  • Page 1 User’s Manual L40 Series computers.toshiba-europe.com...
  • Page 2 © 2007 by TOSHIBA Corporation. All rights reserved. Under copyright law, this manual cannot be reproduced in any form without the prior written permission of TOSHIBA. No patent liability is assumed, with respect to the use of the information contained herein.

  • Page 3: Eu Declaration Of Conformity

    EU Declaration of Conformity This product is carrying the CE-Mark in accordance with the related European Directives. Responsible for CE-Marking is TOSHIBA Europe GmbH, Hammfelddamm 8, 41460 Neuss, Germany. The complete and official EU Declaration of Conformity can be found on TOSHIBA’s web site...

  • Page 4: Optical Disc Drive Safety Instruction

    In other countries, the drive is certified to comply with the requirement pursuant to IEC 825 and EN60825 on class 1 laser product. Depending on the model, the computer is equipped with one of the optical drives mentioned on the next pages. User’s Manual L40 Series...
  • Page 5 TOSHIBA Samsung Storage Technology Korea Corporation CD-RW/DVD-ROM TS-L462D ■ The CD-RW/DVD-ROM drive employs a laser system. To ensure proper use of this product, read this instruction manual carefully and retain for future reference. Should the unit ever require maintenance, contact an authorized service location.
  • Page 6 ■ Use of controls, adjustments, or procedures other than those specified may result in hazardous radiation exposure. ■ To prevent direct exposure to the laser beam, do not try to open the enclosure. User’s Manual L40 Series...
  • Page 7 ■ Use of controls, adjustments, or procedures other than those specified may result in hazardous radiation exposure. ■ To prevent direct exposure to the laser beam, do not try to open the enclosure. User’s Manual L40 Series...
  • Page 8 ■ Use of controls, adjustments, or procedures other than those specified may result in hazardous radiation exposure. ■ To prevent direct exposure to the laser beam, do not try to open the enclosure. User’s Manual L40 Series viii...
  • Page 9 ■ Use of controls, adjustments, or procedures other than those specified may result in hazardous radiation exposure. ■ To prevent direct exposure to the laser beam, do not try to open the enclosure. User’s Manual L40 Series...

  • Page 10: International Precautions

    To prevent direct exposure to the laser beam, do not try to open the enclosure. CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED IN THE OWNER'S MANUAL MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. L40 Series...

  • Page 11: General Precautions

    General Precautions TOSHIBA computers are designed to optimize safety, minimize strain and withstand the rigors of portability. However, certain precautions should be observed to further reduce the risk of personal injury or damage to thecomputer.
  • Page 12 Pressure or impact damage Do not apply heavy pressure to the computer or subject it to any form of strong impact as this can damage the computer's components or otherwise cause it to malfunction. User’s Manual L40 Series Getting Started,...

  • Page 13: Instruction Manual For Safety And Comfort

    Instruction Manual for Safety and Comfort All important information on the safe and proper use of this computer is described in the enclosed Instruction Manual for Safety and Comfort. Be sure to read it before using the computer. User’s Manual L40 Series xiii...

  • Page 14: Table Of Contents

    Table of Contents L40 Series Features Chapter 1 Features..........1-1 Special features .
  • Page 15 TOSHIBA Disc Creator ........4-19...
  • Page 16 TOSHIBA support ........

  • Page 17: Manual Contents

    It is designed to provide years of reliable, high-performance computing. This manual gives information on setting up and using your L40 Series computer. It also provides detailed information on configuring your computer, basic operations and care, using optional devices and troubleshooting.

  • Page 18: Key Operation

    When procedures require an action such as clicking an icon or entering text, the icon’s name or the text you are to type in is represented in the type face you see to the left. L40 Series xviii...

  • Page 19: Equipment Checklist

    Carefully unpack your computer. Save the box and packing materials for future use. Check to make sure you have all the following items: Hardware ■ L40 Series Portable Personal Computer ■ Universal AC Adapter and Power Cord ■ Modular cable for modem (provided with some models) User’s Manual...

  • Page 20: Documentation And Backup Media

    The system may not function properly if you use drivers that are not preinstalled or distributed by TOSHIBA. SD Memory Card Format Utility and other SD functions are packaged into TOSHIBA SD Memory Utilities. When uninstalling the SD utilities, click Start Control Panel Memory Utilities.

  • Page 21: Chapter 1 L40 Series Features

    Basic features are described in a separate pamphlet. Some of the features described in this manual may not function properly if you use an operating system that was not preinstalled by TOSHIBA. Features For the configuration details on your purchased model, visit your region’s TOSHIBA website.

