Exploded View Arc Mini R2
1.
Front fan filter
2.
Fan controller switch
3.
2 x USB 3.0
4.
Removable/rotatable upper HDD cage
5.
Removable lower HDD cage
6.
HDD tray with silicone anti-vibration grommets
7.
Removable top panel with dust filter
8.
Top panel radiator mounting
9.
SSD mounts behind M/B plate
10.
Window side panel
