INSTALLATION GUIDE FOR RA-5200
The figures below show the equipment enclosure layout of RA-5200 MOU, ROU and RRU:
177
359
482

Fig 1: View of MOU fully equipped shelf

300 152
RS-485
DT DT DT
WCDMA GSM900 GSM1800
200-240V ~ 50Hz/60Hz OP/UP OP/DOWN

Fig 2: Front, side and bottom views of ROU enclosure

RA-5200 QI Copyright - refer to title page Page 14
ENU Status : 1-0-0
