MAJORITY WILLINGHAM Instruction Manual

Digital radio & music system
Hide thumbs
Table of Contents

Advertisement

Quick Links

W I L L I N G H A M
D I G I T A L R A D I O & M U S I C S Y S T E M
WIL-CDAB-WAL
Instructions Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WILLINGHAM and is the answer not in the manual?

Questions and answers

Related Manuals for MAJORITY WILLINGHAM

Summary of Contents for MAJORITY WILLINGHAM

  • Page 1 W I L L I N G H A M D I G I T A L R A D I O & M U S I C S Y S T E M WIL-CDAB-WAL Instructions Guide...

  • Page 2: Table Of Contents

    Contents What’s in the Box? Controls And Functions  Support  Instructions Guide  Navigation Settings ��������������������������������������������������� Basic Operation �������������������������������������������������������� DAB/DAB+ Radio ����������������������������������������������������� DAB Radio Settings �������������������������������������������������� FM Radio ����������������������������������������������������������������� FM Radio Settings ���������������������������������������������������� Bluetooth Mode ����������������������������������������������������� AUX-In Mode ����������������������������������������������������������� CD Player �����������������������������������������������������������������...

  • Page 3: What's In The Box

    What’s in the Box? Box Contents 1. Majority Willingham 2. Remote Control 3. Power Adapter 4. Instructions Guide...

  • Page 4: Controls And Functions

    Controls And Functions Top View (Control Panel) Navigation Menu Repeat/Program Power/Mode CD eject/load Info/Menu 10. Play/Pause - CD mode and Alarm Preset 1 button Sleep 11. Repeat/Program - CD Previous mode and Preset 2 button Next 12. Rewind - CD mode and Navigation/Volume/OK/ Preset 3 button Stop dial...
  • Page 5 Controls And Functions Front View 14. Display screen 15. CD port Back View 16. DC power input 19. USB Port 17. Headphone port 20. Antenna 18. Aux In...
  • Page 6 Controls And Functions Remote Control Mode Menu Preset...
  • Page 7 Controls and Functions Power On/Standby 12. EQ (Equaliser) button Select to choose equaliser Switch the unit between on and settings Standby mode 13. CD Eject button Up button Left button Select to eject a CD from the CD Navigate left/Go back a track in player.

  • Page 8: Support

    Support Support Thank you for your purchase of the Majority Willingham radio. Please follow the guidance of the manual to set up your new purchase and begin enjoying its features. If you require further assistance with your new radio, please contact our support team on the Majority website:...

  • Page 9: Instructions Guide

    Instructions Guide Navigation Settings Power/Mode button: This should be used to turn your radio on and into Standby. To put into standby, press and hold the button to display the time, date and any settings set such as alarms. To turn off standby, press the Standby button to be taken to the home screen, or last function that you were using before putting into standby.

  • Page 10: Basic Operation

    Plug the adaptor connector into the back of the system labelled ‘DC in’ (Ref.16) and turn the power on from the mains. The radio will begin to power up and display a ‘MAJORITY’ screen. Ensure the antenna (Ref.20) is extended as far as possible. This will enable you to get the best signal you can before going to DAB and FM modes and beginning to scan for available stations.
  • Page 11 Instructions Guide Standby Mode To place the radio into standby, press and hold the Power/Mode button (Ref.1) for 2-3 seconds and a standby screen showing the date, time and alarm settings will display. To take the radio off standby, press the Power/Mode button (do not hold).