  • Page 22: Main Memory

    (1) month. section in Chapter 9. The computer has an internal battery to back up its Real Time Clock (RTC), calendar, and setup information. This battery will last for at least one month without external power source. L40 Series Features...

  • Page 23: Display (Lcd)

    Depending on the model purchased, one of the following drives will be installed: 60.0 billion bytes (55.88GB) 80.0 billion bytes (74.51GB) 120.0 billion bytes (111.76GB) 160.0 billion bytes (149.01GB) 9.5mm/2.5" hard disk drive support L40 Series Features Disclaimers Display Modes section in...
  • Page 24 CDRWs at up to 24 speed. This drive supports the following formats: ■ ■ DVD-ROM ■ ■ CD-R ■ ■ CD-DA ■ Photo CD (single/multi-session) ■ CD-ROM Mode1, Mode2 ■ CD-ROMXA Mode2 (Form1, Form2) ■ Enhanced CD (CD-EXTRA) L40 Series Features DVD-Video CD-RW CD-Text...
  • Page 25 CD-ROM Mode1, Mode2 ■ CD-ROMXA Mode2 (Form1, Form2) ■ Enhanced CD (CD-EXTRA) Lets you easily transfer data from five different types of common multimedia memory card used in a variety of devices, such as PDAs and digital cameras. L40 Series Features...
  • Page 26 LAN mini Card that is compatible with other systems that support the 802.11 b/g and the 802.11 a/b/g wireless communications standards. It offers frequency selection between 2.4GHz or 5GHz and allows roaming over multiple channels. L40 Series Features...

  • Page 27: Security Lock Slot

    This feature lets you save the battery’s power. You can specify the level of system power management in the Power Options. A specific hot key function locks the system ensuring data security. L40 Series Features...

  • Page 28: Utilities And Applications

    TOSHIBA Assist TOSHIBA DVD Player This is used to play DVD Video media through an Frame dropping, audio skipping, or out-of-synch audio and video may occur during playback of some DVD Video titles. Make sure to connect the computer’s AC adapter when playing a DVD video.
  • Page 29 TOSHIBA ConfigFree This is a suite of utilities to allow easy control of TOSHIBA Disc Creator CD/DVD Drive Acoustic Silencer Ulead DVD MovieFactory TOSHIBA (depending on configuration) Windows Mobility Center User’s Manual communication devices and network connections. ConfigFree also allows you to find communication problems and create profiles for easy switching between location and communication networks.

  • Page 30: Options

    Two memory module can be installed in this computer. An additional battery pack can be purchased from your TOSHIBA dealer. Use it as a spare or a replacement. If you use your computer at more than one site frequently, it may be convenient to purchase an additional AC adapter for each site so you will not have to carry the adapter with you.

  • Page 31: Chapter 2 The Grand Tour

    The Grand Tour This chapter identifies the various components of your computer. Become familiar with each component before you operate the computer. Certain types of notebook chassis are designed to accommodate all possible configurations for an entire product series. Your selected model may not have all the features and specifications corresponding to all of the icons or switches shown on the notebook chassis, unless you have selected all those features.

  • Page 32: Right Side

    Battery LED Hard Disk Drive LED Wireless Communication Switch* Wireless Communication LED* Right side The following figure shows the computer's right side. Headphone Jack Microphone Jack USB Port * The availability of this feature is dependent on the model you purchased. Headphone Jack Microphone Jack Universal Serial Bus...

  • Page 33: Left Side

    Multiple Digital Media Card Slot Access LED Multiple Digital Media Card Slot The green LED near the media card reader connector flashes when the system accesses the media card. Express Card Slot Left side The following figure shows the computer's left side. Optical Disc Drive Optical Disc Drive Optical Disc Drive...

  • Page 34: Back Side

    Back side The following figure shows the computer’s back panel. RGB (Monitor) Port USB Ports LAN Jack * The availability of this feature is dependent on the model you purchased. RGB Monitor Port Universal Serial Bus (USB) Port LAN Jack Modem Jack DC IN 19V Jack Fan vents...

  • Page 35: Underside

    Underside The following figure shows the computer’s underside. Battery Pack Battery Pack Lock Battery Pack Battery Pack Lock Battery Pack Latch Expansion Memory Socket User’s Manual Battery Pack Latch Expansion Memory Socket The battery pack powers the computer when the AC adapter is not connected.

  • Page 36: Front With The Display Open

    Front with the display open The following figure shows the front of the computer with the display open. To open the display, slide the latch on the front of the display and lift it up. Position the display at a comfortable viewing angle. Display Screen Keyboard Status Indicators Power Button...

