f730
Car Camcorder
User Manual

Advertisement

Table of Contents
loading

Related Manuals for HP f730

Summary of Contents for HP f730

  • Page 1 Car Camcorder User Manual...

  • Page 2: Table Of Contents

    Contents About this Guide ..................3 Regulatory notices ................... 3 CE Regulatory Notice ................3 Notes on Installation ................3 Battery Notices ..................3 Caution ....................4 Introduction ................5 1.1 Features ..................... 5 1.2 Package Contents ................5 1.3 Product Overview ................6 2.
  • Page 3 3.5 File Browse ..................18 3.6 Setting ..................... 20 3.7 Parking Mode ................... 20 3.8 Driving Report .................. 22 4. Adjust the Settings ................ 23 5. Specifications ................26...

  • Page 4: About This Guide

    About this Guide The content in this document is for information purpose and is subject to change without prior notice. We made every effort to ensure that this User Guide is accurate and complete. However, no liability is assumed for any errors and omissions that may have occurred.

  • Page 5: Caution

    They are for your reference only.  HP Inc. Company is NOT responsible for the loss of any data/content during operation. Before you start using the Car Camcorder, it is assumed that you agree to the above statements.

  • Page 6: Introduction

    1 Introduction Thank you for purchasing this advanced camcorder. This camcorder is specifically designed for real time video and audio recording when driving. 1.1 Features  Full HD 1920*1080  Night Vision  F/1.4 big aperture  Driver report  Collision Detection ...

  • Page 7: Product Overview

    1.3 Product Overview...
  • Page 8 Item Rearview mirror clip LCD Screen Up/Previous option/Switch front or rear camera Short press: LCD on/off / Confirm Long press: Menu / Return Down/Next option USB port: Car power adapter connection A/V port: Rear Camera connection (option) MicroSD memory card slot GPS port: External GPS connection (option) Speaker Reset...

  • Page 9: Getting Start

    2. Getting Start 2.1 Insert the Memory Card Insert the memory card with the gold contacts facing the back of the camcorder. Push the memory card until it clicks into place. (Use class 10 or greater speed micro SD cards for this camcorder; It is recommended to format the micro SD cards before the initial use.) To remove the memory card Push the edge of the memory card inward until you hear/feel it click,...

  • Page 10: Install In Vehicles

    2.2 Install in Vehicles Clip on to your original car mirror. Circle the clip with the band. Adjust the camcorder lens. Note: Image shown here is for installation illustration. The outlook may differ from what you purchased.

  • Page 11: Connecting To Power

    2.3 Connecting to Power Use only the supplied car adapter to power up the camcorder and charge the built-in battery. 1. Connect one end of the car adapter to the USB connector of the camcorder. USB port input: DC 5V / 2A. 2.
  • Page 12 Battery Status Indicator: Icon Description Low battery 1/4 battery capacity remaining 1/2 battery capacity remaining 3/4 battery capacity remaining Battery full charged External power connected...

  • Page 13: Powering The Camcorder On / Off And Reset

    2.4 Powering the Camcorder On / Off and Reset 2.4.1 Auto Power On/Off Once the vehicle engine is started, the camcorder automatically powers on. And the recording will automatically start. Once the vehicle engine shuts down, the camcorder automatically saves the recording and turns off the power within 10 seconds.

  • Page 14: Initial Settings

    2.5 Initial Settings 2.5.1 Set the Date and Time We recommend to set up date and time before initial use. To set the correct date and time, do the following: In the recording screen, long press button to enter the OSD menu.

  • Page 15: Using The Camcorder

    3. Using the Camcorder 3.1 Recording Videos 3.1.1 Auto Recording When the vehicle engine starts up, the camcorder automatically turns on and starts recording. Recording will automatically stop when the engine is switched off. Note: 1. On some cars, the recording will continue when the engine is switched off. If this happens, please manually turn off the cigarette lighter or remove the car adapter from the cigarette lighter.

  • Page 16: Emergency Recording

    3.1.2 Emergency Recording This Car Camcorder is equipped with a G-Force sensor. If the G-sensor function is enabled, when collision is detected, the camcorder will automatically trigger the Emergency Recording feature. The emergency icon will be displayed on top of screen. The emergency recording files will not be overwritten by the normal loop recording files.

  • Page 17: Photos

    3.2 Photos In the recording screen, long press button to enter the OSD menu. Press to select [Photos] card, and press to enter. In current preview mode, press again to take photo, you will hear “ka-za” sound and the photo will be saved in the Photo folder. By this way to take photo, it’s only available to take singe camera’s image, it cannot be taken dual camera’s images.

  • Page 18: Gps (Option)

    3.3 GPS (Option) Plug the optional GPS accessory into GPS port on the camcorder. Once activate the GPS function, you can preview current car speed, speed cam ahead, traffic lights and direction such information. To activate GPS function, follow the below steps, In the recording screen, long press button to enter the OSD menu.

  • Page 19: Rear Camera (Option)

    Note: 1. GPS function is limited in certain areas. Please contact dealer for details. 2. Once activate the GPS function, when GPS is positioned, the icon will change from white to blue 3. If GPS function is not activated from Menu, even you plug in the GPS accessory, the function is not workable.
  • Page 20 Long press button to select Video, Photo or Lock folder. Short press button to select FRONT or BACK folder, then press button to enter the folder. Then, short press button to select the file of your preference and press button to check the file. Press once button to playback the file, press button again to pause.

  • Page 21: Setting

    3.6 Setting In the recording screen, long press button to enter the OSD menu. Press a few times to select [Setting] card, and press to enter. You can select “Video”, “Security” or “System” option to set up the camcorder. Please refer to 4. Adjust the Setting for details. 3.7 Parking Mode To monitor the vehicle when it is parked, you can activate Parking Mode.
  • Page 22 recording files. Once it finishes recording, the camcorder will power off again and enter Parking Mode. Note: 1. If battery in a fully charged condition, it can record a few hours in Parking Mode . As the camcorder is used, the battery storage capacity will decrease gradually. The recording time will be lesser.

  • Page 23: Driving Report

    3.8 Driving Report When the car engine turns off and before car camcorder completely power off, the driving report will show driving time, sudden break times and sudden speed times of this journey. To activate the Driving Report, do the following, In the recording screen, long press button to enter the OSD menu.

  • Page 24: Adjust The Settings

    4. Adjust the Settings Refer to the below table for details on menu items and available menu options. Menu Sub-Menu Description Available option Resolution Setting of video resolution 1080p / 720p / 480p Cycle Set the recording duration 1 min/ 3 min/ 5 min Video for each recorded video file VGA / 1M / 2M / 3M / 5M /...
  • Page 25 Menu Sub-Menu Description Available option Time-lapse To activate one second one On/off video frame recording. If parking mode is activated, the camcorder Parking will enter parking mode 10 On/ off seconds after disconnect the external power. Security If activate, the camcorder will automatically trigger Motion and record once it detects...
  • Page 26 Menu Sub-Menu Description Available option Adjust the camcorder’s Speed speed to match your On/off calibration car’s. To display driving period, sudden break times and Driving On/off Report sudden speed-up times of this journey. Set the on-screen display Simplified Chinese / Language menu language Traditional Chinese / English...

  • Page 27: Specifications

    5. Specifications Item Description Image sensor 1/2.9” CMOS sensor Effective pixels 1920 (H) x 1080 (V) Storage media Supports Micro SDHC, up to 32GB class 10 speed or greater LCD display 7.84” LCD color TFT Wide Angle Fixed Focus lens Lens Aperture: Up to F1.8 Focus range...