  • Page 12: Dab/Dab+ Radio

    Instructions Guide DAB/DAB+ Radio Press the Power/Mode button (Ref.1) (do not hold the button) or (Rem.6) to open the mode home screen. Select ‘DAB/DAB+’ on the main display screen by browsing with the Navigation dial (Ref.7) and selecting the mode by pressing down the dial or use the navigation buttons on the remote (Rem.2/3/4/5/15).
  • Page 13 Instructions Guide DAB/DAB+ Preset Stations Pre-setting your favourite DAB/DAB+ stations Up to 10 DAB/DAB+ stations can be preset for easy navigation. To create a preset, you must be listening to the chosen station. Presetting from the unit From the unit, you can easily set preset number 1-3 by pressing and holding one of the Preset 1-3 buttons (Ref.10 /11/12 Please ensure that the button is held for 2-3 seconds rather than...
  • Page 14 Instructions Guide Recalling your preset DAB/DAB+ stations Recalling presets from the unit From the unit, you can easily recall preset number 1-3 by pressing one of the Preset 1-3 buttons (Ref.10 ). Please /11/12 ensure that the button is being pressed and released, rather than held.
  • Page 15 Instructions Guide DAB/DAB+ Station Information Whilst playing a DAB/DAB+ station, the following station information can be viewed by pressing the ‘Menu/Info’ button repeatedly (Ref.2) on the unit. Dynamic Label Segment (DLS): Displays text information supplied by the broadcaster. PTY (Programme Type): Shows the type and description of the programme provided by the DAB station.

  • Page 16: Dab Radio Settings

    Instructions Guide DAB Radio Settings On DAB mode, open DAB radio settings by pressing and holding the Menu/Info button (Ref.2) for 2-3 seconds. The following setting options will then display: Station List: Select this option to view the available stations to begin playing on the unit.

  • Page 17: Fm Radio

    Instructions Guide FM Radio Press the Power/Mode button (do not hold the button) (Ref.1) or (Rem.6) to open the mode home screen. Select ‘FM’ on the main display screen by browsing with the Navigation dial (Ref.7) and selecting the mode by pressing down the dial or use the navigation buttons on the remote (Rem.2/3/4/5/15).
  • Page 18 Instructions Guide FM Preset Stations Pre-setting your favourite FM stations Up to 10 FM stations can be preset for easy navigation. To create a preset, you must be listening to the chosen station. Presetting from the unit From the unit, you can easily set preset number 1-3 by pressing and holding one of the Preset 1-3 buttons (Ref.10 /11/12 Please ensure that the button is held for 2-3 seconds rather than...
  • Page 19 Instructions Guide Recalling your preset FM stations Recalling presets from the unit From the unit, you can easily recall preset number 1-3 by pressing one of the Preset 1-3 buttons (Ref.10 ). Please /11/12 ensure that the button is being pressed and released, rather than held.
  • Page 20 Instructions Guide FM Station Information Whilst playing a FM station, the following station information can be viewed by pressing the ‘Menu/Info’ button repeatedly (Ref.2) on the unit. Dynamic Label Segment (DLS): Displays text information supplied by the broadcaster. PTY (Programme Type): Shows the type of the programme provided by the station.

  • Page 21: Fm Radio Settings

    Instructions Guide FM Radio Settings On FM mode, open FM radio settings by pressing and holding the Menu/Info button (Ref.2) for 2-3 seconds. The following setting options will then display: Scan Setting: Choose between scanning only stations with strong signal, or scanning for all stations, including those with weak signals.

  • Page 22: Bluetooth Mode

    Bluetooth. Please note that the radio only takes Bluetooth input from devices such as a phone or tablet. The device will display as “Majority Willingham”. Select the radio from your device and they will begin to connect.

  • Page 23: Aux-In Mode

    Instructions Guide AUX-In Mode Press the Power/Mode button (Ref.1) (do not hold the button) or (Rem.6) to open the mode home screen. Select ‘AUX’ on the main display screen by browsing with the navigation dial (Ref.7) and selecting the mode by pressing down the dial or use the navigation buttons on the remote (Rem.2/3/4/5/15).