  • Page 37: Keyboard Indicators

    Keyboard TouchPad Left and Right Speakers TouchPad Control Buttons Keyboard Indicators Caps Lock Mode Numeric Mode Scroll Lock Mode Optical Disc drive Depending on its configuration, the computer will either have a CD-RW/ DVD-ROM drive or a double layer DVD Super Multi drive. An ATAPI interface controller is used for the operation of these optical drives.

  • Page 38: Writable Discs

    Region codes for DVD drives and media The disc drive and its media are manufactured according to the specifications of six marketing regions. When you purchase DVD-Video, make sure it matches your drive, otherwise it will not play properly. Code Region Canada, United States Japan, Europe, South Africa, Middle East...
  • Page 39 CD-RW/DVD-ROM drive The full-size CD-RW/DVD-ROM drive module lets you record data to rewritable CDs as well as run either 12cm (4.72") or 8cm (3.15") discs without using an adapter. The read speed is slower at the center of a disc and faster at the other edge. DVD read CD read CD-R write...
  • Page 40 Use ONLY the AC Adapter supplied with the computer’s package or an AC adapter certified by TOSHIBA. Using the wrong adapter could damage your computer. TOSHIBA assumes no liability for any damage in such case. The output rating for the computer is 19 volts DC.

  • Page 41: Chapter 3 Getting Started

    Getting Started Before you attempt to use your computer, make sure to read the Instruction Manual for Safety and Comfort included in the package. The Instruction Manual for Safety and Comfort provides you with instructions to safely and fully use your computer. This chapter provides basic information to get you started using your computer.

  • Page 42: Opening The Display

    Use ONLY the AC Adapter supplied with the computer’s package or an AC adapter certified by TOSHIBA. Using the wrong adapter could damage your computer. TOSHIBA assumes no liability for any damage in such case. The output rating for the computer is 19 volts DC.

  • Page 43: Turning On The Power

    Use reasonable care when opening and closing the display panel. Opening it vigorously or slamming it shut could damage the computer. Turning on the power This section describes how to turn on the power. After you turn on the power for the first time, do not turn it off until you have set up the operating system.

  • Page 44: Turning Off The Power

    Turning off the power The power can be turned off in either of these three modes: Shutdown (Boot) Mode, Hibernation Mode, or Sleep Mode. Shut Down mode (Boot mode) When you turn off the power in Shut Down mode no data will be saved and the computer will boot to the operating system’s main screen the next time it is turned on.

  • Page 45: Executing Sleep Mode

    ■ When the AC adapter is connected, the computer will go into Sleep Mode according to the settings in the Power Options. ■ To restore the operation from the computer from Sleep Mode, press the power button or press any key. ■...

  • Page 46: Hibernation Mode

    ■ When the computer is in Sleep Mode, the power indicator will blink orange. ■ If you are operating the computer on battery power, you can lengthen the overall operating time by turning it off into Hibernation Mode - Sleep Mode will consume more power while the computer is off.

  • Page 47: Restarting The Computer

    Starting Hibernation Mode You can also enable Hibernation Mode by pressing Fn + F4. Refer to Chapter 5, The Keyboard To enter Hibernation Mode, follow the steps below. 1. Click Start then click the arrow button ( buttons ( 2. Select Hibernate from the menu. Automatic Hibernation Mode The computer can be configured to enter Hibernate Mode automatically when you press the power button or close the lid.

  • Page 48: System Recovery Options

    2. Switch on the computer and, when the In Touch with Tomorrow TOSHIBA prompt appears, press the F12 key to display the Boot Menu. 3. Use thecursor key to select the CD-ROM/DVD drive in the display menu. 4. Follow the on-screen instructions.

  • Page 49: Chapter 4 Basic Operations

    Basic Operations This chapter gives information on basic operations including using the TouchPad, optical disc drives, the internal modem, LAN and wireless LAN. It also provides tips on caring for your computer and on heat dispersal. Using the TouchPad To use the TouchPad, simply move your finger tip across it in the direction you want the on-screen pointer to go.

  • Page 50: Using The Internal Modem

    You can customize pointing device actions in Mouse Properties. Open the Control Panel, select the Mouse icon and press Enter to open the Mouse Properties window. Click: Double-click: Click the left control button twice or tap the TouchPad Scroll: Using the internal modem This section describes how to setup the modem and use it to connect to other computer systems.

  • Page 51: Region Selection

    1. Open the Modem Region Select application. It is located on the Programs menu at TOSHIBA Do not use the Country/Region Select function in the Modem setup utility in the Control Panel if the function is available. If you change the Country/ Region in the Control Panel, the change may not take effect.

