RFU-UL
RFU-UL 1
RA-5200 QI
ENU Status : 1-0-0
INSTALLATION GUIDE FOR RA-5200
Performs to amplify and condition for uplink RF signals.
N-F connector for uplink input port, is connected to
the uplink output port on a POI system, or the "UP-
UP-LINK
LINK" port on the CBU when CBU option is in use.
Table 11: RFU-UL SIU description
Copyright - refer to title page
Page 43
