Graco Cozy Cline Step 2 Buckle Replacement Manual

www.gracobaby.com
To Remove Existing Harness Tongues and Buckle and Attach Replacement Buckle
You will receive ONE of
these Graco approved
replacement buckles.
Follow instructions for
proper installation.
3
From the side of the seat, pull
the harness and metal
junction plate out and remove
straps from metal junction plate.
6
Unbuckle
harness.
10
Re-insert straps through slots
in seat pad and seat back.
See carseat owner's manual for inserting
the straps into the correct set of harness
slots for your child.
Cozy Cline
Buckle Replacement Guide
1
To loosen straps, lift
lever and pull harness
straps.
4
Pull harness straps
through seat back
and seat pad.
7
Remove and
discard tongues.
Toddler SafeSeat-Step 2
®
2
Recline the seat by
squeezing the recline
lever up and pulling the
seat forward.
8
Slide NEW buckle onto
harness straps. MAKE
sure not to twist straps.
11
Insert harness straps
as shown.
©2014 Graco PD272898C 5/14
5
Remove chest clip.
DO NOT DISCARD
the chest clip.
9
Turn page over to
finish the rest of
the assembly
Steps 12 to 16
for the buckle
replacement.
Re-attach chest clip.
MAKE sure not to
twist straps.