  • Page 52: Modem Selection

    Settings You can enable or disable the following settings: AutoRun Mode Region Select Utility starts automatically when you start up the operating system. Open the Dialing Properties dialog box after selecting region The dialing properties dialog box will be displayed automatically after you select the region.

  • Page 53: Lan

    1. Plug one end of the modular cable into the modem jack. 2. Plug the other end of the modular cable into a telephone jack. Do not pull on the cable or move the computer while the cable is connected. If you use a storage device such as an optical media drive or hard disk drive connected to a 16-bit PC Card, you may find that the modem speed is slow or the communication session might be interrupted.

  • Page 54: Disconnecting The Lan Cable

    Connecting the LAN cable The computer must be configured properly before connecting to a LAN. Logging onto a LAN using the computer’s default settings could cause a malfunction in LAN operation. Check with your LAN administrator regarding set-up procedures. If you are using Ethernet LAN (10 megabits per second, 10BASE-T), you can connect using either a CAT5 or a CAT3 cable.

  • Page 55: Wireless Communication Switch

    Internet is an open invitation for outsiders to abuse your ISP account and privileges. 2. TOSHIBA is not liable for the eavesdropping on your data due to the use of the wireless LAN connection and any damage that may occur thereof.

  • Page 56: Using Optical Disc Drives

    When the computer is accessing a disc, an indicator on the drive illuminates. Use the TOSHIBA DVD Player application to view DVD-Video discs. If you have a CD-RW/DVD-ROM drive, refer also to the Writing CDs on CDRW/DVD-ROM drive section for precautions on writing to CDs.
  • Page 57 Basic Operations b. Pressing the eject button will not open the drawer when the computer’s power is off. If the power is off, you can open the drawer by inserting a slender object (about 15 mm) such as a straightened paper clip into the eject hole just to the right of the eject button.
  • Page 58 4. Lay the disc, label side up, in the drawer. Be careful not to touch the lens or the area around it. Doing so could cause the drive to malfunction. 5. Press gently at the center of the disc until you feel it click into place. The disc should lie below the top of the spindle, flush with its base.

  • Page 59: Removing Compact Discs

    Writing CDs on a CD-RW/DVD-ROM drive You can use the CD-RW/DVD-ROM drive to write data to CD-R/RW discs. This application for writing is preinstalled: TOSHIBA Disc Creator. Important message Before you write or rewrite to CD-R/RW media, read and follow all setup and operating instructions in this section.

  • Page 60: Before Writing Or Rewriting

    CD-RW and High speed CD-RW Ultra speed CD-RW TOSHIBA has confirmed the operation of CD-R and CD-RW media of the manufacturers above. Operation of other media cannot be guaranteed. ■ CD-RW can generally be rewritten about 1,000 times. However, the actual number of rewrites is affected by the quality of the media and the way it is used.

  • Page 61: When Writing Or Rewriting

    Write from the computer’s hard disk drive to the CD. Do not try to write from shared devices such as a LAN server or any other network device. ■ Writing with software other than TOSHIBA Disc Creator has not been confirmed. Operation with other software cannot be guaranteed. When writing or rewriting Observe/consider the following when you write or rewrite to a CD-R/RW, DVD-R/-RW/-RAM or DVD+R/+RW disc.

  • Page 62: Writing Cds/Dvds On A Dvd Super Multi Drive Supporting Double Layer Disc Recording

    Based on TOSHIBA’s limited compatibility testing, we suggest the following manufacturers of CD-R/RW and DVD-R/+R/-RW/+RW/-RAM media. However, in no event does TOSHIBA guarantee the operation, quality or performance of any disc. Disc quality can affect write or rewrite success rates.
  • Page 63 CD-R CD-RW and High speed CD-RW Ultra speed CD-RW DVD-R DVD-RW DVD+R DVD+RW *DVD-RAM DVD+R (Double Layer) DVD-R (Dual Layer) ■ If the disc is poor in quality, dirty or damaged, writing or rewriting errors may occur. Be careful to check the disc for dirt or damage before you use it.
  • Page 64 Write from the computer’s hard disk drive to the CD. Do not try to write from shared devices such as a LAN server or any other network device. ■ Writing with software other than TOSHIBA Disc Creator or Ulead DVD MovieFactory operation with other software cannot be guaranteed.

  • Page 65: When Using Ulead Dvd Moviefactory® For Toshiba

    How to make a DVD-Video Simplified steps for making a DVD-Video from video data captured from a DV-Camcorder: 1. Click Start Ulead DVD MovieFactory for TOSHIBA Launcher to launch DVD MovieFactory. 2. Insert a DVD-RW or DVD+RW disc in Burner. 3. Click Video Disc dialog box, choose DVD-Video/+VR to invoke Straight Capture to Disc Page.

