.5A)
-
Page 5: Safety Instruction
Voltage range 2.5V, 3.3V, 5V selectable Output current Between base and output terminal ≥20MΩ/500V DC Insulation degree Between base and power cord ≥30MΩ/500V DC Display accuracy 3 & 1/2 digits LED display ≤±0.5%+2d 4. SAFETY INSTRUCTION... - Page 6 This section contains important safety instructions. Read the following before any operation to ensure your safety and to keep the best condition for the power supplies. 4.1 Safety Symbols The following symbols may appear in the manual or on the products: DANGER High Voltage ATTENTION refer to Manual Protective Conductor Terminal...
- Page 7 4.2 Safety Guidelines Operation to power outlet and power cord: please use polarized power cord and polarized power outlet for the instrument to ensure the case, output terminal are properly grounded. To avoid damage, don’t remove the upper case, front or rear panel during operation to the power supply. Do not touch the upper case or rear panel (heat sink).
- Page 8 4.3 About AC Input Voltage The AC input voltage for DPS series is 110V/220V selectable±10%, 50/60Hz. When the power source is higher than the rated voltage by +10%, please set the output current to 70%~80% of the rating output current to...
-
Page 9: Panel Instruction
5. PANEL INSTRUCTION 5.1 Front Panel... - Page 10 1) POWER : Power switch. 2) Meter V : Displays CH1 output voltage. 3) Meter V : Displays CH2 output voltage. 4) Meter A : Displays CH1 output current. 5) Meter A : Displays CH2 output current. 6) CV indicator: It turns on when CH1 is under constant voltage. 7) CV indicator: It turns on when CH2 is under constant voltage.
- Page 11 programmable point is invalid when under manual mode. 13) TIMER: It is used to set the programmable parameter T and displays current switch. When setting the programmable parameter T, the current meter displays the target time value. The TIMER button background light and Sec. & Min. indicators turn on. Adjust the time by second and minute respectively using the VOLTAGE and CURRENT knob.
- Page 12 19) VOLTAGE: It is used to adjust the voltage of CH1 and CH2. Pressing TIMER button, it is used to adjust the time by minute. 20) CURRENT: It is used to adjust the current of CH1 and CH2. Pressing TIMER button, it is used to adjust the time by second.
- Page 13 5.2 Rear panel...
- Page 14 31) Power outlet. 32) Fuse holder. 33) Voltage selector(selects suitable voltage according to different regions.) 34) Cooling fan: reduce the inside temperature of the power supply to keep it at best condition. 6. OPERATION INSTRUCTION 6.1 Power source According to local use, select suitable input voltage via the voltage selector. The input voltage is 110V/220V selectable ±10%, 50/60Hz.
- Page 15 Set and store programmable points (CH, V, I, T) One programmable point consists of point position (i.e. address of the programmable point) and its parameters (i.e. voltage V, current I and running time T). DPS series power supply has four programmable points.
- Page 16 These points are to be stored in memory unit 1 2 3 4 respectively. A. Select channel: In manual mode, pressing CH1 or CH2 switches to correspondent channel. B. Set targeted voltage, current and time value: In manual mode, after selecting one channel, set the targeted voltage and current value by rotating their corresponding knobs.
- Page 17 still keep output. Turned off LOCK button, programs runs from start point”1” to end point”4”, then stop running and output is also turned off. C. Demo: In the process of running program, when turned OUTPUT on, the program is demonstrating accompanied with power output;...
- Page 18 seconds) Set and save voltage, current, time of point “1” and point “3” separately at 5V,1A, 3 seconds, using the same way, set point”2” and point “4” at voltage of 0V, current at 1A, time at 3 seconds, then turned on OUTPUT and RUN/STOP button.
- Page 19 b. Connect load to the CH3 positive and negative output terminal. c. Press OUTPUT key to turn on output. d. When the output current is over rating 3A(overload), the overload turns red, and the output voltage and current gradually turns down to enable protection. To restore the CH3 output, lower the load and make the output current less than 3A until the overload indicator turns off.
- Page 20 The DPS series automatically switches between constant voltage (CV) and constant current (CC) mode according to load condition. That is to say, when the output current reaches targeted value, DPS series will automatically switch to constant current mode; and vice visa. The CV mode and CC mode switch point is called...
- Page 21 For example, if connect a load to the DPS series to make it work under CV mode to provide targeted output voltage, the output voltage keeps at a certain rating voltage level. Then increase the load to make the DPS series reach current limit point.
- Page 22 output voltage higher than the amplified voltage of U113, U114 will reduce the output voltage. Relay controls circuits; mainly for the purpose of reduce their loss...
- Page 23 To avoid electric shock, please refer to the following operations to qualified personal only. 7.1 The DPS series have complete current limit protection. When the output terminal is short, the output current will be limited at maximum rating and will not be increased any more. However, there still be high power loss on the transistor.
