- Page 1 F I T Z W I L L I A M I N T E R N E T & D I G I T A L R A D I O S Y S T E M FTZ-ADT-SIL Instructions Guide...
-
Page 2: Table Of Contents
Contents What’s in the Box? Controls And Functions Support Instructions Guide Navigation Settings ��������������������������������������������������� Basic Operation �������������������������������������������������������� Connecting to WiFi �������������������������������������������������� Additional WiFi Connection Settings ������������������������ Internet Radio ���������������������������������������������������������� Spotify Connect (in applicable models) ������������������� Music Player ������������������������������������������������������������ DAB/DAB+ Radio �����������������������������������������������������... -
Page 3: What's In The Box
What’s in the Box? Box Contents 1. Majority Fitzwilliam 2. Remote Control 3. Power Adapter 4. Instructions Guide... -
Page 4: Controls And Functions
Controls And Functions Front View (Control Panel) 10 11 12 Navigation Mode Memory Menu Back Info USB port 5V 1A Display screen Headphone jack Play/Pause button Navigation/OK dial 10. Rewind button Mode button 11. Fastforward button Memory button 12. Info button Menu button 13. - Page 5 Controls And Functions Back View (Ports) AUDIO ANALOG AUDIO DAB/FM W-LAN LAN INPUT OUTPUT AUDIO OUTPUT ANTENNA analog 5.9V optical coaxial input output DC IN BLUETOOTH ANTENNA 15. DC power input 19. Optical & Coaxial Output 16. W-LAN 20. LAN input 17.
- Page 6 Controls And Functions Remote Control Dimmer Alarm Sleep Mode Menu VOL+ VOL- PQRS PQRS WXYZ WXYZ INFO...
- Page 7 Controls and Functions Power/Standby 13. Sleep button Press to switch between power Press to set a sleep timer for and standby mode standby mode Dimmer button 14. Mode button Press repeatedly to switch Select to open main menu screen with available modes between four dimmer options 15.
-
Page 8: Support
Support Support Thank you for your purchase of the Majority Fitzwilliam. Please follow the guidance of the manual to set up the product and begin enjoying its features. If you require further assistance with your new purchase, please contact our support team on the Majority website:... -
Page 9: Instructions Guide
Instructions Guide Navigation Settings Power/Volume dial: This should be used to turn your system on and into Standby. To put into standby, press and hold the dial (Ref.13) to display the time, date and any settings set such as alarms. To turn off standby, press down dial to be taken to the last function that you were using before putting into standby. -
Page 10: Basic Operation
Plug the adaptor connector into the back of the system labelled ‘DC in’ (Ref.15) and turn the power on from the mains. The system will begin to power up and display a ‘MAJORITY’ screen. Ensure that the WLAN antenna and DAB/FM antennas are screwed onto the unit via the WLAN port (Ref.16) and DAB/FM... - Page 11 Instructions Guide “Set timezone” options will now display, so that the correct time to your region will show on the unit. Scroll through the available options with the Navigation dial or the remote, confirm choice by pressing down the dial or the OK button on the remote.
-
Page 12: Connecting To Wifi
“WPS” button on your WiFi modem. This will connect your WiFi to your radio without manually writing in the postcode. If “PIN” is selected, a pin will display on the Fitzwilliam screen. If your WiFi is capable of inserting a PIN, enter the code into your WiFi network. -
Page 13: Additional Wifi Connection Settings
(Rem.18) to initiate a rescan for available WiFi networks. Wired Connect a LAN cable into your WiFi modem and connect into the Fitzwilliam LAN socket (Ref.20). This creates a direct network connection to the unit. Manual Configuration The following options are available: Wired (LAN) - DHCP Enable: Select Wired >... -
Page 14: Internet Radio
Instructions Guide Internet Radio On first setting up, a list of available modes will display. Select “Internet Radio” from this list using the Navigation/OK dial (Ref.3) or the OK button (Rem.18). Alternatively, press the ‘Mode’ button on the unit (Ref.4) or on the remote (Rem.14) repeatedly to scroll through to Internet Radio mode. - Page 15 Instructions Guide Stations - Select option to access all available stations on the radio and narrow down by Location, Genre, Popular Stations or New Stations. You can also search for stations via this menu: Search Stations - Manually type in a station with the Navigation dial or using the navigation buttons on the remote.