  • Page 66: Important Information For Use

    Simplified steps for making a DVD-Video from adding a video source: 1. Click Start Ulead DVD MovieFactory for TOSHIBA Launcher to launch DVD MovieFactory. 2. Click Video Disc project type, then invoke DVD MovieFactory. 3. Add source from HD Disk by click Add Video files button to invoke browser dialog box.

  • Page 67: Toshiba Disc Creator

    You cannot use the TOSHIBA Disc Creator "Audio CD" function to record music to the DVD-R/-RW or DVD+R/+RW media. ■ Do not use the "Disc Backup" function of TOSHIBA Disc Creator to copy DVD-Video and DVD-ROM with copyright protection.DVD-RAM media cannot be backed up with the "Disc Backup" function of TOSHIBA Disc Creator ■...

  • Page 68: Data Verification

    ■ You might not be able to use the Disc Backup function of TOSHIBA Disc Creator to backup a DVD-R/-RW or DVD+R/+RW disc that was made with other software on a different DVD-R/-RW or DVD+R/+RW recorder. ■ If you add data to a DVD-R and DVD+R disc that you have already recorded to, you might not be able to read the added data under some circumstances.

  • Page 69: Discs

    5. Do not expose to direct sunlight, or extreme heat or cold, and do not place heavy objects on your discs. 6. If your discs become dusty or dirty, wipe them with a clean dry cloth. Wipe from the center out, do not wipe in a circular direction around the disc.

  • Page 70: Setting Up More Than One Display

    Setting up more than one display You can set up your computer to utilize more than one display, effectively spreading a single desktop screen across two monitors. The Display Properties window allows you to adjust more precisely the relative positioning of the two displays when they are configured as an extended desktop.

  • Page 71: Cleaning The Computer

    Cleaning the computer To help ensure long, trouble-free operation, keep the computer free of dust and use care with liquids around the computer. ■ Be careful not to spill liquids into the computer. If the computer does get wet, turn the power off immediately and let the computer dry completely before you turn it on again.

  • Page 72: Chapter 5 The Keyboard

    The Keyboard The computer’s keyboard layouts are compatible with a 104/105-key enhanced keyboard. By pressing some keys in combination, all the 104/105-key keyboard functions can be executed on the computer. The number of keys on your keyboard depends on which country/region’s keyboard layout your computer is configured with.

  • Page 73: F1 ... F12 Function Keys

    Soft keys: Fn key combinations The Fn (function) is unique to TOSHIBA computers and is used in combination with other keys to form soft keys. Soft keys are key combinations that enable, disable or configure specific features.

  • Page 74: Hotkeys

    Hotkeys Fn + ESC Mute – Turns the volume on and off. Fn + F1 Fn + F2 Fn + F3 Fn + F4 Fn + F5 Default resolution for simultaneous mode is set to WXGA (1280 × 800). If you connect an RGB (Monitor) that is not WXGA resolution, change it in "Display Properties".

  • Page 75: Keypad Overlay

    Keypad overlay Your computer’s keyboard does not have an independent numeric keypad, but its numeric keypad overlay functions like one. The keys in the center of the keyboard with white letters make up the numeric keypad overlay. The overlay provides the same functions as the numeric keypad.

  • Page 76: Temporarily Using Normal Keyboard (Overlay On)

    Temporarily using normal keyboard (overlay on) While using the overlay, you can temporarily access the normal keyboard without turning off the overlay: 1. Hold down Fn and press any other key. All keys will operate as if the overlay were off. 2.

  • Page 77: Chapter 6 Power And Power-Up Modes

    Power and Power-Up Modes The computer’s power resources include the AC adapter and internal batteries. This chapter gives details on making the most effective use of these resources including charging and changing batteries, tips for saving battery power, and power up modes. Power conditions The computer’s operating capability and battery charge status are affected by the power conditions: whether an AC adapter is connected, whether a...

  • Page 78: Battery Types

    The battery pack is a lithium ion battery, which can explode if not properly replaced, used, handled, or disposed. Dispose the battery as required by local ordinances or regulations. Use only batteries recommended by TOSHIBA as replacements. ■ Do not remove the battery pack while the computer is in Sleep Mode. In this mode data is stored in memory, so if the computer loses power, data will be lost.

  • Page 79: Care And Use Of The Battery Pack

    It may rupture or ignite. 6. DO NOT use other battery pack aside from the battery pack included in your computer package, or those TOSHIBA recommended battery packs. Use of an improper battery could cause smoke, fire, or explosion of the battery pack.
  • Page 80 DO NOT use the computer again until it has been checked by a TOSHIBA service provider. It might generate smoke or fire, or the battery pack might explode. 3. Make sure the battery is securely installed in the computer before attempting to charge the battery pack.