  • Page 24: Cd Player

    Instructions Guide Instructions Guide CD Player Press the Power/Mode button (Ref.1) (do not hold the button) or (Rem.6) to open the mode home screen. Select ‘CD’ on the main display screen by browsing with the navigation dial (Ref.7) and selecting the mode by pressing down the dial or use the navigation buttons on the remote (Rem.2/3/4/5/15).
  • Page 25 Instructions Guide Arrange a CD song program This setting allows you to program the CD player to play songs in a particular order. 1. A CD must be inserted into the CD player of the machine. To open program settings, press and hold down the Navigation dial for 3 seconds (Ref.7) or press and hold the OK button on the remote (Rem.4) for 3 seconds to stop the CD.

  • Page 26: Usb Playback

    Instructions Guide USB Playback Press the Power/Mode button (Ref.1) (do not hold the button) or (Rem.6) to open the mode home screen. Select ‘USB’ on the main display screen by browsing with the navigation dial (Ref.7) and selecting the mode by pressing down the dial or use the navigation buttons on the remote (Rem.2/3/4/5/15).

  • Page 27: Dual Alarm Setting

    Instructions Guide Dual Alarm Setting Setting Alarm 1/Alarm 2 To set an alarm on your radio, select the ‘Alarm’ button (Ref.3) on the unit or on the remote control (Rem.9) After selecting the alarm setting, select Alarm 1 or Alarm 2 with the navigation dial (Ref.7) or navigation buttons on the remote (Rem.2/3/4/5/15) to begin setting the following alarm functions:...
  • Page 28 Instructions Guide Setting: Alarm Features How to cancel your alarm Cancel the alarm before it sounds by pressing the Alarm button (Ref.3) in standby mode or working mode. Select the alarm that you would like to cancel: Alarm 1 or Alarm 2 with the navigation dial (Ref.7).

  • Page 29: Sleep Timer Settings

    Instructions Guide Sleep Timer Settings A sleep timer can be set to switch your radio to standby after the selected period of time. To set a sleep timer, select the ‘Sleep’ button on the unit (Ref.4) or on the remote (Rem.8) to open the “Set Sleep Timer” screen. Press the Sleep button repeatedly to switch between sleep times available.

  • Page 30: System Menu Settings

    Instructions Guide System Menu Settings Access the menu settings by pressing and holding the Info/ Menu button for 2-3 seconds on any of the modes. Scroll with the navigation dial (Ref.7) to the “System Settings” option and select with the dial. The following setting options will display: Time/Date Once this is selected, the following options will display for setting:...
  • Page 31 Instructions Guide Equaliser Choose between a variety of equaliser settings that improve the sound quality of the audio type/genre: Normal, Classic, Jazz, Pop, Rock, Speech or My EQ. My EQ allows you to manually adjust the bass and treble and tailor to your desired sound. Select the chosen option with the navigation dial OK button (Ref.7) Backlight Timeout:...
  • Page 32 Instructions Guide Additional Features Headphone Jack You can listen to any mode on the radio via your favourite earphones, rather than the external speakers. Insert the earphone port into the headphone jack at the back of the radio (Ref.17).

  • Page 33: Troubleshooting

    Ensure that you are on Bluetooth mode on the radio and the Bluetooth on your device is switched on. Select the Bluetooth device ‘Majority Willingham’ and you should now be able to play audio. CD player not working Go to CD mode. Gently insert a CD and the CD player should automatically take the CD within the drive.

  • Page 34: Specifications

    Specifications Specifications DC 12V 2A (output) Power Supply FM: 87.5MHz - 108 MHz DAB: 174 - 240 MHz Mode: Bluetooth 3.5mm AUX-in USB: MP3, WMA Dimensions 40 x 24 x 13cm Weight 3.8kg Warranty All products come with a standard 12 month warranty. All items www.majorityradios.co.uk must be registered on for the...

  • Page 35: Safety Information

    Safety Information ADDITIONAL WARNINGS 1. Read these instructions. 2. Keep these instructions. Instructions are also The apparatus shall not be exposed to dripping or available for download at www.majorityradios.co.uk splashing and no objects filled with liquid, such as 3. Heed all Warnings vases, shall be places on the apparatus.
  • Page 37 www.majorityradios.co.uk...