- Page 16 Instructions Guide Internet Radio: Preset Stations Presetting a Radio Station When you have found your desired station, hold down the Memory button on the unit (Ref.5) or the ‘FAV’ button on the remote (Rem.10) for 2-3 seconds to go to the ‘Save to Preset’ screen.
- Page 17 Instructions Guide Internet Radio: Station Information Station information can be displayed by the station broadcaster which is able to be viewed when listening to particular stations. If the station is broadcasting information, the ‘Info’ button on the unit (Ref.12) or on the remote (Rem.22) can be pressed repeatedly to scroll through the following information: Programme Information - Displays artist and song currently being played on the station.
-
Page 18: Spotify Connect (In Applicable Models)
Please note that this is only compatible in applicable models. Listen out loud with Spotify Connect 1. Connect your Majority Fitzwilliam to your wifi network 2. Open up the Spotify app on your phone, tablet or laptop using the same wifi network 3. -
Page 19: Music Player
Choose the Fitwilliam from your chosen device. Go to the Fitzwilliam and select the device (home server, PC etc) that you wish to connect to and press the OK button to open shared folders on that device. - Page 20 Instructions Guide My Playlist: You can create local playlist on the radio from ’Shared Media’ and the ‘USB Playback’ settings. On ‘Shared Media’ or ‘USB Playback’ settings, choose the file to be added to the playlist. Press and hold the Navigation/OK dial or OK button on the remote for approximately 3 seconds until the display shows “Added to Playlist”.
-
Page 21: Dab/Dab+ Radio
Instructions Guide DAB/DAB+ Radio Press the ‘Mode’ button on the unit (Ref.4) or on the remote (Rem.14) repeatedly to scroll through to DAB/DAB+ mode. Ensure that the antenna is screwed on and connected to the DAB/FM antenna port at the back of the system, and then fully extended. - Page 22 Instructions Guide DAB/DAB+ Preset Stations Presetting a Radio Station When you have found your desired station, hold down the Memory button on the unit (Ref.5) or the ‘FAV’ button on the remote (Rem.10) for 2-3 seconds to go to the ‘Save to Preset’ screen.
- Page 23 Instructions Guide DAB/DAB+ Radio Settings In DAB/DAB+ mode, press the MENU button on the unit or on the remote control to open DAB/DAB+ settings. Use the Navigation/OK dial (Ref.3) or the Up/Down buttons on the remote control (Rem.7/19) to scroll through the following options: Station List Select this option to browse through the available DAB/DAB+...
- Page 24 Instructions Guide Instructions Guide DRC (Dynamic Range Compression) Select this option to reduce the volume of louder sounds and boost the volume of quiter sounds. Select High, Low or Off with the Navigation/OK dial or the OK button on the remote. Station Order Select the order that you would like the DAB/DAB+ stations to display in.
- Page 25 Instructions Guide DAB/DAB+ Station Information Whilst playing a DAB/DAB+ station, the following station information can be viewed by pressing the ‘Info’ button repeatedly on the unit or on the remote. Programme Information: Displays artist and song currently being played on the station. PTY (Programme Type): Shows the type and description of the programme provided by the DAB station.
-
Page 26: Fm Radio
Instructions Guide FM Radio Press the ‘Mode’ button on the unit (Ref.4) or on the remote (Rem.14) repeatedly to scroll through to FM mode. Ensure that the antenna is screwed on and connected to the DAB/FM antenna port at the back of the system (Ref.21), and then fully extended. - Page 27 Instructions Guide FM Preset Stations Presetting a Radio Station When you have found your desired station, hold down the Memory button on the unit (Ref.5) or the ‘FAV’ button on the remote (Rem.10) for 2-3 seconds to go to the ‘Save to Preset’ screen.
- Page 28 Instructions Guide FM Radio Settings In DAB/DAB+ mode, press the MENU button on the unit (Ref.6) or on the remote control (Rem.6) to open DAB/DAB+ settings. Use the Navigation/OK dial (Ref.3) or the Up/Down buttons on the remote control (Rem.7/19) to scroll through the following options: Scan Setting Select whether you would like to scan for all stations, or for...
- Page 29 Instructions Guide FM Station Information Whilst playing a FM station, the following station information can be viewed by pressing the ‘Info’ button repeatedly (Ref.12) on the unit or via the remote (Rem.22) Programme Information: Displays artist and song currently being played on the station. PTY (Programme Type): Shows the type and description of the programme provided by the DAB station.