  • Page 81: Charging The Batteries

    6. Be sure to monitor the remaining battery power. If the battery pack or real time clock battery discharge completely, Sleep Mode will not function, data in memory will be lost, and the computer might register an incorrect time and date. In this case, connect the AC adapter to recharge the batteries.

  • Page 82: Battery Charging Notice

    Time The following table shows the time required to fully charge a discharged battery. Charging time (hours) Battery type Battery pack RTC battery The charging time when the computer is on is affected by ambient temperature, the temperature of the computer and how you use the computer.

  • Page 83: Maximizing Battery Operating Time

    Leaving the AC adapter connected will shorten battery life. At least once a week, run the computer on battery power until the battery is fully discharged, then recharge the battery. Monitoring battery capacity Remaining battery power can be monitored using the following methods. ■...

  • Page 84: Extending Battery Life

    ■ The condition of the battery terminals. Make sure the battery terminals stay clean by wiping them with a clean dry cloth before installing the battery pack. Retaining data with power off (sleep mode) When you turn off your computer with fully charged batteries, the batteries retain data/charge for the following approximate time periods: Battery RTC battery...
  • Page 85 Power and Power-Up Modes 5. Unlock the Battery Pack Lock. 6. Slide the battery pack latch to the left, then pull the battery out of the battery bay. User’s Manual...

  • Page 86: Installing The Battery Pack

    The battery pack is a lithium ion battery, which can explode if not properly replaced, used, handled or disposed of. Dispose of the battery as required by local ordinances or regulations. Use only batteries recommended by TOSHIBA as replacements. 1. Turn the computer's power off. 2. Disconnect all cables connected to the computer.

  • Page 87: System Automatic Sleep/Hibernation

    This feature automatically turns off the system in Sleep or Hibernation mode if the computer is not used for a set duration. Refer to Special explanation of how to set the duration. User’s Manual features, in Chapter 1, L40 Series Features Power and Power-Up Modes for an 6-11...

  • Page 88: Memory Expansion

    Optional Devices Optional devices can expand the computer’s capabilities and its versatility. This chapter describes connection or installation of the following types of devices, which are available from your TOSHIBA dealer: Cards/Memory ■ Express Card ■ SD/SDHC/MMC/MS/MS Pro/xD memory card ■...

  • Page 89: Removing An Express Card

    3. Check the configuration in the HW Setup window to make sure it is appropriate for your card. Removing an Express Card To remove the Express Card, follow the steps below. 1. In Windows Vista system tray and disable the Express Card. 2.

  • Page 90: Sd/Sdhc/Mmc/Ms/Ms Pro/Xd Memory Card

    SD/SDHC/MMC/MS/MS Pro/xD Memory card The computer is equipped with a multiple digital media card slot that can accommodate SD/SDHC/MMC/MS/MS Pro/xD memory cards. These memory cards let you easily transfer data from devices, such as digital cameras and Personal Digital Assistants, which use flash-memory. Card Type SDHC MS Pro...

  • Page 91: Installing A Memory Card

    Installing a memory card To install a memory card: 1. Insert the memory card. 2. Press gently to ensure a firm connection. Be sure the memory card is oriented properly before you insert it. If Windows fails to read the card, remove then reinsert it. The multiple digital media card slot only accepts one type of card at a time.

  • Page 92: Memory Card Care

    4. Grasp the card and remove it. ■ Make sure the memory card indicator is out before you remove the card or turn off the computer’s power. If you remove the card or turn off the power while the computer is accessing the card you may lose data or damage the card.

  • Page 93: Memory Expansion

    CAUTION: If you want to upgrade system memory, you should only use certified modules. Ask your vendor or check the TOSHIBA web site for a list of approved memory products. Insert the two memory modules of the same specifications and capacity into Slot A and Slot B respectively.

  • Page 94: External Monitor

    External monitor An external analog monitor can be connected to the external monitor port on the computer. To connect a monitor, follow the steps below. 1. Turn the computer off. 2. Connect the monitor to the external monitor port. 3. Turn the monitor's power on. 4.

  • Page 95: Troubleshooting

    Troubleshooting TOSHIBA designed the computer for durability. However, should problems occur, following the procedures in this chapter can help you to determine the cause. Problem solving process ■ Stop immediately when you recognize that a problem exists. Further action may result in data loss or damage. You may destroy valuable problem related information that can help solve the problem.

  • Page 96: Analyzing The Problem

    ■ Check that the optical disc drive is correctly inserted. Make notes of your observations and keep them in a permanent error log. This will help you describe your problems to your dealer. If a problem recurs, the log will help you identify the problem faster. Analyzing the problem Sometimes the system gives clues that can help you identify why it is malfunctioning.

  • Page 97: Hardware And System Checklist

    Hardware and system checklist This section discusses problems caused by your computer’s hardware or attached peripherals. Basic problems may occur in the following areas: ■ System start-up ■ Self test ■ Power ■ Battery ■ Keyboard ■ LCD panel ■ Hard disk drive ■...

  • Page 98: Overheating Power Down

    If any of the following conditions are present, the self test failed: ■ The computer stops and does not proceed to display information or messages except the TOSHIBA logo. ■ Random characters appear on the screen, and the system does not function normally.
  • Page 99 Keyboard Keyboard problems can be caused by your setup configuration. Problem Some letter keys produce numbers. Output to screen is garbled. Battery If you suspect a problem with the battery, check the DC IN indicator as well as the indicators for the battery. Problem Battery does not power the computer.

  • Page 100: Hard Disk Drive

    Problem Battery does not power the computer as long as expected. Hard disk drive Problem Computer does not boot from hard drive. Slow performance LCD panel Problem Lines appear broken. No display. Problems above remain unresolved or other problems occur. User’s Manual Procedure Check the power consumption settings in the...
  • Page 101 Wireless LAN If the following procedures do not restore LAN access, consult your LAN administrator. Problem Cannot access Wireless PC Card Problem PC Card error occurs Monitor Refer also to Chapter 7, documentation. Problem Monitor does not turn on Make sure that the external monitor’s power No display Display error occurs Monitor goes into...

  • Page 102: Pointing Device

    Sound system Problem No sound is heard Pointing device TouchPad Problem On-screen pointer does not respond to Pad operation Double-tapping does not work The mouse pointer moves too fast or too slow User’s Manual Procedure Adjust the volume control dial. Check the software volume settings.

  • Page 103: Usb Mouse

    Refer also to your USB device’s documentation. Problem USB device does not work USB mouse Problem On-screen pointer does not respond to mouse movement Double-clicking does not work The mouse pointer moves too fast or too slow The mouse pointer moves erratically User’s Manual Procedure...
  • Page 104 Memory expansion Problem The computer hangs up and issues beep sounds. (A long beep, three short beeps, three short beeps, and then a long beep.) Sleep/Hibernation Problem The system will not enter Sleep/Hibernation Modem Problem Communication software can’t initialize the modem You can hear a dial tone but can’t make a call You place a call, but a...
  • Page 105 Problem CONNECT quickly replaced by NO CARRIER Character display becomes garbled during a communication You cannot receive an incoming call CD-RW/DVD-ROM drive Problem You cannot access a disc in the drive Some discs run correctly, but others do User’s Manual Procedure display is Check the error control setting in your...
  • Page 106 User’s Manual Procedure If you have trouble writing, make sure you are observing the following precautions: ■ Use only media recommended by TOSHIBA. ■ Do not use the mouse or keyboard during writing. ■ Use only the software supplied with the computer for recording.

  • Page 107: Disk Drive

    Check the region code on the DVD. It must match that on the DVD Super Multi drive. If you have trouble writing, make sure you are observing the following precautions: ■ Use only media recommended by TOSHIBA. ■ Do not use the mouse or keyboard during writing. ■...

  • Page 108: Real Time Clock

    Time. TOSHIBA support If you require any additional help using your computer or if you are having problems operating it, you may need to contact TOSHIBA for additional technical assistance. Before you call Some problems you experience may be related to software or the operating system, it is important to investigate other sources of assistance first.

  • Page 109: Cpu

    (41°F to 86°F) or >25°C (77°F) at high altitude. All temperature references are approximate and may vary depending on the specific computer model. Refer to your PC documentation or visit the Toshiba website at CPU performance may also vary from specifications due to design configuration.

  • Page 110: Memory (Main System)

    Published battery life numbers are achieved on select models and configurations tested by Toshiba at the time of publication. Recharge time varies depending on usage. Battery may not charge while computer is consuming full power.

  • Page 111: Graphics Processor Unit ("Gpu")

    Graphics Processor Unit ("GPU") Graphics processor unit ("GPU") performance may vary depending on product model, design configuration, applications, power management settings and features utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.

  • Page 112: Specifications

    Specifications Appendix A Specifications This appendix contains the Notebook PC’s technical specifications. Dimensions 269.5mm 35.3mm User’s Manual...