-
Page 30: Bluetooth Mode
Bluetooth. Please note that the radio only takes Bluetooth input from devices such as a phone or tablet. The device will display as “Majority Fitzwilliam”. Select the radio from your device and they will begin to connect. -
Page 31: Aux In Mode
Audio-in jack on the back of the unit (Ref.18). Insert the AUX audio cable from the back of the Fitzwilliam into the device that you wish to play media from. Now begin playing media from your device. Ensure that the volume on the device is switched up for the best sound quality. -
Page 32: Dual Alarm Setting
Instructions Guide Dual Alarm Setting Setting Alarm 1/Alarm 2 To set an alarm on your radio, select the ‘Alarm’ button on the remote control (Rem.12) or select the ‘Menu’ button on the unit. Select ‘Main Menu’ and select ‘Alarms’ to open alarm settings. After selecting the alarm setting, select Alarm 1 or Alarm 2 with the navigation dial (Ref.3) or OK button on the remote (Rem.18) to begin setting the following alarm functions:... - Page 33 Instructions Guide Setting: Alarm Features How to cancel your alarm Cancel the alarm before it sounds by pressing the ‘Alarm’ button on the remote control (Rem.12) or select the ‘Menu’ button on the unit. Follow by selecting ‘Main Menu’ and select ‘Alarms’ to open alarm settings.
-
Page 34: Sleep Timer Settings
Instructions Guide Sleep Timer Settings A sleep timer can be set to switch your radio to standby after the selected period of time. Setting via the Sleep Button To set a sleep timer, select the ‘Sleep’ button on the remote (Rem.13) Press the Sleep button repeatedly to switch between sleep times available. -
Page 35: System Settings
Instructions Guide System Settings Access system settings by pressing the MENU button on the unit (Ref.6) or on the remote control (Rem.6) Scroll to ‘System Settings’ and select this option. Use the Navigation/ OK dial (Ref.3) or the Up/Down buttons on the remote control (Rem.7/19) to scroll through the following options: Equaliser Choose between a variety of equaliser settings that improve the... - Page 36 LAN cable into your WiFi modem and connect into the Fitzwilliam LAN socket (Ref.20). NetRemote PIN Setup - A pin can be located here, which must be inputted into the remote control app to connect. You can also change the PIN number here.
- Page 37 Instructions Guide Set Timezone: Select your timezone to set the correct time on the unit. Daylight savings: Select whether you would like daylight savings for automatic adjustment between summer time and winter time switched on or off. Language Select your chosen default language for the radio from the list with the Navigation/OK dial or the OK button on the remote.
- Page 38 Instructions Guide Info Select to view software version, spotify version, Radio ID and name. Privacy Policy Information regarding where further privacy information can be located. Backlight Select to set the following backlight levels: Timeout: Select the option to choose the backlight display timeout.
-
Page 39: Remote Control App
Once the app is downloaded, open the app and ensure that your radio is switched on and out of standby mode. The app should then automatically display the Majority Fitzwilliam. Select the device to connect. You can now begin adjusting settings and navigating around the... -
Page 40: Troubleshooting
Ensure that you are on Bluetooth mode on the radio and the Bluetooth on your device is switched on. Select the Bluetooth device ‘Majority Fitzwilliam’ and you should now be able to play audio. If audio is not playing, disconnect the device from your Bluetooth settings and reconnect. -
Page 41: Specifications
Specifications Specifications 100-240V ~ 50-60Hz Power Input Operation: 8W Power Consumption WiFi: WLAN, LAN input FM: 87.5MHz - 108 MHz DAB: 174 - 240 MHz Mode: Bluetooth 3.5mm AUX-in, Audio R/L output, Coaxial and Optical USB: MMP3, AAC, WMA, FLAC, WAV Charging - 5V 1A Power consumption Operation - 4W... -
Page 42: Safety Information
Safety Information ADDITIONAL WARNINGS 1. Read these instructions. 2. Keep these instructions. Instructions are also The apparatus shall not be exposed to dripping or available for download at www.majorityradios.co.uk splashing and no objects filled with liquid, such as 3. Heed all Warnings vases, shall be places on the apparatus. - Page 44 www.majorityradios.co.uk...