  • Page 113: Environmental Requirements

    Weight Starting at 2.86kg* * Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected. Environmental Requirements Characteristics Temperature Altitude (from sea level) -30 to 10,000 feet Humidity Built-in Modem Some computers in this series are equipped with Modem functionality. Network control unit (NCU) Type of NCU Type of line...
  • Page 114 Communication Speed Error correcting Data compression User’s Manual Data transmission and reception 300/1200/2400/4800/7200/9600/12000/14400/ 16800/19200/21600/24000/26400/28800/ 31200/33600 bps Data reception only with V.90/V.92 28000/29333/30666/32000/33333/34666/ 36000/37333/38666/40000/41333/42666/ 44000/45333/46666/48000/49333/50666/ 52000/53333/54666/56000 bps Fax: 2400/4800/7200/9600/12000/14400 bps MNP class 4 and ITU-T V.42 MNP class 5 and ITU-T V.42bis Specifications...

  • Page 115: Display Modes

    Display Modes This appendix contains a table listing all the display modes when the display. is set to an external monitor. If you are running some applications (for example a 3D application or video playback and so on), you may see some disturbance, flickering or frame dropping on your screen.

  • Page 116: Certification Agencies

    AC Power Cord and Connectors The power cord’s AC input plug must be compatible with the various international AC power outlets and the cord must meet the standards for the country/region in which it is used. All cords must meet the following specifications: Length: Wire size:...
  • Page 117 AC Power Cord and Connectors For the United States and Canada, two pin plug configuration must be a 2-15P (250V) or 1-15P (125V) and three pin plug coniguration must be 6-15P (250V) or 5-15P (125V) as designated in the U. S. National Electrical code handbook and the Canadian Electrical Code Part II.

  • Page 118: If Your Computer Is Stolen

    What is your address, phone, and fax number? To register the theft on paper, please follow these procedures: ■ Fill in the TOSHIBA Theft Registration form (or a copy of it) below. ■ Attach a copy of your receipt showing where your computer was purchased.

  • Page 119: Toshiba Theft Registration

    TOSHIBA Theft Registration Send to: Fax number: Country stolen: Machine type: (e.g. L40 Series) Model number: (e.g. PSA30 YXT) Serial number: (e.g. 12345678G) Date stolen: Owner’s details Last name, first name: Company: Street: Postal Code/City: Country: Phone: Fax: User’s Manual...
  • Page 120 Glossary The terms in this glossary cover topics related to this manual. Alternate naming is included for reference. Abbreviations AC: alternating current AGP: accelerated graphics port BIOS: basic input output system CD-ROM: Compact Disc-Read Only Memory CD-RW: Compact Disc-Read/Write CMOS: complementary metal-oxide semiconductor CPU: central processing unit CRT: cathode ray tube DC: direct current...
  • Page 121 ROM: read only memory RTC: real time clock SCSI: small computer system interface TFT: thin-film transistor USB: Universal Serial Bus VESA: Video Electronic Standards Association VGA: video graphics array WXGA: wide extended graphics array adaptor: A device that provides an interface between two dissimilar electronic devices.
  • Page 122 cache memory: High speed memory which stores data that increases processor speed and data transfer rate. When the CPU reads data from main memory, it stores a copy of this data in cache memory. The next time the CPU needs that same data, it looks for it in the cache memory rather than the main memory, which saves time.
  • Page 123 CRT: Cathode Ray Tube. A vacuum tube in which beams projected on a fluorescent screen-producing luminous spots. An example is the television set. cursor: A small, blinking rectangle or line that indicates the current position on the display screen. DC: Direct Current. Electric current that flows in one direction. This type of power is usually supplied by batteries.
  • Page 124 format: The process of readying a blank disk for its first use. Formatting establishes the structure of the disk that the operating system expects before it writes files or programs onto the disk. function keys: The keys labeled F1 through F12 that tell the computer to perform certain functions.
  • Page 125 Light Emitting Diode (LED): A semiconductor device that emits light when a current is applied. Liquid Crystal Display (LCD): Liquid crystal sealed between two sheets of glass coated with transparent conducting material. The viewingside coating is etched into character forming segments with leadsthat extend to the edge of the glass.
  • Page 126 parity: 1) The symmetrical relationship between two parameter values (integers) both of which are either on or off; odd or even; 0 or 1. 2) In serial communications, an error detection bit that is added to a group of data bits making the sum of the bits even or odd. Parity can be set to none, odd, or even.
  • Page 127 TFT display: A liquid crystal display (LCD) made from an array of liquid crystal cells using active-matrix technology with thin film transistor (TFT) to drive each cell. TouchPad: A pointing device integrated into the TOSHIBA computer palm rest. Universal Serial Bus: This serial interface lets you communicate with several devices connected in a chain to a single port on the computer.

This manual is also suitable for:

Satellite l40-asp4261lm

Table of Contents
